iCare Mini GPS User's Manual

Instruction Manual

Port
Power Button
Charging
Please use authorized Magnetic head charging cable
to connect with the port.
And please allow up to 5 hours for first charge. After
the first charge, up to 2 hours is required for a full
charge. ( During charging, the red LED will stay on.
When fully charged, LED will be steady green.)
Turn on/off
Turn on: Press the power button for 3~5 seconds, 3 LEDs
will light up, after second LEDs will go off at the same time.
Turn off: Press the power button for 3~5 seconds, 3 LEDs
will light up, after second LEDs will go off one by one.
Notice
GPS Limitation:
*GPS will more accurate at the outdoor space.
*When beside the building、valley or street will
have some deviation by the signal reflection.
*There is no GPS signal at the indoor space 、
basement or tunnel. Those place can only
supply LBS refernce position.
LBS cell site refernce position
* Device is in the range of LBS signal, not
device location.
*Cell site have high density in the downtown
area, it's make LBS refernce position more near
with practical location.
*Even different device at the same place and if
connect with different cell site will shows
different refernce podition.
No movement for 3 min
*Will change to sleep mode when device is
normal or urgent mode.
When device have been moved it will
return to working status.
*Power saving mode will not change to
sleep mode.
www.traceez.com
Pet collar penetrate
Silicone strips on both sides
of the ear hole
LED Indicator :
Low power : flash red
GPS working : flash blue
GSM working : flash green
Status confirmation : Short
press the power button
Marquee: in operation
No lights: has been turned off
what's is in color box
color box
Quick guide
Page 1
V3.0
(Model:MSP380M)
How to install
Silicon Article
Power key
Silicon Case
iCare Mini
Magnetic head
Silicon Article
charging cable
