- Page 1 MEGATEC Compact Leg Press MT-CLP-350 Assembly Walkthrough The Megatec Compact Leg Press comes in 2 boxes. The dimensions are: Carton 1 Carton 2 Length Width Depth Length Width Depth 1.37 0.38 0.27 0.62 0.62 0.27...
- Page 2 Unpack the boxes and place all the parts on the ground. You will also have the pack with all the nuts and bolts in it. It would be great idea to label the hardware packs at the beginning. You can use the instructions to do this. NOTE: Do not tighten the nuts and bolts until the end, unless told otherwise.
- Page 3 Part #32 Part #20 Bolts #10 Connect parts #32 and #20 using #10 bolts and #62 washers from underneath. Part #20 Part #21 Bolts #10 Reinforcement plate #44 Then using #10 bolts and #44 reinforcement plate connect part #20 and #21 together.
- Page 4 Bolts #7 Part #32 Part #32 Part #21 Parts #32 can be attached to part #21 using bolts #7.
- Page 5 Part #19 Bolts #8 Reinforcement plate #45 Part #20 Using bolts #8 and a #45 reinforcement plate, you can connect parts #19 and #20.
- Page 6 Part #19 Bolts #8 Part #22 Part #36 You can now connect parts #36 and #22 using #8 bolts.
- Page 7 Bolts #7 Reinforcement plate #44 Part #21 Part #18 Part #18 needs to be connected to part #21 using #7 bolts and #44 reinforcement plate. Part #18 Bolts #10 Part #19 Reinforcement plate #44 It also needs to be bolted to part #19 using #10 bolts and #44 reinforcement plate. The reinforcement plate is placed underneath part #19.
- Page 8 Part #40 Part #25 Bolt #51 The seat #40 needs to be bolted onto part #25. This can be done using 2 x #51 bolts. Bolts #11 Part #27 Part #25 Both part #27 and #28 need to be bolted to the side of the part #25. You will need to use 2 #11 bolts each side for this.
- Page 9 Bolt #31 Part #25 Part #28 Part #28 gets bolted onto part #25 using bolt #31. It simply slides through the parts and needs nuts placed on each end. Bolt #31 Part #25 Part #28...
- Page 10 Bolts #6 Bolts #6 Part #28 Part #41 The back seat #41 can now be attached to #28 using #6 bolts.
- Page 11 Bolt #34 Parts #29 and #30 Bolt #31 Parts #29 and #30 need to be attached to #25. Using the same method as the step before, place the 2 steel rods #34 and #31 into position and push through.
- Page 12 Part #47 Part #23 Part #47 Part #23 The guide rails #23 need to be pushed through the wheels on the carriage. You may need another person to give you a hand doing this part. Before doing this, place part #47 onto each of the rails and pull to the top once the rails have been inserted.
- Page 13 Part #18 Part #48 Part #23 You may now place part #48 onto the guide rails #23 and insert the rails into the holes in part #18. Part #24 Bolts #9 You can lock the guide rails #23 into place using part #24 and bolt #9. They will also need to be bolted in at the bottom using bolt #9.
- Page 14 Holder for lever. Part #33 The locking lever #33 will need to be placed underneath the seat pad through the holder provided on the other side of the roller carriage. Be careful that the copper bushing does not fall out as this keeps it snug. It can then be tightened with a nut.
- Page 15 Part #35 Footplate Bolts #13 2 x #13bolts can be used to attached to part #35 footplate onto the main frame. Parts #37 and #38 Bolts #52 Using #52 bolts, parts #37 and #38 can be attached to the base and the footplate.
