- Page 1 Half Cassette wning Assembly Guide ALEKO® WWW.ALEKO.COM...
- Page 2 Half Cassette wning Assembly Guide For 10x8, 12x10, and 13x10 foot sizes. ALEKO®...
-
Page 3: Table Of Contents
· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 13 ALEKO®... -
Page 4: Introduction
Installation can be a simple, streamlined process if you follow the instructions in this manual. To accompany these written instructions, ALEKO has a YouTube channel with assembly and installation tutorials, demos, and more. Go to: www.youtube.com/AlekoProducts. -
Page 5: Parts Diagram
PARTS DIAGRAM... -
Page 6: Assemble The Fabric Roller
ASSEMBLY �� Assemble the fabric roller (A) • Insert fabric roller link (A-3) into fabric roller bar (A-2) and tap into place with a mallet. • Use 4 (A-A-1) screws to secure (A-3) in place. • Insert fabric roller link (A-3) into fabric roller bar (A-1) and tap into place with a mallet. •... -
Page 7: Assemble The Front Bar
ASSEMBLY �� Assemble the front bar (C) • Insert front bar link (C-3) into front bar (C-2) and tap into place with a mallet. • Use 4 (A-A-1) screws to secure (C-3) in place. • Insert front bar link (C-3) into front bar (C-1) and tap into place with a mallet. •... -
Page 8: Assemble To Torsion Bar
ASSEMBLY �� Assemble to torsion bar (B) • Insert torsion bar link (B-3) into torsion bar (B-2) and tap into place with a mallet. WARNING DO NOT REMOVE THE SAFETY SLEEVES THAT HOLD THE ARMS DOWN! • Use (B-B-1) screws to secure (B-3) in place. •... -
Page 9: Assemble The Fabric
ASSEMBLY �� Assemble the fabric. • Unfold canopy (M) and valance (O). • Thread two fabric liner (N) to both ends of (M) and (O); two people will make this much easier. • Once (N) has been threaded through both sides of (M), thread the back side of (M) and its liner through the slot in the assembled fabric roller (A) all the way to the end. -
Page 10: Assemble The Cassette
ASSEMBLY �� Assemble the Cassette (G). • Insert the completed roller with fabric into cassette (G-1); the end of roller end cap (F-1) will stick out of the end of (G-1). • Repeat step b with the other end of the completed roller into cassette (G-2). •... -
Page 11: Assemble The Roller Support
ASSEMBLY �� Assemble the Roller Support • Attach 1 unit of roller support (D) and gear box (D-3) to the end cap of cassette (H-1) and secure them in place with 2 pieces of bolt (W). • Attach 1 unit of roller support (D) and 1 unit of plastic bushing (E) to the end cap of cassette (H-2) and secure them in place with 2 units of bolt (Y). -
Page 12: Connect Arm Bar To The Assembled Front Bar
ASSEMBLY �� Connect Arm Bar to the Assembled Front Bar. • Before assembly, inspect the wrapping on the arm bar (L) and make sure the wrapping is intact. Arm bars are spring-loaded and can cause serious damage or injury during assembly. •... -
Page 13: Finish Assembly
ASSEMBLY �� Finish Assembly • Insert fabric lock (S) into both ends of assembled front bar (C) near the canopy fabric (M); tighten fabric locks with a Phillips head screwdriver. • Insert torsion bar cover (U) and front bar cover (R) onto each end of the assembled torsion bar (B) and assembled front bar (R), respectively. - Page 14 ALEKO Products 8307 S 192ND ST. KENT, WA 98032 SALES@ALEKOPRODUCTS.COM PHONE: +1 (888) 246-8596 ALEKO.COM YOUTUBE.COM/ALEKOPRODUCTS...
