- Page 1 Vision Text-Display-PLC XSystem Device Description XVC-100 Moeller GmbH! Hein-Moeller-Str. 7-11! D-53115 Bonn ! Germany Tel. +49(0) 228/602-0 Fax +49(0) 228/602-2433 www.moeller.net ! info@moeller.net For Immediate Delivery call KMParts.com at (866) 595-9616...
- Page 2 Moeller GmbH. Moeller GmbH does not accept any liability for damages arising from the use of any incorrect or incomplete information contained in this documentation or any information missing therefrom.
- Page 3 Proper use The device must only be used for the applications specified in the device description and only in conjunction with the components recommended by Moeller GmbH. Warning Trouble-free and safe operation of the product can only be ensured if the measures relating to proper transport, storage, assembly, installation and careful operation are strictly observed.
- Page 4 Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616...
-
Page 5: Table Of Contents
Maintenance and repair ..................47 Technical data ......................49 Disposal ........................53 EC Conformity......................53 Revision history ...................... 55 Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... - Page 6 XVC-100 Text Display PLC Device Description XVC-100 Contents Appendix, Font ......................57 Alphabetical index ....................59 Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616...
-
Page 7: Explanation Of Symbols
The “Information” pictogram has the following meaning: Indicates important and instructional information. Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... - Page 8 XVC-100 Text Display PLC Device Description XVC-100 Explanation of symbols Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616...
-
Page 9: Introduction
(" Section 3), unless otherwise stated. The designation and function of the connections and signals are the same for all versions. Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... - Page 10 XVC-100 Text Display PLC Device Description XVC-100 Introduction Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616...
-
Page 11: Device Versions
LCD mono 8X20 or 4X10 24 VDC characters can be selected via the software The following front plate versions are available: Standard front with Moeller membrane seal Front plate type 3.1 S PECIFICATIONS XVC-101-C192K-K82 Order No.: 264113 8 x 20/4 x 10 characters, 28 keys / 3 LEDs, retentive data 8KB Interface: 1 x CAN, 1 x RS232 I/O: 10 x DI 24VDC, 8 x DO 24VDC 0.5A, 8 x DIO selectable,... -
Page 12: Accessories
3.3 D ESIGNING XSoft-Professional XSoftProfessional (on CD) Consisting of: - XSoft -> IEC61131 software - Documentation in PDF format Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... -
Page 13: Features
55 pictures * 8 lines * 20 characters * 5 languages) Standard font see Appendix Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... -
Page 14: Utilisation Of The Can Identifier (Canopen)
Own node number + 96 Utilisation of the CAN node numbers (Node ID): Node ID (XVC-100) Function code Node ID (CiA) Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... -
Page 15: Commissioning
" Section 5.12 CompactFlash™ " Section 5.12 control LED 12-14 CompactFlash™ with protective cover and ejector " Section 5.11 Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... -
Page 16: Inserting The Battery
Unplug the power supply (the retentive data will be stored at least 2 minutes) Carefully remove the battery cover Insert battery Refit battery cover Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... -
Page 17: Connecting The Power Supply
If level 1 is undershot, the backlight is switched off. If level 2 is undershot, the PLC is switched off. Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... -
Page 18: Preparing The Shield Connections
The EMC values stated in the technical data can only be guaranteed if the cables are prepared according to the stated specifications. Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... -
Page 19: Connecting The Programming Interface - X7
“XSoft” system description or in the appropriate software documentation. Wiring of the null modem cable female female 9pole 25pole 25pole 9pole DCD/DSR Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... -
Page 20: Connection Of The Digital Input / Output - Connector X 1
The outputs can be used for switching inductive loads. An external free-wheeling circuit must be implemented for large inductances. (" Section 11). Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... -
Page 21: Connection Of The Digital Output - Connector X 2
The outputs can be used for switching inductive loads. An external free-wheeling circuit must be implemented for large inductances. (" Section11). Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... -
Page 22: Connection Of The Digital Input - Connector X 3
The debouncing of inputs is implemented via the software. This function must be activated if required. (see also Description of the function block libraries for XVC-100) Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... - Page 23 The connected incremental encoder must be provided with a push-pull interface! Counters and incremental encoder inputs must be shielded. Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616...
-
Page 24: Connection Of The Analog Input / Output - Connector X 4
Mean analog input values are automatically determined from the 8 most recent measured values. (arithmetic mean) Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... - Page 25 (20VDC). If only a range of 0 to 5VDC is used for example, the resolution is reduced to 10-bit. Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616...
-
Page 26: Connection Of The Can Interface - Connector X 6
The CAN connector is not provided with a supply for third-party devices. A detailed description of the wiring is provided in the “XSoft” system description Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... - Page 27 CAN bus. Do not swap around the two signal wires! Interface 1 Interface 2 Shield Protective ground Protective ground Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616...
- Page 28 Max. length 20kBit/sec 2500m 25kBit/sec 2000m 50kBit/sec 1000m 100kBit/sec 650m 125kBit/sec 500m 250kBit/sec 250m 500kBit/sec 100m 800kBit/sec 1000kBit/sec Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616...
-
Page 29: Inserting The Compactflash
Correct functioning can only be ensured by using CompactFlash™ cards obtained from the original accessories. Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... -
Page 30: Function And Control Leds
• Flashes at approx. 1 Hz # System menu active SYS control LED (green) CompactFlash control LED (red) Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... -
Page 31: Membrane Keyboard
PLC user program by means of appropriate function blocks. (see also Description of the function block libraries for XVC-100) Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... - Page 32 XVC-100 Text Display PLC Device Description XVC-100 Commissioning Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616...
-
Page 33: Operation
5V supply remains stable for at least 100ms. This is enough time for all the information required for the restart to be saved. Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... -
Page 34: Plc Operating States
The SF LED indicates a system fault. The following system faults can occur (" Section 9): • Hardware fault • System fault in firmware Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... -
Page 35: Changing Operating Mode
PLC. The PLC is reset to its basic setting. The XVC-100 does not support persistent tag variables. Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... -
Page 36: Startup Behaviour/Startup
Retain Data o.k. ? Reset-cold Start (OMS) OMS=STOP OMS=RUN PLC-Status: PLC-Status: PLC-Status: PLC-Status: Power on Stop System Fault Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... -
Page 37: Program Transfer
A program transfer from the PC to the CompactFlash™ in the PLC is in preparation. (see notes on Firmware) Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... -
Page 38: System Settings
Position 1 (RUN) or 2 (STOP) and press the ENTER key. • Fault messages are displayed instead of BSW XX.YY (" Section Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... - Page 39 Use the “◄►” keys to change the Baud rate • Press ENTER to exit the RS232 Settings menu without saving Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616...
- Page 40 (e.g. power failure). The saved PLC project is retained during a firmware update. Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616...
-
Page 41: Mounting Instructions
. Ensure that the seal is fitted correctly on the front panel. Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... -
Page 42: Mounting In The Front Panel
5 mm. The conter frame can be used for mounting in thin- walled front panels <= 2 mm. Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... -
Page 43: Front Cutout
198 +0/-1 mm x 142 +0/-1 mm The thickness of the front panel must not exceed 5 mm. Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... -
Page 44: Mechanical Dimensions
XVC-100 Text Display PLC Device Description XVC-100 Mounting instructions 7.4 M ECHANICAL DIMENSIONS Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... -
Page 45: Display, Backlight, Contrast
Flashes at approx. 1 Hz # System menu active Refer to the XSoft engineering software documentation for other diagnostics options. Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... - Page 46 XVC-100 Text Display PLC Device Description XVC-100 Display, backlight, contrast Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616...
-
Page 47: Maintenance And Repair
Repairs Repairs to the XVC-100 should only be carried out by the manufacturer or by Moeller GmbH repair centers. In this case, please contact your local XSystem dealer or the Technical Support at Moeller GmbH. (manufacturer's address " Section 13) No liability is accepted for any modifications made to the device that are not described in this document. - Page 48 XVC-100 Text Display PLC Device Description XVC-100 Maintenance and repair Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616...
-
Page 49: Technical Data
Connection Sub-D pole male Type CAN, not potential-free " Communication Section 5.10) interface Connection D-Subminiature 9-pole male Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... - Page 50 Input voltage -3...4.5VDC High 14...32.0VDC Input current 0..1mA High 2..15mA Max. input voltage 40VDC Protection against reverse polarity Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616...
- Page 51 2 per output (0V, voltage) Output voltage -10VDC...+10VDC Output current 1mA (10kΩ load) Resolution 12-bit Protected against short-circuit Potential isolation Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616...
- Page 52 XVC-100 Text Display PLC Device Description XVC-100 Technical data Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616...
-
Page 53: Disposal
The following standard was used to assess the electrical safety of the XVC-100: EN 60950-1 2002 Manufacturer: Moeller GmbH Manufacturer address: Hein-Moeller-Str. 7-11 D-53115 Bonn Germany Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... - Page 54 XVC-100 Text Display PLC Device Description XVC-100 Disposal Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616...
-
Page 55: Revision History
Initial Version for XVC-100 Moeller GmbH Hein-Moeller-Str. 7-11 D-53115 Bonn Germany +49(0) 228/602-0 +49(0) 228/602-2433 email automation@moeller.net homepage : www.moeller.net Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616... - Page 56 XVC-100 Text Display PLC Device Description XVC-100 Revision history Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616...
- Page 57 The characters from ASCII code 0x0e to 0x1f are special characters and cannot therefore be entered directly via the keyboard. Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616...
- Page 58 XVC-100 Text Display PLC Device Description XVC-100 Appendix Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616...
- Page 59 PLC-STOP 35 Operation 33 EC Conformity 53 Email 55 EMC 49 Emission 53 PLC 13 Exchangeable memory 13 Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616...
- Page 60 Setting of the serial interface 38 Shutdown behaviour 33 X 5 - Supply 17 Spare battery Start 36 Start messages 33 Subject to technical modifications Doc No. 92 23 100000 (06/2002) © by Moeller GmbH For Immediate Delivery call KMParts.com at (866) 595-9616...
