Agema AG6248C Instruction

Poe onie load

Instruction to load AG6248C-POE ONIE

NOTE: Please follow the steps carefully because you are going to erase and

overwrite NAND storage

Pre-install connectivity

1. Connect the console port of the switch to a PC. Most switches come

with a RJ45 console port. Use a RJ45-to-serial cable or an RJ45-to-

USB cable to connect to a PC.

2. Use a terminal application; such as "Tera Term" to terminal connect.

Configure the console port. Use these settings for the console port:

• 115200 baud

• No flow control

• 1 stop bit

• No parity bits

• 8 data bits

3- Connect MGMT port of the switch to the same segment as TFTP server

1. Uncompressed ONIE image that you have downloaded and place it on

TFTP server root

2. Install ONIE kernel ( 20160309-onie-agema_ag6248c-poe-r0.bin )

NOTE: Following directions assume the files are on the root of the TFTP

server with following ip and server name:

hostname: tftp-srv

TFTP IP : 192.168.1.5

Table of Contents

Do you have a question about the AG6248C and is the answer not in the manual?

Page 1 Instruction to load AG6248C-POE ONIE NOTE: Please follow the steps carefully because you are going to erase and overwrite NAND storage Pre-install connectivity 1. Connect the console port of the switch to a PC. Most switches come with a RJ45 console port. Use a RJ45-to-serial cable or an RJ45-to- USB cable to connect to a PC.
Page 2 3.Get into loader cli, run the following commands. Power up the switch. During power up press any key on the terminal to get loader CLI: agema_ag6248c-poe -> Follow these steps CAREFULLY: agema_ag6248c-poe -> setenv ipaddr 192.168.1.1 agema_ag6248c-poe -> setenv serverip 192.168.1.5 agema_ag6248c-poe -> tftp 20160309-onie-agema_ag6248c-poe-r0.bin && nand erase 0 0xa00000 && nand write $loadaddr 0 $filesize agema_ag6248c-poe -> nand read $loadaddr onie && nand write $loadaddr onie2 4.Power up the switch NOTE: During the first boot you will see few pages of debug data. This should take...
