Summary of Contents for TrackMan Portable
- Page 2 WELCOME TO TRACKMAN Congratulations on the purchase of your TrackMan Portable. This guide helps you set it up, and gets you up and running. Your battery is charged and ready to go, so you can start using your Track- Man right out of the box...
- Page 3 WHAT’S IN THE BOX · 1 TrackMan B1 · 1 Power supply with cable · 1 Micro USB service cable · 1 Protection foam · 1 Tripod mounting plate with 4 screws...
-
Page 4: Setup Requirements
SETUP REQUIREMENTS You need the following equipment: · Apple iPad running iOS 11 or later · For portable setup: * Tripod Quick-start Kit from TrackMan or your own Tripod equipment. See Appendix for requirements * Supported iPad models: iPad 4th/5th gen, 2017 model or later. -
Page 5: Connections & Indicators
CONNECTIONS & INDICATORS Primary Power plug-in Power button Wifi Battery Secondary Factory reset Micro USB Ethernet... - Page 6 GETTING STARTED...
- Page 7 ATTACHING THE COVER Ensure that the protection foam is attached properly.
- Page 8 Assemble tripod-head quick release plate to the bottom of backing plate · Fasten the tripod-head on the tripod. · Mount the TrackMan with the quick release plate on the tripod. Push the tripod-head lever to ensure it is fully locked.
- Page 10 TRACKMAN PLACEMENT Place the TrackMan anywhere in the marked area 6-12 ft behind home- plate. In a later step, the TrackMan Baseball iPad App will guide you for detailed placement instructions.
- Page 11 TURN ON THE POWER Turn on the power by pressing and holding the power button for one second. Wait until Wi-Fi symbol lights solid blue (this may take up to 30 seconds)
- Page 12 TrackMan Baseball App. · Install the App on your iPad: Use the link in the invitation email you received or search for “TrackMan Baseball” on the Apple App Store. · Login to the App with the account you created from the invitation email*...
- Page 13 USING THE TRACKMAN B1 · Open the TrackMan app, follow instructions to connect and calibrate your TrackMan and start a new prac- tice session. · Open a web browser and go to http://teamportal.trackmanbaseball. to manage your orgvanization, view reports and more.
- Page 14 APPENDIX...
- Page 15 BATTERY STATUS Charged Charging Not charging Full...
- Page 16 TRACKMAN B1 STATUS Ready Error Booting Updating...
- Page 17 TRIPOD REQUIREMENTS You may use your own Tripod equip- ment instead of the TrackMan Tripod Quick-start Kit. You’ll need: · An adjustable Tripod head with a 3/8” screw. Trackman recommends the Manfrotto MHXPRO-3WG XPRO Geared Head · A Tripod that meets these specs: - Min.
