VERITAS Flex 5150 Appliance Hardware Service Procedure

Veritas Appliance
Hardware Service Procedure
Replacing the storage disk drive: Veritas 5150 Appliance
Document Number: 291
Version: 1.1 (02-Dec-2019)

Purpose

This document describes the process for replacing the storage disk drives in a Veritas appliance.

Affected Models

The instructions that are provided in this document pertain to the following Veritas appliance hardware:
• 5150 Appliance

Electrical Safety

The static discharged by human bodies can damage static-sensitive components on the boards.
When installing and maintaining the equipment, observe appropriate electrostatic safety precautions
to prevent personnel injuries or device damage.
When operating a device in an electrostatic sensitive area, you must take electrostatic-discharge
(ESD)-preventive measures. These include wearing ESD-preventive gloves, an ESD-preventive wrist
strap, and ESD-preventive clothes to avoid personnel injury or device damage.
To prevent damage to the device, pay attention to the following during operations:
• Do not touch devices with bare hands because ESD from the human body may damage the
electrostatically sensitive elements on a board.
• When dealing with the server or any of the internal components, wear an ESD-preventive wrist
strap, ESD-preventive gloves, and ESD-preventive suit.

About removing and replacing a faulty storage disk drive

This document describes how to remove and replace a faulty storage disk drive from the chassis in
a Veritas appliance.
Slots 4 through 7 are noted in the following figures.
