- Page 1 ® SonicWall Switch 8-Port Series Quick Start Guide Regulatory Model Numbers: APL51-0E1 SWS12-8 APL52-0E2 SWS12-8POE...
- Page 2 Copyright © 2020 SonicWall Inc. All rights reserved. SonicWall is a trademark or registered trademark of SonicWall Inc. and/or its affiliates in the U.S.A. and/or other countries. All other trademarks and registered trademarks are property of their respective owners. The information in this document is provided in connection with SonicWall Inc. and/or its affiliates’ products. No license, express or implied, by estoppel or otherwise, to any intellectual property right is granted by this document or in connection with the sale of SonicWall products.
-
Page 3: Table Of Contents
SonicWall Support ............... . . 31 SonicWall Switch Quick Start Guide... - Page 4 SonicWall Switch Quick Start Guide...
-
Page 5: Introduction
Introduction Thank you for purchasing a SonicWall Switch. SonicWall Switches provide greater security and performance while enabling integrated security administration. This Quick Start Guide provides hardware information and multiple setup options for connecting your Switch and getting started with More details and complete instructions are available SWS12-8 online in the Switch Getting Started Guide. -
Page 6: Check The Package Contents
添付の電源 コ ー ド に関 し て 電気安全を確保する ために、 弊社製品にご使用いただ く 電源 コ ー ド は必ず 製品同梱の電源 コ ー ド を ご使用 く だ さ い。 こ の電源 コ ー ド は他の製品では使用で き ません。 SonicWall Switch Quick Start Guide... -
Page 7: Specifications
— 15.4 W Operating Temperature 0 — 40 0 — 40 Humidity (non-condensing) 5 — 95% 5 — 95% 1 Contact your SonicWall sales representative for information on available SonicWall SFP/SFP+ modules and cables: https://www.sonicwall.com/customers/contact-sales/ SonicWall Switch Quick Start Guide... -
Page 8: Hardware Interface
Hardware Interface SWS12-8 SWS12-8POE SonicWall Switch Quick Start Guide... - Page 9 Reset button: Press to reset the Switch to current Optional connector allows connection to ground settings. Press for 10 seconds to enter Recovery Mode. Note: Returns Switch to default configuration. RJ45 LAN Ports: 10/100/1000 Mbps RJ45 LAN ports SonicWall Switch Quick Start Guide...
- Page 10 SonicWall Switch Quick Start Guide...
-
Page 11: Installing The Switch
To install the Switch on a flat surface such as a desktop or shelf, attach the rubber feet on the bottom at each corner of the Switch. The rubber feet cushion the Switch from shock or vibration, and secure space between devices when stacking to allow ventilation. SonicWall Switch Quick Start Guide... -
Page 12: Installing On A Wall
Tools and parts for wall mounting: • Screwdriver • Drill with appropriate size bit • Two #6 pan-head wood or machine screws, 1 inch long (7mm diameter head, 25mm long) • Two wall anchors if mounting on drywall SonicWall Switch Quick Start Guide... - Page 13 To mount the appliance on the wall: 1 Drill two holes in positions that correspond to the slots on bottom side of SonicWall Switch. 2 If using wall anchors, insert a wall anchor into each hole. 3 Insert a screw into each wall anchor (into each hole if not using wall anchors), leaving 3/16 inches (0.45 cm) on the screws exposed (including screw head).
- Page 14 SonicWall Switch Quick Start Guide...
-
Page 15: Managing The Switch
Managing the Switch This section covers configuration of the Switch through a SonicWall firewall, or, through the SonicWall Switch. • Firewall Managed • Standalone SonicWall Switch Quick Start Guide... -
Page 16: Firewall Managed
Firewall Managed Zero-Touch Switch setup is available when connecting your Switch to a SonicWall firewall running SonicOS 6.5.4.6 or higher. To prepare the Firewall: 1 Configure the firewall interface where the Switch will be connected with a static IP address. - Page 17 192.168.2.1 SonicWall Switch Quick Start Guide...
- Page 18 2 Click on the Advanced tab shown below and then select Enable Auto-Discovery of SonicWall Switches. This will automatically add DHCP scope under the configured interface. SonicWall Switch Quick Start Guide...
- Page 19 3 After the Switch boots, verify that the Link/Act LED indicates a good cable connection. After the new Switch boots, it gets the DHCP lease from the firewall interface. 4 In SonicOS, navigate to Switch Controller > Dashboard of and click on Authorize. SonicWall Switch Quick Start Guide...
- Page 20 5 Navigate to the Switch Controller > Switch and verify that the firewall Switch Controller GUI shows the Switch status as green and online: For detailed instructions, go to https://www.sonicwall.com/support/technical-documentation/ to access the Switch Getting Started Guide. ?category=Switch SonicWall Switch Quick Start Guide...
-
Page 21: Standalone
To clear this address, disconnect the Switch from the LAN and press the Reset Button (see feature 7 in Hardware Interface on page 8) for 10 seconds to restore the default IP address. SonicWall Switch Quick Start Guide... - Page 22 SonicWall Switch Quick Start Guide...
-
Page 23: Safety And Regulatory
Install in a location away from direct sunlight and sources of heat. A maximum ambient temperature of 104º F (40º C) is recommended. Route cables away from power lines, fluorescent lighting fixtures, and sources of noise such as radios, transmitters, and broadband amplifiers. SonicWall Switch Quick Start Guide... - Page 24 Cable Connections All Ethernet and RS232 (Console) cables are designed for intra-building connection to other equipment. Do not connect these ports directly to communication wiring or other wiring that exits the building where the SonicWall appliance is located. Power Supply Information...
- Page 25 8-Port PoE Switch (SWS12-8POE) If the power supply is missing from your SonicWall product package, please contact SonicWall Technical Support at https:// www.sonicwall.com/support/contact-support for a replacement. This product should only be used with a UL listed power supply marked “I.T.E. LPS” with an output rated 54V DC, minimum 1.2 A, Tma: minimum 40 degree C.
- Page 26 SonicWall. Informations sur l’alimentation Électrique 8-Port Switch (SWS12-8) Si le bloc d'alimentation ne se trouve pas dans l'emballage de votre produit SonicWall, veuillez communiquer avec l'assistance technique de SonicWall au https://www.sonicwall.com/support/contact-support pour obtenir un remplacement. Ce produit ne doit être utilisé...
- Page 27 Alle Ethernet- und RS232-C-Kabel eignen sich für die Verbindung von Geräten in Innenräumen. Schließen Sie an die Anschlüsse der SonicWall keine Kabel an, die aus dem Gebäude herausgeführt werden, in dem sich das Gerät befindet. SonicWall Switch Quick Start Guide...
- Page 28 Logo "I.T.E. LPS" und einer Ausgangsleistung von 54VDC, mind. 1.2 A, Tma: mind. 40 Grad C, betrieben werden. EU and EFTA Declarations of Conformity A “Declaration of Conformity” in accordance with the directives and standards has been made and is on file at SonicWall International Limited, City Gate Park, Mahon, Cork, Ireland.
- Page 29 Warranty Information All SonicWall appliances come with a 1-year Limited Hardware Warranty which provides delivery of critical replacement parts for defective parts under warranty. Visit the Warranty Information page for details on your product’s warranty at https:// www.sonicwall.com/support. SonicWall Switch Quick Start Guide...
- Page 30 SonicWall Switch Quick Start Guide...
-
Page 31: Sonicwall Support
SonicWall Support Technical support is available to customers who have purchased SonicWall products with a valid maintenance contract and to customers who have trial versions. The Support Portal provides self-help tools you can use to solve problems quickly and independently, 24 hours a day, 365 days a year. - Page 32 SonicWall Switch Quick Start Guide February 2020 232-005203-50 Rev A...
