- Page 1 ® SonicWall Switch 10-Port / 24-Port / 48-Port Series Quick Start Guide Regulatory Model Numbers: 1RK43-0E3 SWS12-10FPOE 1RK44-0E4 SWS14-24 1RK45-0E5 SWS14-24FPOE 1RK46-0E6 SWS14-48 1RK47-0E7 SWS14-48FPOE...
- Page 2 Copyright © 2020 SonicWall Inc. All rights reserved. SonicWall is a trademark or registered trademark of SonicWall Inc. and/or its affiliates in the U.S.A. and/or other countries. All other trademarks and registered trademarks are property of their respective owners. The information in this document is provided in connection with SonicWall Inc. and/or its affiliates’ products. No license, express or implied, by estoppel or otherwise, to any intellectual property right is granted by this document or in connection with the sale of SonicWall products.
-
Page 3: Table Of Contents
SonicWall Support ............... . . 35 SonicWall Switch Quick Start Guide... - Page 4 SonicWall Switch Quick Start Guide...
-
Page 5: Introduction
Introduction Thank you for purchasing a SonicWall Switch. SonicWall Switches provide greater security and performance while enabling integrated security administration. This Quick Start Guide provides hardware information and multiple setup options for connecting your Switch and getting started with SWS12-10FPOE... -
Page 6: Check The Package Contents
添付の電源 コ ー ド に関 し て 電気安全を確保する ために、 弊社製品にご使用いただ く 電源 コ ー ド は必ず 製品同梱の電源 コ ー ド を ご使用 く だ さ い。 こ の電源 コ ー ド は他の製品では使用で き ません。 SonicWall Switch Quick Start Guide... -
Page 7: Specifications
0 — 40 (non-condensing) Humidity 5 — 95% 5 — 95% 5 — 95% 5 — 95% 5 — 95% 1.Contact your SonicWall sales representative for information on available SonicWall SFP/SFP+ modules and cables: https://www.sonicwall.com/customers/contact-sales/ SonicWall Switch Quick Start Guide... -
Page 8: Hardware Interface - 10-Port Switch
Hardware Interface — 10-Port Switch SWS12-10FPOE SonicWall Switch Quick Start Guide... - Page 9 SFP Speed (per SFP port): Off = No traffic; Green = 1 Lit = PoE mode on Gbps LAN/PoE Mode Selector: Press to change between SFP Ports: 1 Gbps ports LAN and PoE LED display modes. Refer to feature 9. AC Power Port SonicWall Switch Quick Start Guide...
-
Page 10: Hardware Interface - 24-Port Switches
Hardware Interface — 24-Port Switches SWS14-24 13 14 SWS14-24FPOE 13 14 3 4 5 SonicWall Switch Quick Start Guide... - Page 11 Press to change between SFP+ Link/Act LED (per SFP+ port): Off = No link; LAN and PoE LED display modes. Refer to feature 10. Green = active link; Blinking = packet transfer in process AC Power Port SonicWall Switch Quick Start Guide...
-
Page 12: Hardware Interface - 48-Port Switches
Hardware Interface — 48-Port Switches SWS14-48 SWS14-48FPOE SonicWall Switch Quick Start Guide... - Page 13 Press to change between SFP+ Link/Act LED (per SFP+ port): Off = No link; LAN and PoE LED display modes. See feature 10. Green = active link; Blinking = packet transfer in process AC Power Port SonicWall Switch Quick Start Guide...
- Page 14 SonicWall Switch Quick Start Guide...
-
Page 15: Installing The Switch
To mount the Switch in a rack, attach the included rack mounting brackets to the Switch. Then connect the Switch to the rack, securing the mounting brackets to the rack. The Switch can be mounted in an EIA standard 19-inch rack, which can be placed in a wiring closet with other equipment. SonicWall Switch Quick Start Guide... - Page 16 SonicWall Switch Quick Start Guide...
-
Page 17: Managing The Switch
Managing the Switch This section covers configuration of the Switch through a SonicWall firewall, or, through the SonicWall Switch. • Firewall Managed • Standalone SonicWall Switch Quick Start Guide... -
Page 18: Firewall Managed
Firewall Managed Zero-Touch Switch setup is available when connecting your Switch to a SonicWall firewall running SonicOS 6.5.4.6 or higher. To prepare the firewall: 1 Configure the firewall interface where the Switch will be connected with a static IP address. - Page 19 192.168.2.1 SonicWall Switch Quick Start Guide...
- Page 20 2 Click on the Advanced tab shown below and then select Enable Auto-Discovery of SonicWall Switches. This will automatically add DHCP scope under the configured interface. SonicWall Switch Quick Start Guide...
- Page 21 3 After the Switch boots, verify that the Link/Act LED indicates a good cable connection. After the new Switch boots, it gets the DHCP lease from the firewall interface. 4 In SonicOS, navigate to Switch Controller > Dashboard of and click on Authorize. SonicWall Switch Quick Start Guide...
- Page 22 5 Navigate to the Switch Controller > Switch and verify that the firewall Switch Controller GUI shows the Switch status as green and online: For detailed instructions, go to https://www.sonicwall.com/support/technical-documentation/ to access the Switch Getting Started Guide. ?category=Switch SonicWall Switch Quick Start Guide...
-
Page 23: Standalone
Use the procedure below to find that IP address. To access the Switch through the console port 1 Connect a console cable from the configuring computer to the switch port marked Console. SonicWall Switch Quick Start Guide... - Page 24 4 Enter show ip interface and the Switch will respond with the address of the GUI for local setup. Connect the Switch to your network. For detailed instructions, go to https://www.sonicwall.com/support/ to access the Switch Getting Started Guide. technical-documentation/?category=Switch SonicWall Switch Quick Start Guide...
-
Page 25: Safety And Regulatory
The following conditions are required for proper installation. The SonicWall appliance is designed to be mounted in a standard 19-inch rack mount cabinet. Use the mounting hardware recommended by the rack manufacturer and ensure that the rack is adequate for the application. - Page 26 Therefore, consideration should be given to installing the equipment in an environment compatible with the maximum recommended ambient temperature. Mount the SonicWall appliances evenly in the rack in order to prevent a hazardous condition caused by uneven mechanical loading.
- Page 27 All Ethernet and RS232 (Console) cables are designed for intra-building connection to other equipment. Do not connect these ports directly to communication wiring or other wiring that exits the building where the SonicWall appliance is located. Anforderungen an die Installation WARNUNG: Für eine ordnungsgemäße Montage sollten die folgenden...
- Page 28 Temperatur in der Gehäuse höher sein als die Umgebungstemperatur. Achten Sie darauf, daß die Umgebungstemperatur nicht mehr als 40° C beträgt. Bringen Sie die SonicWall waagerecht im Rack an, um mögliche Gefahren durch ungleiche mechanische Belastung zu vermeiden. Verwenden Sie für eine sichere Montage vier passende Befestigungsschrauben, und ziehen Sie diese mit der Hand an.
- Page 29 Kabelverbindungen Alle Ethernet- und RS232-C-Kabel eignen sich für die Verbindung von Geräten in Innenräumen. Schließen Sie an die Anschlüsse der SonicWall keine Kabel an, die aus dem Gebäude herausgeführt werden, in dem sich das Gerät befindet. Exigences Relatives à l'installation AVERTISSEMENT: Les conditions suivantes sont requises pour une installation correcte.
- Page 30 à la température ambiante maximale recommandée. Montez les appareils SonicWall de manière égale dans la baie afin d'empêcher toute situation dangereuse due à un chargement mécanique inégal. Quatre vis de montage compatibles avec la conception de la baie doivent être utilisées et serrées à la main pour garantir une installation sécuritaire.
- Page 31 à des câbles de communication ou à d'autres câbles qui sortent du bâtiment dans lequel se trouve l'appareil SonicWall. 安裝要求 警告 : 需要滿足以下條件以進行正確安裝。 SonicWall 設備被設計成安裝在一個標準的 19 吋機架安裝櫃。 使用機架製造商推薦的裝載硬體，確認機架足夠裝置所需。 請確認裝置內不會滲入水分或過多的濕氣。 裝置週邊請保持通風，特別是裝置通風口側。建議裝置與牆壁間至少要有 1 英吋 (25.44 公釐 ) 的淨空。 纜線的路徑應遠離電源線、日光燈，以及會產生雜訊的來源，如無線電、發送器與寬頻放大器。 架設位置需遠離陽光直射與熱源。建議周圍溫度最高溫不 要超過 104°F (40°C)。 SonicWall Switch Quick Start Guide...
- Page 32 10 應當提供一個合適額定值並且已被認可的分支電路斷路器作為安裝該裝置的一部分。在購買材料或部件 時，應遵循當地安全代碼。 11 必須留心裝置與電源電路的連接問題，電路過載對過電流保護與電路電線的影響需降至最低。解決這個問 題時，需正確考慮裝置銘牌額定值。不要過載電路。 12 必須維護可靠的機架裝載設備接地。必須特別留意電源供應器連線，而不是直接連接到電源板之類的分支 電路。 13 隨附的電源線僅限於特定的國家或地區使用。使用前，請確認電源線的額定值且已被認可在你的地區上使 用。 14 當使用光纖小封裝熱插拔 (Small-Form Pluggable, SFP) 模組時，請確認該模組通過 IEC 60825 認證 並且為 Class 1 產品。 纜線連結 所有乙太網路與 RS232 ( 主控台 ) 線路都是為與其他裝置進行內建連接所設計的。請不要將這些連接 埠直接連接至通訊線路，或其他連出 SonicWall 裝置所在建築的線路。 SonicWall Switch Quick Start Guide...
- Page 33 Note 2：“ ” indicates that the percentage content of the restricted substance does not exceed the percentage of reference value of presence. 備考3.〝—〞係指該項限用物質為排除項目。 Note 3：The “—” indicates that the restricted substance corresponds to the exemption. SonicWall Switch Quick Start Guide...
- Page 34 Declaration of Conformity A “Declaration of Conformity” in accordance with the directives and standards has been made and is on file at SonicWall International Limited, City Gate Park, Mahon, Cork, Ireland. CE declarations can be found online at https://www.sonicwall.com/support. NOTE: Additional regulatory notifications and information for this product can be found online at https://www.sonicwall.com/support.
-
Page 35: Sonicwall Support
SonicWall Support Technical support is available to customers who have purchased SonicWall products with a valid maintenance contract and to customers who have trial versions. The Support Portal provides self-help tools you can use to solve problems quickly and independently, 24 hours a day, 365 days a year. - Page 36 SonicWall Switch Quick Start Guide February 2020 232-005204-50 Rev A...
