- Page 1 GROUND GROUND - (610-624) Interrati elettromeccanici ISTRUZIONI PER L’INSTALLAZIONE Electromechanical underground INSTRUCTIONS FOR INSTALLATIONS...
- Page 2 GROUND Ø 5 x4 GROUND 610 - 230Vac GROUND 610 - 230Vac cavo marrone / brown cable apertura / opening DESCRIZIONE CAVI / CABLES DETAILS Marrone / Brown Apertura / Opening cavo grigio / grey cable Grigio / Grey Nero / Black Chiusura / Closing cavo nero / black cable chiusura / closing...
- Page 3 GROUND 415 m m 345 m m 440 m m 360m m 72 mm 72 mm 72 mm 9 7 9 5 AJ00720 AJ00730 AJ00740 AJ00770...
- Page 4 GROUND 90° 72 mm...
- Page 5 GROUND Esterno / External AJ00730 AJ00720 90°/135° Interno / Internal Esterno / External AJ00720 AJ00730 90° Interno / Internal...
- Page 6 GROUND Esterno / External 90° 135° 135° 90° 135° Interno / Internal 9 14 Esterno / External 90° 90° Interno / Internal L=LEFT sinistra R=RIGHT destra...
- Page 7 GROUND cavo rosso / red cable + 24 Vdc cavo marrone / brown cable M3 x 6mm cavo viola / purple cable FCA (OPEN) cavo blu / blue cable FCC (CLOSE) DESCRIZIONE CAVI / CABLES DETAILS Blu / Blue Chiude / Close Viola / Purple Apre / Open Rosso / Red...
- Page 8 GROUND...
-
Page 9: Installation Warnings
• Exclusively use original spare parts for any maintenance or repair operations. • Do not modify any components of the automated device unless expressly authorised by Gi.Bi.Di. Use suitable cable clamps to assure proper mechanical connection of the wiring and such as to maintain the IP degree of protection. -
Page 10: Technical Data
GROUND ELECTRICAL LAYOUT (1a - 1b) 1- Underground motor GROUND610 power cable 4 x 1 mm²: grey= motor common; brown= opening; black= closing; yellow/green= ground. Underground motor GROUND624 2 x 1,5 mm² cable power supply: RED = + BLACK = - for a cable length of 6 m max., over it’s necessary increase the cable section. -
Page 11: Installation
GROUND • Check that the area where the gearmotor will be fitted is not exposed to flooding. • If the gate is not a new installation, check the state of wear of all the components, repair or replace the defective or worn parts and perform any other operations necessary. -
Page 12: Fitting The Gate
GROUND - Embed the operator box in the foundation hole. FITTING THE GATE N.B. Check that the cement in the foundation hole has dried sufficiently before installing the operator. 1- Fit the lever unit to the box pin (10) AJ00720 - AJ00730 (14). 2- Procure a U-bracket of the dimensions indicated in (11) and close it on the pillar side using a plate as shown in (12/a) and (12/b). -
Page 13: Manual Operation
GROUND 8- Fit the deceleration and opening and closing limit switch enable magnets in the desired position. In any case, always refer to the control unit instructions for handling the limit switches. There are several seats on the limit switches in which to position the magnets spaced out 5°, which is equivalent to a circumference arc of 250/300 mm on a 2.5 m long leaf. -
Page 14: Final Testing
Periodically check proper adjustment of the electronic anti-crushing safety device and the efficiency of the unlocking device for manual operation (see the relevant paragraph). The safety devices installed on the system must be checked every six months. Gi.Bi.Di. Srl reserves the right to change the technical data without prior notice in relation to product development. - Page 15 GROUND CE Declaration of conformity The manufacturer: GI.BI.DI. S.r.l. Via Abetone Brennero, 177/B, 46025 Poggio Rusco (MN) ITALY Declares that the products: ELECTROMECHANICAL GEARMOTOR GROUND 610 - 624 Are in conformity with the following CEE Directives: Directive 2006/95/CE and subsequent amendments;...
-
