- Page 1 Operating instructions BEAUTY ANGEL RVT 28 1010978-0 / us / 0 .201...
- Page 2 Contact information Contact information Technical Service JK-Global Service A Div of JK Products & Services, Inc. #1 Walter Kratz Drive Jonesboro, AR 72401 800-445-0624 870-935-9046 e-mail: support@jkamerica.com http://support.jkamerica.com WARNING! Read these operating instructions. Failure to observe these instructions: • may result in serious injury and death, •...
-
Page 3: Table Of Contents
Table of contents Table of contents General...................5 Definitions ..................5 Identify your device .................5 Safety notices................6 Description of warning signs ............6 Instructions pertaining to a risk of fire, electric shock, or injury ..7 2.2.1 Beauty device..................7 2.2.2 VibraShape (Vibration plate) ............8 Instructions pertaining to a risk of damage to the machine ... - Page 4 Cleaning or replacing interior lighting ..........35 Technical data ................36 Power rating, electrical specifications and noise level....36 Dimensions..................37 Lamp configuration................38 7.3.1 BEAUTY ANGEL RVT 28..............38 7.3.2 Accent lighting ................39 Spare parts and accessories............39 JK-Products, Inc. – Limited Warranty........40 Limited Acrylic Warranty..............41 Warranty Claims................41...
-
Page 5: General
General General Definitions Operator Person who provides the devices described here to users on a commercial basis. The operator is responsible for the correct operation of the device as well as compliance with the maintenance intervals. User A person who uses the device at a commercial location. Staff People who are responsible for the operation, cleaning as well as general maintenance work and who instruct the users in the operation of the devices. -
Page 6: Safety Notices
Safety notices Safety notices Description of warning signs Danger notices, damage to persons: DANGER! Type and source of danger, e.g. 'DANGER – High volt- age!' Description of the consequences, e.g. 'You can be killed or injured by an electric shock!' Countermeasures: –... -
Page 7: Instructions Pertaining To A Risk Of Fire, Electric Shock, Or Injury
Safety notices Instructions pertaining to a risk of fire, electric shock, or injury 2.2.1 Beauty device DANGER – HIGH VOLTAGE! You can be killed or injured by an electric shock! Assembly and electrical connection must comply with na- tional and local regulations. –... -
Page 8: Vibrashape (Vibration Plate)
Safety notices WARNING! Infections can be transferred through skin contact! All items/equipment components, with which the user can come into contact during the application, must be disinfected after every application: – Protective goggles – Acrylic panels – Holding bars and control panel –... - Page 9 Safety notices WARNING! Risk of damage to health! Vibrations can lead to or intensify health problems. You should only use the vibration plate after consulting your doctor when you suffer from one of the following health restrictions: – Cardiovascular diseases –...
-
Page 10: Instructions Pertaining To A Risk Of Damage To The Machine
Safety notices Instructions pertaining to a risk of damage to the machine CAUTION! Danger of overheating by obstruction of the air routing! – Do not change, obstruct or block the air inflow and outflow area to the device or make any unauthorized changes to the device. -
Page 11: Information For The Studio Operator
Information for the studio operator Information for the studio operator Intended use Beauty device This device is intended to temporarily firm and tone the appearance of the muscles and the body. The device may only be used by one person at a time. VibraShape function The vibration plate can be used additionally during the light application. -
Page 12: Staff Training
Information for the studio operator Staff training As the operator you are obligated to train your personnel and instruct them in the established legal and accident prevention regulations. Ensure that your staff have understood and observe these instructions. This includes: information regarding intended use and foreseeable misuse safety instructions operating instructions... -
Page 13: Mp3 Music
Information for the studio operator MP3 music The personal use of an MP3 player during the application is not a public broadcast in copyright terms, so that there is no obligation for registration or payment by the studio owner to the corresponding copyright owning com- pany. -
Page 14: Description
Description Description Scope of delivery BEAUTY ANGEL RVT 28 device Beauty Light lamps VibraShape Fan (Body cooling) Trim, including loudspeaker and cockpit control Interior lighting Sound system MP3 cable Allen-key Connecting lead Suction cup for acrylic panels Protective goggles Technical documentation (folder with instructions, CD-ROM and addi- tional documentation) 4.1.1... -
Page 15: Device Description
Description Device description 1. Base plate 2. Floor mat and vibration plate (VibraShape) 3. Operating panel 4. Holding bars 5. Headphone connection, jack plug Ø 6.3 mm 6. MP3 connection, jack plug Ø 3.5 mm 7. Fan (body cooling) 8. Loudspeaker 9. -
Page 16: Accessories (Optional)
Description Accessories (optional) 1. Central air outlet system VibraShape You may choose from four (4) different programs, each offering varying levels of targeted muscle stimulation, exercise and massage intensity. The body immediately responds to the patented, pre-programmed movement of the platform. -
Page 17: Description: Vibration Programs
Description Description: vibration programs Program Duration Description 10 Minutes Wellness (low intensity): Loosens and relaxes mus- cles, improves flexibility, and enhances well-being with gentle movements at low vibration frequency. 10 Minutes New You: For beginners and ideal for those starting a fitness regimen. -
Page 18: Operation
Operation Operation Mandatory reading Always read and follow all instructions for proper usage prior to allowing any- one to use the device. The operating instructions included with this device must always be followed to prevent possible injuries. Inform users – to use provided protective eyewear whenever the equipment is ener- gized. -
Page 19: Application Tips
Operation Application tips Behavior before, during and after a light application: No other persons are permitted in the vicinity of the cabin when using the device, this especially applies to children. Remove all jewelry (including piercings) prior to the application. Remove cosmetics before using the device and do not use sun screen products. - Page 20 Operation VibraShape WARNING! Risk of injury! The vibration function is not suitable for all users. – Please observe the contraindications on page 8. NOTE: Each program starts with a warm-up phase and ends with a cooling-down phase. A vibration program normally lasts for 10 minutes.
-
Page 21: Operation Overview
Operation Operation overview 1. START/STOP button 2. Down navigation arrow button 3. Minus button 4. Display – Functions … 5. VibraShape LED 6. Body cooling pictogram 7. Volume pictogram 8. Audio system pictogram 9. Up navigation arrow button 10. Plus button 1010978-01 Operating instructions –... -
Page 22: Navigation
Operation 5.3.1 Navigation The device is operated with the navigation ring. Switch on lamps: Press the button once. Switch off lamps/interrupt application: Hold the button. Select device function (go to pictogram) e.g. VOLUME Select sub-function (if available) Change setting The LEDs of the available functions and the navigation ring are illuminated in default mode after starting up the device. -
Page 23: Functions
Operation Functions Function Button sequence Description Information 1. Lamps START/STOP If the lamps are switched off during the Switch lamps on/off during the application, the application time continues application (in combination with to run. VibraShape: See below). 5. VibraShape Select VibraShape (the LED at the top) Tap the button once: START/STOP also switches off the lamps. -
Page 24: Start
Operation Start The device is started automatically with an internal or external timer. NOTE: Timer instructions see separate manual (order no. 1008370-..). 5.5.1 Preparation time Before the Beauty Light lamps turn on, you have a few minutes to prepare yourself. During the preparation time you can switch on the lamps at any time by pressing the START/STOP button. -
Page 25: Connect Mp3 Player
Operation Connect MP3 player DANGER! Danger of hearing damage! Using earphones or headphones at high volume can result in permanent hearing damage. – Do not set the volume too high. The user can connect their own private MP3 player to the device. 1. -
Page 26: Cleaning And Maintenance
Cleaning and maintenance Cleaning and maintenance Safety instructions for cleaning and maintenance DANGER – HIGH VOLTAGE! You can be killed or injured by an electric shock! During maintenance work there is a risk of touching live parts and receiving a fatal electric shock. –... -
Page 27: Faults
Cleaning and maintenance WARNING! Danger of burns from hot lamps and device parts! If the device was operated before being switched off and opened, lamps and housing parts may be hot. – Before replacing lamps or other spare parts, wait until lamps and metal parts of the device have cooled down sufficiently. -
Page 28: Cleaning
Cleaning and maintenance Cleaning WARNING! Infections can be transferred through skin contact! All items/equipment components, with which the user can come into contact during the application, must be disinfected after every application: – Protective goggles – Acrylic panels – Holding bars and control panel –... -
Page 29: Lamps
Cleaning and maintenance During cleaning a slight discoloration of the leather cloth by the rubber seals should be expected for production-related reasons. Prevent damage to the acrylic and plastic surfaces. – Remove rings, watches, bracelets etc. before starting cleaning work. 6.3.3 Lamps The lamps can be cleaned with a damp cloth and without additional cleaning... -
Page 30: Maintenance
Cleaning and maintenance Component Interval Activity See page Entry area Cleaning and disinfection Floor mat (Plastic) Cleaning and disinfection Control panel Cleaning and disinfection Holding bars Cleaning and disinfection Protective goggles Cleaning and disinfection MP3 cable Cleaning and disinfection Cleaning and disinfection Acrylic panels Cleaning and disinfection Surfaces... - Page 31 Cleaning and maintenance Component Interval Activity See page a Beauty Light lamps, right side Replace b Beauty Light lamps, left side Replace c Low pressure lamp Replace d Cooling fan fasteners Inspect Bolts and fasteners of the door Inspect hinge mechanism Bolts and fasteners of the door Replace as necessary hinge mechanism...
-
Page 32: Instructions For Replacing The Lamps
Cleaning and maintenance Instructions for replacing the lamps The lamps effectiveness decreases over the course of time. As such, the replacement intervals specified in the maintenance plan must be adhered to. 6.7.1 Low pressure lamps Replace faulty lamps immediately. Always replace the entire set of lamps after the specified operating time. –... -
Page 33: Cleaning Or Replacing The Lamps On The Left
Cleaning and maintenance Cleaning or replacing the lamps on the left CAUTION! Acrylic panels unusable due to soiling! Soiling on the panels is burned in by the hot lamps and in the longterm results in unserviceable panels. – Remove fingerprints and other soiling carefully. –... -
Page 34: Cleaning Or Replacing The Lamps On The Right
Cleaning and maintenance The assembly is the same process in reverse order. When assembling please note: – Insert the holding bar at the bottom with the hexagon in the recess of the holding device and align. DANGER! Danger of crushing fingers when folding the clamping strip! Fingers can be crushed when folding the clamping strip. -
Page 35: Cleaning Or Replacing Interior Lighting
Cleaning and maintenance – Loosen the screws and then remove the lamp cover. Replacing the lamps: see page 32. The assembly is the same process in reverse order. DANGER! Danger of crushing fingers when folding the clamping strip! Fingers can be crushed when folding the clamping strip. –... -
Page 36: Technical Data
Technical data Technical data Power rating, electrical specifications and noise level BEAUTY ANGEL RVT 28 Nominal power consumption (without exhaust air): 4,500 W Nominal power consumption (with exhaust air): 4,750 W Rated frequency: 60 Hz Rated voltage: 230 V Rated fuses:... -
Page 37: Dimensions
Technical data Dimensions 42 15/16 in 1090 mm B1 = 27 9/16 in 700 mm 53 1/8 in 1350 mm B2 = B3 = 24 7/16 in 620 mm 43 5/16 in 1100 mm T1 = 27 9/16 in 700 mm T2 = 43 5/16 in 1100 mm... -
Page 38: Lamp Configuration
Technical data Lamp configuration CAUTION! Use of non-compliant lamps voids warranty and risks injury! 7.3.1 BEAUTY ANGEL RVT 28 Installed lamps Number Description Length Power Control Order-no. Low pressure lamps 79 in 180 W 180 W 3031109501 Beauty Light 180W FR2.0M-T12-RL-180W... -
Page 39: Accent Lighting
Technical data 7.3.2 Accent lighting Number Description Power Order-no. Low pressure lamp 36 W 12969-.. Spare parts and accessories Number Description Order-no. Acrylic panels 0041110201 Protective goggles 1007934-.. MP3 cable 4630911001 Allen-key 83828-.. 1010978-01 Operating instructions – 39 02/2012... -
Page 40: Jk-Products, Inc. - Limited Warranty
JK-Products, Inc. – Limited Warranty JK-Products, Inc. – Limited Warranty JK-Products, Inc. warrants its products to be free from defects in materials and workmanship under intended normal use as described in the unit's Op- eration and Instruction Manual, for a period of one (1) year from date of sale. This Limited Warranty applies only to the original purchaser of the equipment through JK-Products, Inc. -
Page 41: Limited Acrylic Warranty
JK-Products, Inc. – Limited Warranty Limited Acrylic Warranty JK Products, Inc. warrants its acrylic sheets to be free from defects in material and workmanship, under intended normal use, for a period of one (1) year from date of sale of the appliance. Due to the tanning lotions, cosmetics, disinfectants and improper cleaners used on acrylic surfaces that cannot be controlled by JK Products, Inc., after the first thirty (30) days of warranty pe- riod acrylic will be subject to a prorated cost to the consumer. -
Page 42: Labor Warranty Claim/Credit Procedures
JK-Products, Inc. – Limited Warranty 2. Where to call to place a Warranty Claim: JK-Products, Inc. is supported nationwide by an extensive dealer/distributor network through whom the majority of our units are sold. These deal- ers/distributors are required by contract to stock sufficient parts to meet the various warranty and nonwarranty needs of their customers. - Page 43 JK-Products, Inc. – Limited Warranty NOTE: Components are warranted on an individual basis and not as they may effect the complete product. Warranty coverage does not include cosmetic abnormalities such as scratches, nicks, dents, rust, oxidation of paint or other cosmetic changes that do not interfere with the designed function of the unit.
-
Page 44: Appendix
Appendix Appendix Signs and stickers on the device Signs which warn of danger areas are attached to the device. The signs shown below are examples. Ensure that the instruction signs are always clearly recognizable and easily legible. Any missing instruction signs or stick- ers must be replaced. - Page 45 Appendix 2: Application times 1010978-01 Operating instructions – 45 02/2012...
- Page 46 Appendix 3: USA mains connection sticker (1009684-..) The sticker is located behind the trim. 4: Lamp cover sticker (801139-..) 801139-01-...
- Page 47 Appendix 5: Nameplate 6: Module plate 7: Warning sticker (1010503-..) 1010978-01 Operating instructions – 47 02/2012...
-
Page 48: Index
Index Index Accent lighting......39 Fault codes....... 27 Accessories......16, 39 Faults ........27 Acrylic glass (maintenance) ..28 Foreseeable misuse....11 Adolescents......7, 11 Functions........23 Assembly........7 Injury .......... 7 Base plate Installed lamps ......38 Permitted load ....36 Instruction signs ....... - Page 49 Index Recycling ........13 Technical Service......2 Replace the Beauty Light Transport........12 lamps ........32 Treatment........17 Replacing interior lamp ..........35 Risk of injury.......18 Ventilation .........12 VibraShape Description ......17 Vibration plate ......17 Safety notices ......7 Scope of delivery ......14 Setup.........12 Warning signs, description..6 Sickness........7, 9 Warranty ........40 Spare parts ......30, 39 Staff..........5...
- Page 50 Index...
