CAE LearningSpace Setup Manual

Server-based system
Hide thumbs
Table of Contents

Advertisement

Quick Links

CAELearningSpace
Server-Based System Setup Guide
905K463452 (267r)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LearningSpace and is the answer not in the manual?

Questions and answers

Summary of Contents for CAE LearningSpace

  • Page 1 CAELearningSpace Server-Based System Setup Guide 905K463452 (267r)
  • Page 2 Server-Based System Setup Guide Copyright © CAE Healthcare Academy 2019. All rights reserved. No part of this document may be reproduced without written consent from CAE Healthcare Academy. 905K463452 (267r)
  • Page 3 Dear Valued Customer, Congratulations, and thank you for your recent purchase of the CAE LearningSpace Connect Server system. This guide will help you get started using CAE LearningSpace. In addition, a CAE LearningSpace user guide is available from within the CAE LearningSpace web software.

  • Page 4: Table Of Contents

    CAELearningSpace Server-Based System Setup Guide Welcome to CAE LearningSpace! This guide will help you get started using CAE LearningSpace - intelligent recording, easy debriefing. It will explain how to get your system started. 1.0 Equipment Setup (Server-Based) ................5 2.0 Initial Network Setup ....................7 2.1 To configure your server as a MASTER Connect Server: ........

  • Page 5: Equipment Setup (Server-Based)

    CAE LearningSpace 1.0 Equipment Setup (Server-Based) Upon receipt of your CAE LearningSpace Connect Server, remove the equipment from the packaging and set it up. 1.1 Unpack the server. IMPORTANT: The slave and master Connect Servers are identical with respect to hardware component configuration.
  • Page 6 Server-Based System Setup Guide 1.2. Connect one end of an Ethernet cable to the institution network and the other end to Port 1. Port 1 Port 2 (A/V network) Port 1 and Port 2 on the Connect Server (back) NOTE: The default client access port is Port 1, which is dedicated to the institution network.

  • Page 7: Initial Network Setup

    CAE LearningSpace 2.0 Initial Network Setup This section will walk you through how to configure your CAE LearningSpace Connect Server as a MASTER Connect Server (see 2.1) • SLAVE Connect Server (see 2.2) • and helps you set up your server network connection and create the initial login: 2.1 To configure your server as a MASTER Connect Server:...
  • Page 8 IMPORTANT: All fields marked with an asterisk (*) are required. 2.1.5 When you are finished with editing, click Save Settings. 2.1.6 Once you have configured the MASTER Connect Server, click the Continue to LearningSpace button or enter learning.space in the browser. 905K463452 (267r)

  • Page 9: To Configure Your Server As A Slave Connect Server

    IMPORTANT: All fields marked with an asterisk (*) are required. 2.2.3 When you are finished with editing, click Save Settings. 2.2.4 Once you have configured the SLAVE Connect Server, click the Continue to LearningSpace button or enter learning.space in the browser. 905K463452 (267r)

  • Page 10: Note About Continuing After Network Setup

    In case the license of the software was already activated (see 3.0), the Continue to LearningSpace button or the learning.space URL directs you to the Initial Settings tab (see 4.3 in 4.0), where you are required to provide the Admin login credentials (password and email) and location.

  • Page 11: Licensing

    CAE LearningSpace 3.0 Licensing Following the network setup, the purchased CAE LearningSpace software can be activated online (3.2.1) by connecting to the Internet or offline (3.2.2) − if the internet connection was not detected successfully − by contacting the CAE support team.
  • Page 12 Completed online licensing 3.2.2 Offline activation IMPORTANT: Please have the serial number ready to identify your unit. Call CAE LearningSpace support to receive your Activation Code. Enter the activation code in the designated field of the offline licensing page. Offline licensing page...

  • Page 13: Initial System Setup

    Once the licensing is successfully concluded, the Login button is displayed. Activation success message and login button 4.1 Click Login, and you will land on the login page: LearningSpace login fields 4.2 Logging in for the first time, enter the default email address and password: email: admin@learning.space password : mls#changeme You will be redirected to the Initial Settings tab.
  • Page 14 Server-Based System Setup Guide NOTE: Passwords have to meet a minimum requirement to ensure the security of your user accounts. The new password has to be 8 characters or longer and has to include at least one of each of the following characters: lower case letters, upper case letters, numbers, and special characters/symbols.

  • Page 15: Connecting Simulators

    5.1.4 Go to System → Simulators, select the Controls cogwheel on the left panel (under Wireless Bridges) and select the wireless network of the simulator. In case the CAE simulator is not listed when trying to connect to the WiFi network: i.

  • Page 16: Connecting Cae Simulators Using A Wired Connection

    Simulators tab in System 5.1.5 Connect to the selected CAE simulator. 5.1.6 The CAE simulator will show up within 10-30 seconds on the right-side panel. 5.1.7 After adding the simulator using the icon, you can add the simulator to the desired room, using the Rooms tab.

  • Page 17: Connecting Third-Party (Non-Cae) Simulators

    A/V network connection CAE Simulator Bridge and ports Make sure to use a LAN port on the CAE Simulator Bridge to connect to the switch. The LAN ports of the CAE Simulator Bridge are dedicated to the A/V network. 5.2.3 Connect your simulator with an Ethernet cable to the WAN port of the CAE Simulator Bridge.
  • Page 18 CAE DCU’s frame grabber: NOTE: The CAE DCU’s frame grabber has a DVI input. a. Use a VGA to DVI video cable to capture signals from non-CAE simulators with VGA output. b. Use a DVI to DVI video cable to capture signals from non-CAE simulators with DVI output.
  • Page 19 CAE LearningSpace CAELearningSpace caehealthcare.com For more information about CAE Healthcare products, contact your regional sales manager Healthcare distributor your country visit caehealthcare.com. Tel +1 941-377-5562 or 866-233-6384 For customer service, please contact CAE Healthcare. United States Monday - Friday from 7:00 a.m. to 6:00 p.m.
