- Page 1 OPERATING MANUAL SCOOTER, Control panel with LCD- display W e m o v e p e o p l e .
-
Page 2: Table Of Contents
Contents Introduction ....................3 Specifi cations/ utilisation ................3 Use ........................3 Adjustment ......................3 Overview ....................... 4 Keyboard ......................4 LCD-Display ......................4 Pre-operation checks ..................5 Battery charge condition ................6 Battery gauge .......................6 Battery-symbols ....................6 Evaluation ......................7 Pre-selectable maximum speed ................8 Keys and symbols .................. -
Page 3: Introduction
INTRODUCTION SPECIFICATIONS/ UTILI- SATION The SCOOTER is steered through the control panel. ☞ Note: The control panel is an inherent part Please note that the options and of the SCOOTER and gives the user im- accessories are not a part of the portant information through the LCD- standard scope of supply! display before and during the ride. -
Page 4: Overview
OVERVIEW 1 LCD-Display 2 Light sensor 3 Control panel 4 Control panel housing Keyboard 5 Right indicator ON/OFF 6 Horn key 7 Hazard warning signal ON/OFF 8 Lighting ON/OFF 9 Horn key 10 Left indicator ON/OFF 11 Right indicator ON/OFF 12 Driving direction reverse for- ward/backward 13 Preselection walking speed ON/... -
Page 5: Pre-Operation Checks
PRE-OPERATION CHECKS After switching the scooter on the electronic runs through a system test. ☞ Note: During the system test the logo < MEYRA ORTOPEDIA > appears and the director may not be acti- vated. The electronic is ready when the dis- play is completed [1]. -
Page 6: Battery Charge Condition
BATTERY CHARGE CON- DITION Battery gauge The battery gauge shows the battery symbol with changing degree of the fi lling status of the battery charge condition. Battery-symbols (1) fully charged (complete charge) – maximum driving range can be achieved under optimal condi- tions. -
Page 7: Evaluation
Evaluation The display of the battery charging condition is tuned to the discharge characteristics of the batteries sup- plied by us. Other types of batteries or batteries from other manufactur- ers can show other characteristics and therefore decrease the exactness of the display. -
Page 8: Pre-Selectable Maximum Speed
Pre-selectable maximum speed The maximum speed is adjusted con- tinuously through the turning knob (1). With increasing clockwise turn of the knob the maximum speed is adjusted accordingly from slow to the model specifi c maximum speed. Attention: Danger of accidents due to inad- equate limitation of the maximum speed! Select a lower maximum speed for... -
Page 9: Keys And Symbols
KEYS AND SYMBOLS ☞ With the driving key extracted or when switched off (driving key po- sition 0) the button key < Warning signal > (3) blinks every 10 seconds and thus signal the activated anti- theft function. Automatic switch-off period The scooter features an automatic switch-off period. -
Page 10: Position Of Driving Key 2
Position of driving key 2 ☞ Also observe the operating manual < Scooter >! The driving key is inserted at a 90° an- gle in the driving lock (2). ☞ The drive mode is activated. – The LCD-display shows the operational status (1). - Page 11 Right indicator Switches the turn signal on or off when the < Right turn signal > key is pressed. ☞ The symbol for the right turn sig- nal blinks in the LCD-display. ☞ Note: A defective turn signal bulb is in- dicated by a higher blinking fre- quency of the right turn signal symbol.
- Page 12 Hazard warning signal Switches the warning signal on or off when the < Warning signal > key is pressed. ☞ Both symbols – turn signal and warning signal appear in the LCD- display and blink from slightly red to bright red. ☞...
- Page 13 Travel direction reversing ☞ Note: Only in combination with the optional directors < Gas turning knob > or < Foot gas >. Switches the driving direction from forward motion to backward motion when the key is depressed < Reverse driving direction > . ☞...
- Page 14 Preselection of walking speed Switches the walking speed on or off when the key < Preselection walking speed > is pressed. ☞ The LCD-display shows the symbol – walking speed. < Preselection walking speed > enables a targeted activa- tion of a permitted maximum speed for driving on pedestrian walkways or shopping zones.
- Page 15 Economical speed Switches the speed control (only in forward driving direction) on or off when the < Economical speed > key is pressed. Attention: Only use the speed control on clearly laid out routes. Activation: After reaching the desired speed, acti- vate the speed control by pressing the <...
-
Page 16: Daily Kilometre Counter
Daily kilometre counter During stillstand of the scooter the daily kilometres will be displayed in- stead of the speed gauge (1). ☞ The daily kilometre gauge can be reset on demand. Resetting daily kilometre gauge In order to reset the daily kilometre counter to <... -
Page 17: User Menu
USER MENU User menu Language The following menus can be selected through the user menu: Code key Language Clock Code key Audible warning Clock Backlight Light sensor Audible warning Backlight Light sensor User menu Language Basic setting Code key The delivery condition includes the following functions/settings: Clock Audible warning... - Page 18 User menu Menu selection Enter / Language Confi rm Code key Clock With the < Lighting > key the sub- menu is selected. Audible warning After confi rming the corresponding Backlight parameters by pressing the < Light- Light sensor ing > key the selection is stored. At the same time you switch into the next higher menu.
-
Page 19: Language
☞ Language The warning signal can be switched on or off. The menu < Language > offers a se- lection of several languages for the menu guide. Back-lighting The Back-lighting for the keys and the Code key display of the control panel can be ac- tivated when the lighting is switched The code lock can be activated against unpermitted use of the scooter. -
Page 20: Menu Structure
Menu structure: User menu Language Language Code key Clock Audible warning Backlight Light sensor User menu Code key Language enable Code key disable Clock Audible warning Code Backlight 0 0 0 0 Light sensor = Plus User menu Language = Minus . - Page 21 Menu structure: User menu Clock Language Code key Clock adjust Audible warning Clock Backlight 00 00 Light sensor User menu = Plus Language Code key = Minus Clock Audible warning Clock Backlight 00 00 Light sensor User menu Language Audible warning Code key Clock While indicator on...
- Page 22 Menu structure: User menu Backlight Language 100 % Code key 75 % Clock 50 % Audible warning 25 % Backlight on / off Light sensor on / off User menu Language Code key Clock Audible warning Backlight Light sensor User menu Language Code key Clock...
-
Page 23: Service
SERVICE ERROR LIST Error code display Repairs Trustingly contact your specialist deal- er for maintenance work. He has been The director was moved out of the introduces to the maintenance at has zero position too early. educated personnel. Malfunction help Switch the Scooter off and on again if Service this happens. - Page 24 Your specialist dealer: MEYRA-ORTOPEDIA Vertriebsgesellschaft mbH Meyra-Ring 2 · D-32689 Kalletal-Kalldorf P.O. Box 1 703 • D-32591 Vlotho Fon +49 (0)5733 922-355 Fax +49 (0)5733 922-9355 info@meyra-ortopedia.de W e m o v e p e o p l e .
