- Page 1 GILLÖGA HIGH CHAIR...
- Page 2 ＠ ● The figures in the instruction are to illustrate the right operation and product structure.When there is a small difference between the real and the picture, pls refer to real one. ● In order to improve the quality of products. We may have improved the quality without Informing you in advance.
- Page 3 ＠ Assembly ＠ ＠ Step 1: Insert left and right foot tube(L.R) into chair body separately according to arrow direction. Step 2: Insert front and rear foot tube(A.B) into foot tube support. ( A:front foot tube. B: rear foot tube) WARNING: Make sure the shrapnel of the foot tube is completely locked tube support before next operation.
- Page 4 ＠ Opening of Chair stand Press the button on both sides, open front and rear tube to maximum 1. Loose the button,Try to fold two foot tubes and confirm they are locked. Then pull the chair upward to highest position 2. Make sure the whole chair is in stable state.
- Page 5 ＠ Foot pedal installation As shown by the arrow, put the foot pedal set into chair body square hole. ＠ ＠ ( pic 2) ＠...
- Page 6 ＠ Foot pedal angle adjustment Press the round adjustable button on both pedal sides. Rotate the pedal up and down with the button as axis. Pedal can be adjusted with three positions. press three position adjustable button ＠ ＠ ( pic 3) ＠...
-
Page 7: Pedal Height Adjustment
＠ Pedal height adjustment Hold the height adjusting button in 3 holes of pedal two sides, Push the lower part of the foot pedal downwards, make it locked in the lower hole, This is lowering the pedal.. Otherwise, push the pedal upwards to make it lock in above holes. - Page 8 ＠ Tray assembly instruction Put tray directly to the both armrest of main body and press bilateral button under the tray. The tray has three optional position, can be moved forward or backward. ＠ ＠ ( pic 5) ＠...
- Page 9 ＠ Tray removed instruction 1、Press bilateral button under the tray, and pull it out. ＠ ＠ 2、To fix the removed tray, hooking the tray on the back of legs as the arrow direction in figure 6. ( pic 6) ＠...
-
Page 10: Chair Height Adjustment
＠ Chair height adjustment Lift the up and down button at the backrest to adjust needful position of chair body. WARNING: Prohibit to adjust up and down when child in the chair to avoid any injury! use hand pull ＠ ＠... -
Page 11: Backrest Angle
＠ Backrest angle adjustment when the backrest is in perpendicular state, It is only WARNING: suitable for child who are 6 months old. use hand pull ＠ ＠ Pull the adjusting button at the back of backrest and force on front and back direction. -
Page 12: Safety Harness
＠ Safety harness WARNING: Must always use the restraint system! Harness using Release all the buckles on the restraint, place the baby in the seat and bring the safety strap up between baby’s legs and the harness over the baby’s shoulders. Fasten each buckle and pull the straps to tighten until comfortable. - Page 13 ＠ Folding and unfolding instruction 1、Press the lift button at the backrest and adjust the seat to the lowest position① 2、Press the bilateral folded buttons and close the front and rear legs together②( figure 10) 3、Hook the tray on the back legs before folding the high chair③...
- Page 14 ＠ Parts Adjustable button for backrest angel Adjustable button for backrest height Cushion fixed hook Fold button Tray hook ＠ ＠ Shrapnel Hind foot tube Brake ( pic 11) ＠...
- Page 15 ＠ Parts ● Use soft cloth to clean the smudge. ● Please clean the chair, dry the water when not use it, and store in a dry, cool environment. ● Please maintain in time when shrapnel , screw loose or lost. Cushion Five point safety harness Tray...
