  • Page 1 GLUING SOLUTIONS ANNEX TO INSTRUCTIONS MANUAL INTEGRATED PATTERN CONTROLLER STARBI BI Software v97 MA-5188-GBR 040320...
  • Page 2 The specifications and information contained in this manual may be modified without prior notice. This manual is a translation of the original that was written by Focke Meler Gluing Solutions, S. A. in spanish language. If there is any discrepancy between the different versions of this manual, the original written in the spanish language shall prevail.
  • Page 3 INDEX MA-5188-GBR ANNEX INTEGRATED PATTERN CONTROLLER STARBI INDEX 1. SAFETY GUIDELINES General Symbols Mechanical components Electrical components Hydraulic components Pneumatic components Thermal components Materials Noise emission declaration Intended use Limited use 2. INTRODUCTION Description Intended use Basic terminology Mods of operation...
  • Page 4 FOCKE MELER GLUING SOLUTIONS INDEX 3. INSTALLATION Installation requirements Electrical consumption Input and output signals Voltage activation time (PWM) Connection of the peripheral components (StarBi 2 Outputs) Electrical installation of Micron systems Location of the peripheral components Photocell Encoder Pressure regulator 4. UTILIZATION...
  • Page 5 INDEX MA-5188-GBR ANNEX INTEGRATED PATTERN CONTROLLER STARBI Main menu. Accessing the integrated StarBi. Screen navigation. User menu General characteristics Navigation icons Save changes Interpretation of the screens Description of screens Password management 4-29 External communication 4-33 5. MANTENANCE General Outside cleaning...
  • Page 6 FOCKE MELER GLUING SOLUTIONS INDEX This page is intentionally left blank.

  • Page 7: Safety Guidelines

    SAFETY GUIDELINES MA-5188-GBR ANNEX INTEGRATED PATTERN CONTROLLER STARBI 1. SAFETY GUIDELINES General The information contained in this section applies not only to everyday equipment operation, but also to any procedure carried out on it, whether for preventive maintenance or in the case of repairs and the replacement of worn out parts.

  • Page 8: Mechanical Components

    FOCKE MELER GLUING SOLUTIONS SAFETY GUIDELINES Mechanical components The hot-melt installation, which is installed to this device, requires moving parts that can cause damage. Use the equipment correctly, and do not remove the safety guards while the equipment is in operation; prevent the risk of possible entrapment due to moving mechanical parts.

  • Page 9: Thermal Components

    Safety Information Sheet of the adhesive. Materials Meler systems are designed for use with hot-melt adhesives. They should not be used with any other type of material, and especially not with solvents, which may cause personal injury or damage to internal system components.

  • Page 10: Intended Use

    Note: Do not modify the equipment or use components that were not supplied by Meler. For any modification of a component of the equipment or part of the installation, you must firstly consult the After-Sales Service...
  • Page 11 ANNEX INTEGRATED PATTERN CONTROLLER STARBI 2. INTRODUCTION Description Focke Meler’s StarBi pattern controller is a control system for the dispensing and positioning of hot-melt or vinyl glue (cold glue) adhesives in gluing applications. This device has a place in any market related to industrial gluing with hot- melt or cold glue, such as labelling machines, box folding machines, wood lamination, bookbinding…...

  • Page 12: Basic Terminology

    FOCKE MELER GLUING SOLUTIONS INTRODUCTION Basic terminology Some of the terms used in the instruction manual are described below: Channel: pair of homologous outputs through which the activation signals are transmitted to the applicator. Cycle: period of time that includes the process of applying a product or substrate from the start to the end of it.

  • Page 13: Controller Identification

    INTRODUCTION MA-5188-GBR ANNEX INTEGRATED PATTERN CONTROLLER STARBI Mods of operation The pattern controller has two modes of operation: Manual mode: to enable purging, cleaning or depressurising of the installation or for checking the correct operation of the applicators. The selected outputs are activated by actuating the corresponding button.

  • Page 14: Main Components

    FOCKE MELER GLUING SOLUTIONS INTRODUCTION Main components 1. Touchscreen 2. Central light LEDs. 3. RED LED, unit in STOPPED mode. 4. Button to stop or turn on the program (STOPPED to RUNNING/RUNNING to STOPPED). 5. GREEN LED unit turned on.
  • Page 15 ANNEX INTEGRATED PATTERN CONTROLLER STARBI Componentes adicionales a la instalación Applicators All Focke Meler applicators controlled by 24 VDC solenoid valves (limited by the output power) can be connected. For other devices, consult the Central Office or your nearest Distributor.
  • Page 16 FOCKE MELER GLUING SOLUTIONS INTRODUCTION Pressure regulator It is connected to the 0-10 V output (output without isolation) and is used when a pneumatic supply pressure control is required: - For the application pump (in the case of piston pumping units)

  • Page 17: Installation Requirements

    Warning: This manual specifies the installation requirements for the StarBi pattern controller. For information about the installation of other devices, please consult the corresponding Micron+ manuals.
  • Page 18 To install input and output signals, please see the manual for your specific melter. With the pattern controller enabled, the system displays a new input signal (Firing OFF). This function inhibits the pattern controller. The other signals are common to both systems (melter and StarBi pattern controller). Signal Type...
  • Page 19 INSTALLATION MA-5188-GBR ANNEX INTEGRATED PATTERN CONTROLLER STARBI Connection of the peripheral components (StarBi 2 Outputs) To connect the peripherals in the unit, it is necessary to pass the cable through the corresponding PG cable gland and connect it to the appropriate terminal.
  • Page 20 FOCKE MELER GLUING SOLUTIONS INSTALLATION Electrical installation of Micron systems There are three installation options for the StarBi depending on the unit into which it will be integrated. Identify the unit when locating and handling the board. 1. MICRON WITH PISTON PUMP: In the Micron piston pump unit, the board is on the opening side panel of the electric cabinet.
  • Page 21 To use another type of photocell or presence of substrate sensor, consult your Focke Meler representative or the Focke Meler Main Office. Encoder The positioning and length of the lines of application and their precision,...
  • Page 22 (max. 10 bar), through a built-in filter of 5 µ. The VP-200 has a display that shows the existing pressure at any given moment. To connect other types of devices, consult your Focke Meler Representative or the Focke Meler Main Office.
  • Page 23 This section explains how to use the pattern controller. Although its operation is very user-friendly, it should not be used by untrained personnel. Warning: This manual specifies the functions of the integrated StarBi pattern controller. For more information about using the melter, please see the corresponding manual.
  • Page 24 Extra settings Sound on alarm FOCKE MELER GLUING SOLUTIONS UTILIZATION Screen saver Inside device temperature alarm Change from RUNNING mode to STOPPED mode 85 ºC 60 s 1. With the ‘Autolock Pump / Shooting’ function enabled: GRADO v97 Autolock Pump / Shooting In STOPPED mode the STOP button’s RED LED stays lit.

  • Page 25: Low Speed

    UTILIZATION MA-5188-GBR ANNEX INTEGRATED PATTERN CONTROLLER STARBI Temperature OK (Ready) An internal signal is sent from the melter to the pattern controller, indicating that the adhesive is at the set temperature to start production. The pattern control will never activate the channel outputs (solenoid valves) if the temperature is not ‘OK’...
  • Page 26 FOCKE MELER GLUING SOLUTIONS UTILIZATION Melter/StarBi common functions Certain functions are common to both systems and can be controlled and set up via the melter menus. This applies to the following functions: • Language settings. • Date and time settings.
  • Page 27 : svn97 Extra settings Sound on alarm UTILIZATION MA-5188-GBR ANNEX INTEGRATED PATTERN CONTROLLER STARBI Screen saver Inside device temperature alarm ‘Autolock pump / Shooting’ enabled 85 ºC 60 s When it is enabled, every time an event forces the unit to change to STOPPED mode, automatic shot blocking is enabled and the STOP button’s red LED...
  • Page 28 FOCKE MELER GLUING SOLUTIONS UTILIZATION Main menu. The main functions of the melter and the user settings for the pattern controller can be accessed via the main menu of the melter. Certain functions are common and can be accessed via this screen, such as language settings, date and time settings, alarms, and calendars.
  • Page 29 UTILIZATION MA-5188-GBR ANNEX INTEGRATED PATTERN CONTROLLER STARBI Accessing the integrated StarBi. The pattern controller function is accessed by pressing the circular icon on the screen. RADO v97 STARBI INTEGRADO v97 Warning: For detailed information about using the melter, please refer to the Use section of the corresponding manual.
  • Page 30 FOCKE MELER GLUING SOLUTIONS UTILIZATION ENGRANE v1.0.106 Save changes v1.0.084 v1.0.106 v1.0.106 2.2 Extra Settings The ‘SAVE CHANGES’ icon, located in the upper right part of the screen, appears in the data entry and programming screens. If the data shown on the Sound on alarm screen is stored, the icon appears with a blue background.
  • Page 31 UTILIZATION MA-5188-GBR ANNEX INTEGRATED PATTERN CONTROLLER STARBI Description of screens 1. HOME screen. TARBI INTEGRADO v97 This is the start screen. When it starts, the system displays this screen with the main data of the device. : S02001100 v1.0.106 : S02200100 v1.0.084 : S02102100 v1.0.106...
  • Page 32 FOCKE MELER GLUING SOLUTIONS UTILIZATION STARBI INTEGRADO v97 : S02001100 v1.0.106 2. MENU screen. : S02200100 v1.0.084 : S02102100 v1.0.106 : svn97 Shooting menu Product Installation Manual mode Settings Statistics Alarms 3. INSTALLATION screen. ARBI INTEGRADO v97 STARBI INTEGRADO v97 To work with products by distances, it is necessary to determine an installation before starting.
  • Page 33 UTILIZATION MA-5188-GBR ANNEX INTEGRATED PATTERN CONTROLLER STARBI 4. NEW INSTALLATION screen. ARBI INTEGRADO v97 STARBI INTEGRADO v97 After selecting NEW INSTALLATION a screen will open to enter the name; then go to the EDIT INSTALLATION screen. : S02001100 v1.0.106 : S02001100 v1.0.106 : S02200100 v1.0.084...
  • Page 34 FOCKE MELER GLUING SOLUTIONS UTILIZATION 6. EDIT SELECTED INSTALLATION screen. 6 tabs appear, one for each channel (EV). Each tab allows you to edit the STARBI INTEGRADO v97 distance between the applicator of that channel and each photocell. It also : S02001100 v1.0.106...
  • Page 35 UTILIZATION MA-5188-GBR ANNEX INTEGRATED PATTERN CONTROLLER STARBI 8. ENCODER screen. INTEGRADO v97 STARBI INTEGRADO v97 There are 3 options to configure the encoder and only one of them can be 00 v1.0.106 : S02001100 v1.0.106 active. 00 v1.0.084 : S02200100 v1.0.084 00 v1.0.106...
  • Page 36 FOCKE MELER GLUING SOLUTIONS UTILIZATION 9. ANALOGUE INPUT screen. The following screen will appear where you can configure a ramp with 5 dots, defining the conversion between input voltage and line speed. The maximum input voltage cannot exceed 10 V.
  • Page 37 UTILIZATION MA-5188-GBR ANNEX INTEGRATED PATTERN CONTROLLER STARBI 10. COPY INSTALLATION screen. Select the installation to copy. A confirmation message will appear and then a EGRADO v97 STARBI INTEGRADO v97 screen will open to enter the name of the new installation.
  • Page 38 FOCKE MELER GLUING SOLUTIONS UTILIZATION 12. PRODUCT screen. TEGRADO v97 STARBI INTEGRADO v97 It is selected from the MENU screen. .0.106 : S02001100 v1.0.106 .0.084 : S02200100 v1.0.084 .0.106 : S02102100 v1.0.106 : svn97 Shooting menu Product Edit product Product...
  • Page 39 UTILIZATION MA-5188-GBR ANNEX INTEGRATED PATTERN CONTROLLER STARBI 14. NEW PRODUCT screen. It is selected from the PRODUCT screen. Once the type of product is selected, NTEGRADO v97 STARBI INTEGRADO v97 an editing screen is opened depending on the type of product chosen.
  • Page 40 FOCKE MELER GLUING SOLUTIONS UTILIZATION 16. COPY PRODUCT screen. It is selected from the PRODUCT screen. A confirmation message will appear EGRADO v97 STARBI INTEGRADO v97 and then a screen will open to enter the name of the new product.
  • Page 41 STARBI.v97 UTILIZATION MA-5188-GBR ANNEX INTEGRATED PATTERN CONTROLLER STARBI New product 18. EDITING PRODUCT BY TIME screen. The screen appears when you name a new product from the NEW PRODUCT Time product Distance product screen or if you select an existing one from the EDIT PRODUCT screen. The...
  • Page 42 RBI.v97 FOCKE MELER GLUING SOLUTIONS UTILIZATION New product 20. ADVANCED PARAMETERS screen. Time product Distance product INTEGRADO v97 Other parameters can be configured in addition to the patterns. The keyboard opens when pressing on the text boxes. After entering the value it will be 0 v1.0.106...
  • Page 43 New product UTILIZATION MA-5188-GBR ANNEX INTEGRATED PATTERN CONTROLLER STARBI Time product Distance product 22. ADVANCED PARAMETERS screen. Other parameters can be configured in addition to the patterns. The keyboard INTEGRADO v97 Variable time product Variable distance opens when pressing on the text boxes. After entering the value it will be product 00 v1.0.106...
  • Page 44 Time product Distance product FOCKE MELER GLUING SOLUTIONS UTILIZATION Variable time product Variable distance product 24. ADVANCED PARAMETERS screen. Other parameters can be configured in addition to the patterns. The keyboard Repetitive time product Repetitive distance INTEGRADO v97 opens when pressing on the text boxes. After entering the value it will be product 0 v1.0.106...
  • Page 45 STARBI.v97 UTILIZATION MA-5188-GBR ANNEX INTEGRATED PATTERN CONTROLLER STARBI New product 26. ADVANCED PARAMETERS screen. These parameters are configured in the same way as the products by times Time product Distance product but with values in millimetres (mm). The analogue outputs are configured in...
  • Page 46 New product FOCKE MELER GLUING SOLUTIONS UTILIZATION Time product Distance product 28. ADVANCED PARAMETERS screen. These parameters are configured in the same way as the products by times but with RADO v97 STARBI INTEGRADO v97 Variable time product Variable distance values in millimetres (mm).
  • Page 47 Time product Distance product UTILIZATION MA-5188-GBR ANNEX INTEGRATED PATTERN CONTROLLER STARBI Variable time product Variable distance product 30. ADVANCED OPTIONS screen. These parameters are configured in the same way as the products by times Repetitive time product Repetitive distance but with values in millimetres (mm). The analogue outputs are configured in...
  • Page 48 FOCKE MELER GLUING SOLUTIONS UTILIZATION 32. MANUAL MODE screen. Here each of the outputs can be activated and deactivated manually. This TEGRADO v97 mode enables purging, cleaning or depressurising the installation, or 1.0.106 checking the correct operation of the applicators.
  • Page 49 UTILIZATION MA-5188-GBR ANNEX INTEGRATED PATTERN CONTROLLER STARBI 34. Selection of CONFIGURATION screen. It is selected from the MENU screen. Melter MENU. MICRON+ PISTÓN MICRON+ PISTÓN EGRADO v97 The general settings are accessed via the MENU. These settings apply to the : S02001100 v1.0.106...
  • Page 50 FOCKE MELER GLUING SOLUTIONS UTILIZATION 36. DATE AND TIME screen. From Main menu the ‘Date and Time’ menu can be accessed directly. The ARBI INTEGRADO v97 STARBI INTEGRADO v97 following screen will appear where you can see and modify the date and time of the system.

  • Page 51: Locked Mode

    ****** New password Repeat new password ****** A -Block or unblock direct access to the StarBi pattern controller function. Shooting menu locked When this function is disabled, a password is required whenever the user wants to access the controller. Password management LOCKED MODE: Access is only provided to the HOME screen.
  • Page 52 FOCKE MELER GLUING SOLUTIONS UTILIZATION 38. ADVANCED SETTINGS screen. STARBI INTEGRADO v97 STARBI.v97 Allows you to change other options. : S02001100 v1.0.106 : S02200100 v1.0.084 : S02102100 v1.0.106 : svn97 Configuration Settings PWM in time 24V 10 ms. Password Extra settings Restore default •...
  • Page 53 UTILIZATION MA-5188-GBR ANNEX INTEGRATED PATTERN CONTROLLER STARBI 40. Selection of STATISTICS screen. It is selected from the MENU screen. it shows the total amount of products produced and the total and partial amount of a specific product produced. It also allows you to reset these values.
  • Page 54 FOCKE MELER GLUING SOLUTIONS UTILIZATION 40. Selection of STATISTICS screen. It is selected from the MENU screen. it shows the total amount of products TARBI INTEGRADO v97 produced and the total and partial amount of a specific product produced. It STARBI.v97...

  • Page 55: External Communication

    UTILIZATION MA-5188-GBR ANNEX INTEGRATED PATTERN CONTROLLER STARBI External communication For more information about communications, please see the “Micron+ Series Communications Annex” section of the manual. 4-33...
  • Page 56 FOCKE MELER GLUING SOLUTIONS UTILIZATION This page is intentionally left blank. 4-34...

  • Page 57: Outside Cleaning

    Do not replace the cable with another one of a type that is different from that provided by the equipment or recommended by Focke Meler. If in doubt, please check with your Focke Meler Representative or the Focke Meler Main Office.

  • Page 58: Calibrate The Screen

    FOCKE MELER GLUING SOLUTIONS MANTENANCE Calibrate the screen If necessary, it is possible to calibrate the touchscreen. Disconnect the power supply from the equipment. Open the front door to access the HMI card. Lower microswitch 8 on the HMI card to the OFF position.

  • Page 59: Technical Characteristics

    TECHNICAL CHARACTERISTICS MA-5188-GBR ANNEX INTEGRATED PATTERN CONTROLLER STARBI 6. TECHNICAL CHARACTERISTICS General StarBi 2 channels Supply voltage 100-240V ±10% Frequency 50/60Hz Channel Power up to 25 W/channel (per pair of outputs) Channels output voltage 24 VDC Screen 7”Touchscreen Output 0-10V (without insulation) 24 VDC (supply);...
  • Page 60 FOCKE MELER GLUING SOLUTIONS TECHNICAL CHARACTERISTICS This page is intentionally left blank.

  • Page 61: Accessories And Spare Parts List

    ACCESSORIES ANDESPARE PARTS LIST MA-5188-GBR ANNEX INTEGRATED PATTERN CONTROLLER STARBI 7. ACCESSORIES AND SPARE PARTS LIST The list of the most common spare parts in the time controller device appears in this chapter in order to provide a quick and reliable guide to choosing them.
  • Page 62 FOCKE MELER GLUING SOLUTIONS ACCESSORIES AND SPARE PARTS LIST Spare parts Nº Ref. Description 1500 30620 Power supply 24 VDC 4,5 A (2 outputs) 150030630 HMI card 150030640 I/O card...
  • Page 63 Solenoid valve cable 5/2 UF 6 m connection to terminals 150031070 Solenoid valve cable 5/2 UF 9 m connection to terminals 150060140 Solenoid valve cable 5/2 UF 10 m connection to terminals 150031240 Cable 6m output 24V pedal at Starbi photocell infeed...
  • Page 64 FOCKE MELER GLUING SOLUTIONS ACCESSORIES AND SPARE PARTS LIST This page is intentionally left blank.

  • Page 65: Ec Declaration Of Conformity

    EC DECLARATION OF CONFORMITY Original Declaration The manufacturer, Focke Meler Gluing Solutions, S.A. Pol. Arazuri-Orkoien, c/B, nº3 A E-31170 Arazuri - Navarra - Spain — A Focke Group Company — declaring that the machinery, Type: Model: Serial Number: fulfils all the relevant provisions of the Directive 2006/42/EC on machinery,...
  • Page 66 For more information speak with your Focke Meler representative: Focke Meler Gluing Solutions, S.A. Pol. Arazuri-Orkoien, c/B, nº3 A E-31170 Arazuri - Navarra - Spain Phone: +34 948 351 110 info@meler.eu - www.meler.eu A Focke Group Company...
