OPERATING INSTRUCTIONS
LIFTING BARRIERS
LBA 4, 6, 63PK, 7 and 74
Before installing or repairing your equipment, we recommend that you read these user and operating
instructions carefully.
We are at your disposal for any additional information or comments.
Please contact our After-Sales Service on +33 (0)4 78 86 02 86, from Monday to Friday, 9 am to 6 pm.
451 Chemin de Champivost - 69760 LIMONEST
Tél : +33 (0)4 78 86 02 86
www.grouplba.com - contact@lbagroup.fr
