Summary of Contents for GREINER MULTILINE NEXT DC

  • Page 2 Copyright: © 2019 GREINER GmbH All copyrights to this instruction manual remain with GREINER GmbH. Reprinting - even in extracts - is not permit- ted. The transfer of this manual to third parties requires the written permission of GREINER GmbH. Any use or modification outside the narrow limits of copyright law is not permitted without the consent of GREINER GmbH.

  • Page 3: Table Of Contents

    Basic position 4.3.3 Relax position 4.3.4 Bed position (flat position) 4.3.5 Shock position Duty cycle Battery mode Foot switch Equipotential bonding pin LED reading lamp Armrests 4.10 Footrest © 2019 GREINER GmbH Instruction manual - MULTILINE NEXT DC 3 / 72...
  • Page 4 Storage and transportation 8.2.1 Battery Check before recommissioning Disposal Appendix Explanation of symbols Ordering spare parts Return delivery / repair order Technical data Proof of instruction Glossary Notes 4 / 72 Instruction manual - MULTILINE NEXT DC © 2019 GREINER GmbH...

  • Page 5: Introduction

    With this instruction manual (hereinafter also referred to as the "manual") we would like to provide the user and operator with useful information for safe and proper operation of the MULTILINE NEXT DC couch (hereinafter also referred to as the "couch").

  • Page 6: Type Plate

    Further type plates can be found on all electrical components. Type plates are documents that may not be altered or removed. Damaged or lost type plates must be replaced true to the original. 6 / 72 Instruction manual - MULTILINE NEXT DC © 2019 GREINER GmbH...

  • Page 7: Safety

    The main objective of the safety instructions is to prevent injury to persons. In addition, observation of the safety instructions helps to avoid material damage. As the operator you have purchased a MULTILINE NEXT DC couch from GREINER GmbH. As a result, you are also responsible for its proper and intended operation.

  • Page 8: Safety Inspection

    (in printed or electronic form). Basic instruction for the user can be given by GREINER GmbH or its authorised specialist distributor at the re- quest of the operator.

  • Page 9: Intended Use

    Safety Intended use The MULTILINE NEXT DC couch from GREINER GmbH is a medical couch for use by patients in health facilities such as hospitals, clinics, medical practices and dialysis centres. It is intended exclusively for use inside buildings and under normal environmental conditions.

  • Page 10: Commissioning

    Operating temperature [C]: + 40 Air humidity [rH] (non-condensing): 20 % - 90 % Air pressure [hPa]: 700 - 1060 Operation at estimated altitude [m]: ≤ 2000 10 / 72 Instruction manual - MULTILINE NEXT DC © 2019 GREINER GmbH...

  • Page 11: Scope Of Delivery

    Scope of delivery Configuration options There are basically 3 different versions of the MULTILINE NEXT DC couches. They differ in the number of electri- cal adjustment options. In addition, the type of brake system installed for the castors determines the principle variant.

  • Page 12: Packaging

    The preparation section describes and shows how to unpack the couch and make it ready for operation using the example of a fully equipped MULTILINE NEXT DC with 5 adjustment drives and central locking of the castors (4225100) [A] [B].

  • Page 13: Removing The Packaging

    Remove the cardboard lid (2), the outer packaging (3) and the protective film (4) upwards [B] [C] [D]. NOTE Do not cut the packaging with a knife or long blade. The upholstery material or other parts of the couch could be damaged. © 2019 GREINER GmbH Instruction manual - MULTILINE NEXT DC 13 / 72...

  • Page 14: Preparation For Assembly

    Cut through the cable tie (7) on the wing screws (8) for fastening the seat upholstery. Remove the wing screws [F]. Do not lose the wing screws, as both are needed later again [G]. 14 / 72 Instruction manual - MULTILINE NEXT DC © 2019 GREINER GmbH...

  • Page 15: Releasing The Transport Lock

    Use your hand to guide the leg section when lowering. Hold the leg section while lowering and do not let it fall freely. Fig. 10 Folding down the cross bar Fold down the cross bar (4) vertically [D]. © 2019 GREINER GmbH Instruction manual - MULTILINE NEXT DC 15 / 72...

  • Page 16: Attaching The Leg Section Drive

    The circlips on the axles must re-engage correctly [E]. CAUTION Risk of trapping and crushing. The axle may slip out and the leg section may then drop unexpectedly. 16 / 72 Instruction manual - MULTILINE NEXT DC © 2019 GREINER GmbH...

  • Page 17: Electrical Commissioning

    To unlock the hand control (3), swipe the magnetic key (4) over the key symbol (5) (see 4.3.1 Un- locking and locking the hand control) [A] [B]. © 2019 GREINER GmbH Instruction manual - MULTILINE NEXT DC 17 / 72...

  • Page 18: Attaching The Footrest

    The circlips on the axles must re-engage correctly [D]. CAUTION Risk of trapping and crushing. The axle may slip out and the footrest may then drop unexpectedly. 18 / 72 Instruction manual - MULTILINE NEXT DC © 2019 GREINER GmbH...
  • Page 19 After assembly, both components must be arranged as shown [E]. Fig. 17 Checking the laying of the cables Checking the laying of the cables. The cables must not be trapped or crushed [F]. © 2019 GREINER GmbH Instruction manual - MULTILINE NEXT DC 19 / 72...

  • Page 20: Attaching The Seat Upholstery

    Place seat (1) on backrest upholstery (2) and align centrically with the backrest upholstery [B]. Align the Velcro connection (3) between the seat and backrest upholstery and attach [B]. 20 / 72 Instruction manual - MULTILINE NEXT DC © 2019 GREINER GmbH...
  • Page 21 Ensure correct fitting of the mounting bolts by lifting the seat upholstery [D]. Fig. 22 Check the Velcro connection Check that the Velcro connection is centred and wrinkle-free [E]. © 2019 GREINER GmbH Instruction manual - MULTILINE NEXT DC 21 / 72...
  • Page 22 Lock the hand control and hang it on the brackets at the front end of the arm supports (see 4.3.1 Unlocking and locking the hand control) [H]. 22 / 72 Instruction manual - MULTILINE NEXT DC © 2019 GREINER GmbH...

  • Page 23: Pushing The Couch Off The Transport Pallet

    The packaging material must be separated according to substance groups and disposed of properly in accordance with national regulations. If you have any queries, please contact your operator, your local municipalities or waste disposal companies (see 8.4 Disposal). © 2019 GREINER GmbH Instruction manual - MULTILINE NEXT DC 23 / 72...

  • Page 24: Requirements On The Place Of Operation

    A defective or faulty couch must be clearly marked "DEFECT". The marking must be done in such a way that the defective condition is clearly identifiable for everyone. Inform the operator for intensive inspection during repair. 24 / 72 Instruction manual - MULTILINE NEXT DC © 2019 GREINER GmbH...

  • Page 25: Operation

    WARNING Risk of injury due to the use of unsuitable accessories. Only original accessories from GREINER GmbH may be used. The attachment of accessories from other manufacturers (e.g. fixing belts etc.) lies within the re- sponsibility and duty of care of the operator.

  • Page 26: Structure

    Operation Structure The structure of the couch is shown here using the example of a fully equipped MULTILINE NEXT DC with 5 ad- justment drives and central locking of all 4 castors (4225100). Fig. 27 Structure of the couch Footrest 11.

  • Page 27: Hand Control

    11. Footrest - retract Backrest - down 12. Footrest - extend Seat inclination - up 13. Basic position Seat inclination - down 14. Shock position (Trendelenburg position) © 2019 GREINER GmbH Instruction manual - MULTILINE NEXT DC 27 / 72...

  • Page 28: Unlocking And Locking The Hand Control

    4.3.1 Unlocking and locking the hand control The unlocking and locking of the hand control is shown here using the example of a MULTILINE NEXT DC with 5 adjustment drives (only 4225000/4225100). Locking the hand control prevents the couch from moving accidentally or unintentionally.

  • Page 29: Basic Position

     The electric actuator of the footrest (only 4225000/4225100) remains in the existing position. Fig. 32 Button for basic position 13. Basic position Fig. 33 Basic position © 2019 GREINER GmbH Instruction manual - MULTILINE NEXT DC 29 / 72...

  • Page 30: Relax Position

    The position is permanently stored in the control unit and cannot be changed. Fig. 34 Button combination for relax position 15. Relax position: seat inclination - up+down Fig. 35 Relax position 30 / 72 Instruction manual - MULTILINE NEXT DC © 2019 GREINER GmbH...

  • Page 31: Bed Position (Flat Position)

    The position is permanently stored in the control unit and cannot be changed. Fig. 36 Button combination for bed position (flat position) 16. Bed position (flat position): leg section - up+down Fig. 37 Bed position (flat position) © 2019 GREINER GmbH Instruction manual - MULTILINE NEXT DC 31 / 72...

  • Page 32: Shock Position

    The seat height (not 4223000/4223100) and the electric adjustment drive of the footrest (only 4225000/4225100), if present, remain in the existing position. Fig. 38 Button for shock position (Trendelenburg position) 14. Shock position (Trendelenburg position) Fig. 39 Shock position 32 / 72 Instruction manual - MULTILINE NEXT DC © 2019 GREINER GmbH...

  • Page 33: Duty Cycle

    There is a danger that the initiated movement cannot be finished or that the processor in the control unit can no longer detect the position of the drives. The longest life span is achieved when the battery is fully charged. © 2019 GREINER GmbH Instruction manual - MULTILINE NEXT DC 33 / 72...

  • Page 34: Foot Switch

    To do this, place the plug completely onto the corresponding connection pin against the noticeable resistance. To remove, simply disconnect the plug. Connection pin Fig. 41 Equipotential bonding pin 34 / 72 Instruction manual - MULTILINE NEXT DC © 2019 GREINER GmbH...

  • Page 35: Led Reading Lamp

    Before cleaning and disinfecting, switch off the LED reading lamp and then disconnect the mains plug - allow to cool sufficiently (see 6 Cleaning and disinfection). Use commercially available plastic cleaners to clean the electrical components. © 2019 GREINER GmbH Instruction manual - MULTILINE NEXT DC 35 / 72...

  • Page 36: Armrests

    Now insert or pull out the armrest. Always hold the armrest when lowering and do not let it fall freely. Armrest Fig. 44 Armrests - adjusting the width 36 / 72 Instruction manual - MULTILINE NEXT DC © 2019 GREINER GmbH...
  • Page 37 The arm support (2) can be swivelled inwards or outwards independently of the armrest. To do this, loosen the handwheel (5) and swivel the arm support inwards or outwards, then retighten the handwheel. Arm support Handwheel (swivelling) Fig. 47 Arm supports - swivelling © 2019 GREINER GmbH Instruction manual - MULTILINE NEXT DC 37 / 72...

  • Page 38: Footrest

    To fix them in place, pull the clamping lever upwards. NOTE Do not use force to tighten the clamping lever beyond the noticeable end position. Footrest Clamping lever Fig. 49 Manual footrest 38 / 72 Instruction manual - MULTILINE NEXT DC © 2019 GREINER GmbH...

  • Page 39: Driving

    The couch is equipped with four lockable castors. All castors must be braked at all times the couch is parked (see 4.12 Braking). Fig. 50 Driving © 2019 GREINER GmbH Instruction manual - MULTILINE NEXT DC 39 / 72...

  • Page 40: Braking

    In the driving position, the green side of both pedals points downwards. All castors (2) are released simultaneously. Pedal Castor Fig. 52 Releasing the castors with central locking 40 / 72 Instruction manual - MULTILINE NEXT DC © 2019 GREINER GmbH...

  • Page 41: Castors With Central Locking And Directional Control

    In the manoeuvring position, all castors are completely free to move. This means that the couch can be manoeuvred in the tightest of spaces. Pedal Castor Castor (directional) Fig. 54 Manoeuvring the couch with central locking and directional control © 2019 GREINER GmbH Instruction manual - MULTILINE NEXT DC 41 / 72...
  • Page 42 Ensure that the directional castor is locked in the retracted position. Pedal Castor Castor (directional) Fig. 56 Driving the couch with central locking and directional control - directional castor set incorrectly 42 / 72 Instruction manual - MULTILINE NEXT DC © 2019 GREINER GmbH...

  • Page 43: Single-Braked Castors

    To release the brakes, push all 4 locking levers at the upper end with the tip of your foot. Locking pedal Castor Fig. 58 Releasing the single-braked castors © 2019 GREINER GmbH Instruction manual - MULTILINE NEXT DC 43 / 72...

  • Page 44: Sitting Down And Standing Up Of The Patients

    When driving on slopes or inclines, e.g. ramps, a second user must additionally secure the couch at  the front due to its weight and for the safety of the patient. 44 / 72 Instruction manual - MULTILINE NEXT DC © 2019 GREINER GmbH...

  • Page 45: Infusion Rod Holder And Infusion Rod

    Do not use the infusion rod as a push handle - risk of damage (see 4.11 Driving). NOTE Infusion rod holder Infusion rod Handwheel Clamping screw Fig. 60 Infusion rod holder and infusion rod © 2019 GREINER GmbH Instruction manual - MULTILINE NEXT DC 45 / 72...

  • Page 46: Accessories

    The couch can be ordered with a neck roll (4222600) to support the cervical spine. Of course, a neck roll, in the appropriate cover material and the desired colour, can be re-ordered at any time. Fig. 62 Neck roll 46 / 72 Instruction manual - MULTILINE NEXT DC © 2019 GREINER GmbH...

  • Page 47: Relax Pillow

    They are also available in combination with compact cover material on the large surfaces for backrest, seat and legrest upholstery. Fig. 64 Arm supports in premium material © 2019 GREINER GmbH Instruction manual - MULTILINE NEXT DC 47 / 72...

  • Page 48: Led Reading Lamp

    Vel- cro fasteners. This allows the protection cover to be attached and removed quickly and user-friendly - easy handling during cleaning. Fig. 66 Legrest upholstery protection cover 48 / 72 Instruction manual - MULTILINE NEXT DC © 2019 GREINER GmbH...

  • Page 49: Footrest Protection Cover

    - safety aspect. Fig. 68 Battery © 2019 GREINER GmbH Instruction manual - MULTILINE NEXT DC 49 / 72...

  • Page 50: Push Handle With Paper Roll Holder

    Of course, padded arm supports, in the appropri- ate cover material and the desired colour, can be re- ordered at any time. Fig. 70 Padded arm supports 50 / 72 Instruction manual - MULTILINE NEXT DC © 2019 GREINER GmbH...

  • Page 51: Infusion Rod Holder

    For handling the infusion rod holder (4221800) (see 4.15 Infusion rod holder and infusion rod). Fig. 71 Infusion rod holder 5.13 Infusion rod For handling the infusion rod (4221900) (see 4.15 Infusion rod holder and infusion rod). Fig. 72 Infusion rod © 2019 GREINER GmbH Instruction manual - MULTILINE NEXT DC 51 / 72...

  • Page 52: Standard Rails

    (see 5.1 Premium material). Fig. 74 Seat upholstery with pressure-relieving springs "premium." cover material Felt cover Wadding Single spring element Cut foam Ventilation opening in the wood 52 / 72 Instruction manual - MULTILINE NEXT DC © 2019 GREINER GmbH...

  • Page 53: Foot Switch

    See "4.3.2 Replacing the mains cable" in the service manual in any case. The range of possible variants is constantly being expanded. Just ask. Fig. 76 Mains cable CH Mains cable CH Mains plug CH © 2019 GREINER GmbH Instruction manual - MULTILINE NEXT DC 53 / 72...

  • Page 54: Cleaning And Disinfection

    The use of unsuitable cleaning agents and disinfectants, the wrong mixing ratio and insufficient NOTE care of the couch can cause damage to the surface coating for which GREINER GmbH is not liable. Ensure that no liquid residues remain on the metallic parts of the couch after cleaning and disin- fection (avoid droplet formation on edges).

  • Page 55: Cleaning

    Fire and explosion hazard due to wiping / spraying disinfection containing alcohol. There is a fire and explosion hazard when wiping or spraying disinfectants containing alcohol are used over large areas. © 2019 GREINER GmbH Instruction manual - MULTILINE NEXT DC 55 / 72...

  • Page 56: Troubleshooting

    When the couch is connected to the mains and the hand control is enabled with the magnetic key, the green op- eration control LED (2) lights up to indicate that the couch is ready for operation (see 4.3.1 Unlocking and locking the hand control). 56 / 72 Instruction manual - MULTILINE NEXT DC © 2019 GREINER GmbH...

  • Page 57: Initialisation Of Actuators

    This procedure is only recommended for an unoccupied couch. Fig. 77 Initialisation of actuators Backrest - up Seat inclination - down Leg section - down 13. Basic position 14. Shock position (Trendelenburg position) © 2019 GREINER GmbH Instruction manual - MULTILINE NEXT DC 57 / 72...

  • Page 58: Control Unit Reset

    In some cases, the actuators may have to be reinitialised after a "RESET" of the control unit (see 7.1 Initialisation of actuators). Fig. 78 Control unit RESET 15. Backrest - up 16. Backrest - down 58 / 72 Instruction manual - MULTILINE NEXT DC © 2019 GREINER GmbH...

  • Page 59: Troubleshooting Table

     Recalibrate the actuator(s).  when the actuators for the current position of the correspond- (see 7.1 Initialisation of actuators) backrest, seat inclination or ing actuator. leg section are activated. © 2019 GREINER GmbH Instruction manual - MULTILINE NEXT DC 59 / 72...
  • Page 60  If necessary, replace the castor(s).  Single-braked castor(s) Defective castor(s).  Inform the operator for intensive  do(s) not function(s) inspection during repair. properly.  If necessary, replace the castor(s). 60 / 72 Instruction manual - MULTILINE NEXT DC © 2019 GREINER GmbH...

  • Page 61: Decommissioning

    Service life Provided that the intended use, safety inspections and necessary maintenance measures are observed, the ser- vice life of the MULTILINE NEXT DC couch is approx. 7 to 10 years, depending on stress, operating conditions and frequency. Storage and transportation NOTE The MULTILINE NEXT DC couch should only be moved (see 4.3.2 Basic position and 4.11 Driving)

  • Page 62: Check Before Recommissioning

    A defective or faulty couch must be clearly marked "DEFECT". The marking must be done in such a way that the defective condition is clearly identifiable for everyone. Inform the operator for intensive inspection during repair. 62 / 72 Instruction manual - MULTILINE NEXT DC © 2019 GREINER GmbH...

  • Page 63: Disposal

    GREINER GmbH in a proper condition (cleaned and disinfected) (see 9.3 Return delivery / re- pair order). The device is identified by its GREINER serial number and type plate. The customer is respon- sible for proving that the product was produced by GREINER. For further information, please refer to our General Terms and Conditions at www.greiner-gmbh.de.

  • Page 64: Appendix

    Medical devices must be disinfected before repair. The operator or client is responsible for execution and credible proof. For further information, please refer to our General Terms and Conditions at www.greiner-gmbh.de. CAUTION Risk of infection from contaminated couch.

  • Page 65: Technical Data

    / lead gel 1) Duty cycle 10 % max. 2 minutes continuous use followed by 18 minutes not in use. Failure to do so may result in a malfunction. © 2019 GREINER GmbH Instruction manual - MULTILINE NEXT DC 65 / 72...

  • Page 66: Proof Of Instruction

    Appendix Proof of instruction MULTILINE NEXT DC Form for proof of instruction Fig. 80 Proof of instruction MULTILINE NEXT DC Type of instruction  Initial instruction  Repeated instruction Instruction by  Manufacturer  Authorised person of the authorised specialist distributor ...
  • Page 67 Company / Department Signature Last name First name Company / Department Signature Last name First name Company / Department Signature Last name First name Company / Department Signature © 2019 GREINER GmbH Instruction manual - MULTILINE NEXT DC 67 / 72...

  • Page 68: Glossary

    An operator (e.g. hospital, dialysis centre, hospital, hospital management, medical practice, company doctor etc.) can be the legal owner of the MULTILINE NEXT DC couch, as well as have actual control over it. The operator is responsible for the safe operation of this medical device.

  • Page 69: Notes

    Appendix Notes © 2019 GREINER GmbH Instruction manual - MULTILINE NEXT DC 69 / 72...
  • Page 70 Appendix 70 / 72 Instruction manual - MULTILINE NEXT DC © 2019 GREINER GmbH...
  • Page 71 Appendix © 2019 GREINER GmbH Instruction manual - MULTILINE NEXT DC 71 / 72...
