OWNER'S MANUAL
WASHING
MACHINE
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
EN ENGLISH
WV9-1410B, WV9-1412W
MFL71485444
Rev.00_030420
Copyright © 2020 LG Electronics Inc. All Rights Reserved.
www.lg.com
