- Page 1 CAMON Lawn Scarifier LS42 ORIGINAL INSTRUCTION MANUAL Manufactured by Tracmaster Ltd Before commissioning the machine, read operating instructions and observe warning and safety instructions.
- Page 2 CAMON LS42 Lawn Scarifier Manufacturer Details Tracmaster Ltd Units 6-7 Winterpick Business Park Hurstpierpoint Road Wineham Henfield BN5 9BJ UNITED KINGDOM Tel: +44 (0)1444 247689 www.tracmaster.co.uk info@tracmaster.co.uk Machine Details CAMON LS42 Lawn Scarifier Model: Serial No: B 0 1 -...
-
Page 3: Table Of Contents
To Stop the Engine .......................11 Safety Equipment ........................11 Operation..........................11 Procedure for Unexpected Shut Down ................13 How to Clear Unwanted Debris from the Underside of the Machine .........13 Residual Risks of the LS42 Scarifier ..................13 Maintenance ..........................14 Schedule ..........................14 Basic Maintenance ......................14 Advanced Maintenance .......................14 7.3.1 Belt ..........................14... -
Page 4: Introduction
We are confident that you will be more than happy with your machine. Your machine is covered by a comprehensive warranty. However, the lifespan of your CAMON machine depends on a number of factors. It is important that you read this manual carefully and follow the instructions regarding operation, maintenance, and care. -
Page 5: What The Machine Is Designed For
The blades of the CAMON LS42 Scarifier are designed to pass through the grass ONLY - they are NOT designed to make contact with solid ground at any point during operation. -
Page 6: Specifications
CAMON LS42 Lawn Scarifier 3.0 Specifications ENGINE Engine Manufacturer Honda Engine Model GX160 Engine Type 4-stroke OHV, single cylinder Net Engine Power 3.6kW (4.8hp) @ 3600rpm Engine Shaft Size ¾” straight Spark Plug BPR6ES (NGK) / W20EPR-U (DENSO) Spark Plug Gap 0.70 - 0.80mm... -
Page 7: Unpacking And Assembly
CAMON LS42 Lawn Scarifier 4.0 Unpacking and Assembly Major Components Diagram ① Operating Lever ① ② Throttle ③ ② ③ Top Handlebar ④ Engine ⑩ ⑤ Locating Pin ⑥ Height Adjuster Knob ⑤ ⑦ Belt Guard ④ ⑧ Wheels ⑦... -
Page 8: Safety Instructions - Pre-Operation
Scarifier. Height Adjustment The height of the blades of LS42 Scarifier is altered using the two large knobs at the front of the machine. The top knob is connected to the centre of the front axle via a threaded rod. Rotating the knob in each direction will raise or lower the front axle in relation to the main chassis of the machine and in turn alter the height of the blades with the chassis. -
Page 9: Rotor Shaft
CAMON LS42 Lawn Scarifier Use the central lifting handle when connecting or disconnecting the bag from the machine. Always stop the engine and wait for the blades to stop rotating by removing or replacing the collection bag. To attach the collection bag onto the machine, first lift the safety back flap on the rear of the machine chassis with one hand. -
Page 10: Engine Specific Safety Instructions
CAMON LS42 Lawn Scarifier 5.10 Engine Specific Safety Instructions Petrol is highly flammable. Always stop the engine and ensure the fuel tap is turned off before refueling, or when transporting, cleaning, or making adjustments to the machinery. Do not smoke or use a naked flame when refueling. - Page 11 It is important that these stickers are in good condition, are legible, and are in the correct positions on the LS42 Lawn Scarifier. If any of these stickers are missing or damaged then they must be replaced. They can be obtained from Tracmaster Ltd.
-
Page 12: Safety Instructions Starting And Operating
CAMON LS42 Lawn Scarifier 6.0 Safety Instructions Starting and Operating To Start the Engine Using the dipstick provided, check the engine oil level. Top up with SAE 10W/30 oil, API SJ or equivalent, if the dipstick is clear of oil. -
Page 13: To Stop The Engine
Turn the fuel tap lever to the OFF position. Ensure the blades have stopped prior to moving the machine. WARNING: THE EXHAUST COVER MAY BE HOT – DO NOT TOUCH. Safety Equipment The LS42 operator must be wearing: • Ear Defenders • Gloves • Protective Footwear •... - Page 14 Lift the operating lever to engage the rotor shaft and walk at a slow steady pace pushing the machine ahead of you. To turn the LS42 Scarifier 180 , release the operating lever, put light downwards pressure on the handlebars and rotate the machine on its rear wheels.
-
Page 15: Procedure For Unexpected Shut Down
Ensure that the blades have stopped rotating prior to moving or tilting the machine. The LS42 Scarifier is designed to be pushed by the operator both during transportation and operation. It has no brake system and therefore the operator must hold firmly onto the machine on sloped areas. -
Page 16: Maintenance
CAMON LS42 Lawn Scarifier 7.0 Maintenance Important! Before undertaking any maintenance ensure that the engine is off and the fuel tap is off. Schedule Every Every Operation Daily Week Month Check engine oil level SAE 10W/30 API SJ or equivalent... -
Page 17: Rotate Rotor
CAMON LS42 Lawn Scarifier Release the tension from the belt by using the engine plate tension screws at the rear of the engine plate. The drive belt has now become slack. Grab the right-hand side of the belt close to the bottom pulley and pull as if you are trying to pull the belt off the bottom pulley. -
Page 18: Blades
7.3.3 Blades Inspection Check: Blades that have been worn so that they have become rounded must be changed in order for the LS42 Scarifier to function properly. Changing the Blades: Safety glasses and gloves must be worn. Remove the rotor as described in section 7.3.2. -
Page 19: Engine
CAMON LS42 Lawn Scarifier Engine 7.4.1 Check Engine Oil Level This is to be checked prior to each use and every 8 hours during operation. Check only when the engine is off and in a horizontal position. Clean the oil filler plug and its surrounding parts. -
Page 20: Spark Plug
CAMON LS42 Lawn Scarifier 7.4.4 Spark Plug Clean and replace. Cleaning After cleaning, particularly if a pressure washer has been used, ensure any lubrication points are re-lubricated. Clean the engine with a cloth only. Avoid spraying the engine with jets of water as this may leak into the fuel and ignition systems. -
Page 21: Engine
CAMON LS42 Lawn Scarifier 7.6.2 Engine Problem Possible Cause Remedy Spark plug connector Connect spark plug connector not connected Choke lever is not Actuate choke lever actuated Engine does not Fuel tank empty Fill fuel tank start Fuel line clogged... -
Page 22: Transportation, Storage And Handling
Use ramps where possible to manoeuvre the LS42 Lawn Scarifier into a transportation vehicle. The LS42 Lawn Scarifier must be fixed securely using straps and by placing chocks behind the wheels. Always transport the LS42 Lawn Scarifier horizontally and not tilted at an angle. -
Page 23: Spare Parts
9.0 Spare Parts Parts Diagrams The spare parts diagrams and part numbers for the CAMON LS42 Lawn Scarifier can be found on our website or by contacting our spare parts department. Spare parts can be ordered via the following methods:... -
Page 24: Service Record
CAMON LS42 Lawn Scarifier 10.0 Service Record To ensure your machine is kept in peak condition we recommend that your CAMON LS42 Lawn Scarifier is serviced at regular intervals. Contact Tracmaster on 01444 247689 to find out who your local Authorised Tracmaster Dealer is, or check our Dealer Locator online at www.tracmaster.co.uk. -
Page 25: Ec Declaration Of Conformity
CAMON LS42 Lawn Scarifier 11.0 EC Declaration of Conformity Tracmaster Ltd declares that the machinery stipulated below complies with all the relevant provisions of: Machinery Directive 2006/42/EC EMC Directive 2004/108/EC and the National Laws and Regulations adopting these directives and other relevant directive. -
Page 26: Warranty Information
CAMON LS42 Lawn Scarifier 12.0 Warranty Information The Warranty applies to any part of the machine, except the engine, which presents manufacturing or assembly defects in the opinion of Tracmaster Ltd. The Warranty covers the original purchaser of the machine from the date of sale for the warranty period. - Page 27 CAMON LS42 Lawn Scarifier For any issues relating to the engine please contact an authorised service centre for the engine. The engines are warranted according to the practices set by their respective manufacturers and distributors. If an issue develops with the machine, within the warranty period, the problem must be verfied by Tracmaster or an Authorised Tracmaster Dealer before any repair is undertaken.
- Page 28 CAMON LS42 Lawn Scarifier Original Instruction Manual © 2020 Tracmaster Ltd Tracmaster Ltd Units 6-7 Winterpick Business Park | Hurstpierpoint Road | Wineham | Henfield | BN5 9BJ | UK Tel: +44 (0)1444 247689 | www.tracmaster.co.uk | info@tracmaster.co.uk...
