Forms+Surfaces AVIVO TABLE Installation Instructions

AVIVO TABLE
TM

MATERIALS INCLUDED

a
7/32" hex bit for tamper-
resistant screws

STEP BY STEP

FOR ALL SURFACE MOUNT AVIVO TABLES (STAVO-T4040 SHOWN)

Mark hole locations

• Place table in desired location. Mark the
center of each mounting hole location
with a pencil.
T 800.451.0410 | www.forms-surfaces.com
© 2018 Forms+Surfaces® | All dimensions are nominal. Specifications and pricing subject to change without notice. For the most current version of this document, please refer to our website at www.forms-surfaces.com.

TOOLS NEEDED

c
b
d
e
1/4" & 1/2" drill bits

Drill holes

• Use hammer drill to drill 1.5" deep x 1/2"
diameter anchor hole at each marked
location using a 1/2" drill bit suitable for
concrete drilling.
NOTE: Forms+Surfaces recommends
starting holes with 1/4" diameter drill bit
followed by 1/2" for maximum accuracy.
SURFACE MOUNT INSTALLATION INSTRUCTIONS
pencil
for concrete
hammer

Insert anchors

• Use compressed air and steel wire brush
• Insert 3/8"-16 x 1-1/2" anchor (a) into
wire brush
hammer drill
a
to clean each anchor hole.
each anchor hole. Using a hammer, make
sure anchor top is flush with ground.
page 1 of 2 | Rev. 12-07-17
steel
a
