ENDEAVOUR ETPRO-30W Manual

The ETPRO-30W represents the latest in soldering iron technology. Using
a rechargeable lithium battery, this unit delivers a 30W output suitable for
automotive / industrial applications.
New rapid heat technology generates a 420 degree temperature within 35
seconds. The unit has a 45 minutes continuous runtime. Rechargeable
via mini USB.

Charging Instructions

This soldering is rechargeable. Using the supplied cable, insert the Micro
USB connector into the end of the soldering iron, and the USB connector to
a wall charger / computer port.
A full charge will take approximately 3.5 hours. Once charged, the indicator
light will turn green

Soldering Instructions

1. Thoroughly clean and remove oil and other contaminants from the parts to be
soldered.
2. Use only small amounts of solder. Excess solder can cause a short circuit.
3. Slide the soldering iron switch to the ON position. Press and hold the power button. LED will illuminate indicating that the iron is on.
4. Allow the tip to reach working temperature (about 10 seconds). Apply a small amount of solder to tapered surface of tip. Remove
excess solder with a damp soft rag or sponge.
5. Tin wires by heating the bare wire and allowing a small amount of solder to flow onto the tip of the wire.
6. Touch the tapered surface of the tip (not the point) to the joint to be soldered. Heat joint and allow heat from joint to melt solder.
7. Allow a small amount of solder to flow into the joint.
8. To ensure a strong joint, do not touch or move the joint until it has cooled completely.

Hot Knife Instructions

1. Slide soldering iron switch to the ON position. Press and hold the power button. LED will illuminate indicating the iron is on.
2. Allow the knife to reach working temperature (about 10 seconds). Cut the object you want.

How To Replace The Tip

1. Ensure soldering iron switch is in the OFF position. Allow tip to cool completely before replacing tip.
2. Use only genuine replacement tips.
3. Unscrew old tip by rotating translucent locking nut counterclockwise.
4. Screw in new tip by rotating translucent locking nut clockwise until it snaps on lock position. Note: Align the notch on the housing
to install the new tip.
5. Do not file the tip.

Adjust The Direction Of The Tip

Rotate the black knurled nut to adjust the direction of the tip.
Warnings
Potential electrical shock. Do not use soldering iron if housing is cracked or damaged. Never use in wet area. Do not attempt to
repair or modify soldering iron. Always de-energize devices being soldered.
Potential burn hazard. Hot tip can cause severe burns. Do not touch tip of tool. Allow tool to cool before touching tip or replacing
protective cap. Tip remains hot after use for several minutes.
www.endeavourtools.com.au
30W Soldering Iron Kit
Cone Soldering Tip
Cap
Chisel Soldering Tip
Knurled Nut
Locking Nut
LED Light
Power Button
ON/OFF Switch
Notch
Micro-USB Port
Knurled Nut
Locking Nut
LED Light
1300 137 753
ETPRO-30W
Hot Knife
Cleaning Sponge
Micro USB Connector
USB Connector
Safety Stand
15 gram Solder
(Tin:60%/Lead:40%)
