- Page 1 GLENSOUND EXPEDITION BROADCASTER’S 4G, 3G, GSM MOBILE PHONE PRODUCT DETAILS 6 BROOKS PLACE, MAIDSTONE, KENT, ME14 1HE. ENGLAND. TEL: +44 (0) 1622 753662 Visit our Website at www.glensound.co.uk FAX: +44 (0) 1622 762330...
- Page 2 Glensound Expedition Manual E&OE Page 2 of 35...
- Page 3 1 – 6 Brooks Place Maidstone Kent ME14 1HE United Kingdom Telephone: +44 (0) 1622 753662 Fax: +44 (0) 1622 762330 EMAIL ADDRESSES General enquires: office@glensound.co.uk Technical enquires: techinfo@glensound.co.uk Sales enquires: sales@glensound.co.uk Glensound Expedition Manual E&OE Page 3 of 35...
-
Page 4: Product Warranty
All non-wear parts are guaranteed for 2 years after despatch and any defect developing after proper use from faulty materials or workmanship will be repaired under this warranty providing the Customer returns the goods to the Company's works or their local dealer. Glensound Expedition Manual E&OE Page 4 of 35... - Page 5 Emissions: EN55103.1 Immunity: EN55103.2 WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT REGULATIONS 2006 (WEEE) Glensound Electronics Ltd is registered for business to business sales of WEEE in the UK our registration number is: WEE/JJ0074UR RoHS2 DIRECTIVE EC directive 2011/65/EU restricts the use of the hazardous substances listed below in electrical and electronic equipment.
-
Page 6: Conformity Statement For
Health and Safety (Art. 3.1 a): EN 60950-1 :2006+A11 :2009+A1 :2010 +A12:2011 EN 62311 :2008 (Art. 3.1 b): EN 301489-1:v.1.9.2; EN 301 489-7:v.1.3.1 RF spectrum efficiency (Art. 3.2): EN 301 511:v .9.0.2; Glensound Expedition Manual E&OE Page 6 of 35... -
Page 7: Table Of Contents
Receive SMS (Text) ............................29 View Own Telephone Number ........................29 Headphone Mix .............................. 30 Line Out Mix ..............................31 Ringing Melody ............................... 32 Ringing Melody Volume ..........................32 DTMF Duration ............................... 32 Glensound Expedition Manual E&OE Page 7 of 35... - Page 8 UPDATING FIRMWARE ........................... 33 BATTERY LIFE ..............................34 WIRING INFORMATION ..........................35 Glensound Expedition Manual E&OE Page 8 of 35...
-
Page 9: Overview
The Glensound Expedition is powered either from batteries (6 x AA cells) or an external DC input. Internally the Glensound Expedition is a highly sophisticated digital mixer, it has 2 analogue inputs both of which pass through high quality analogue to digital converters and then these signals are handled and routed by the onboard DSP. -
Page 10: Antenna Placement
ANTENNAS SUPPLIED The Expedition is supplied fitted with a pair of antennas suitable for general use. It is also supplied with a pair of large antennas which are higher performance tuned antennas capable of dissipating more of the Expedition’s phone energy with less reflections back to the mobile phone. -
Page 11: Panel Layout & Functions
2. HANG-UP Status LED This 5mm red LED is illuminated when no call is in progress. 3. DIAL Button Pressing the dial button makes the Expedition dial the currently selected number or answer an incoming call. 4. DIAL Status LED This 5mm green LED is illuminated when a call is in progress. - Page 12 8. Shoulder Strap Holes These holes in the lid and base can be used for attached the supplied shoulder strap to or for inserting screws through if the Expedition is to be permanently mounted. 9. Enter Button This is used in the configuration and other menus to confirm a selected option.
- Page 13 This red LED illuminates when channel A’s audio input is too high and the audio is becoming distorted. If this LED comes on then turn the gain down. 17. Power LED The power LED indicates when the Expedition is powered on and the internal microprocessor is operational. Glensound Expedition Manual E&OE Page 13 of 35...
- Page 14 PPM style meter to allow the user to see the level of the audio. This meter will stay on the display for approximately 15 seconds after the gain potentiometer was last adjusted. Glensound Expedition Manual E&OE Page 14 of 35...
- Page 15 This balanced standard 3 pin XLR audio input socket is the input of the A channel of the mixer. 27. Input B XLR balanced Audio Input This balanced standard 3 pin XLR audio input socket is the input of the A channel of the mixer. Glensound Expedition Manual E&OE Page 15 of 35...
- Page 16 30. Line Out XLR This balanced analogue output provides an output from the Expedition to connect to other audio equipment such as mixers, recorders, headphone amps etc. The audio that is present on the output can be altered in the configuration menu.
- Page 17 ***Please note removing the battery cover will disconnect the battery compartment and make the Expedition turn off if no external supply is connected. 33. Battery Compartment Access Thumbscrew See no 32. above.
- Page 18 Slide the SIM card into the slot provided (with the terminals of the SIM card towards the base of the Expedition) until it ‘clicks’ into place. To remove the SIM card first push the SIM card slightly into the Expedition until a ‘click’ is heard and then it will spring out.
-
Page 19: Inserting/ Removing A Sim
Slide the SIM card into the slot provided (with the terminals of the SIM card towards the base of the Expedition) until it ‘clicks’ into place. To remove the SIM card first push the SIM card slightly into the Expedition until a ‘click’ is heard and then it will spring out. -
Page 20: Turning The Expedition On/Off
‘beep’ is heard and the front panel LCD display is illuminated. ****Please note it can take nearly a minute for the Expedition to boot up and in low signal areas it can take another minute to find a network*** 4. -
Page 21: Basic Operation
BASIC OPERATION 1. Making a Call A. Insert a SIM card and turn the Expedition on. B. Using the top panel keypad dial the number that you wish to call C. Press and release the top panel green ‘DIAL’ button until the display shows ‘dialing’... -
Page 22: Lcd Display & Menus
The backlit LCD display provides general information useful to the operator. If the Expedition is being powered from an external DC supply then the back light of the display will on permanently. However if the Expedition Is being powered from batteries then to help preserve battery life the back light of the display will only be illuminated while and shortly after a button has been pressed. -
Page 23: Navigating Within The Menu System
View own Telephone Number Headphone Mix Menu Outgoing Phone: Phone RET AVC: Phone RET: Line Out Mix Menu Outgoing Phone: Phone RET AVC: Phone RET: Ringing Melody (sounder) Ringing Melody Volume (sounder) DTMF Duration Glensound Expedition Manual E&OE Page 23 of 35... -
Page 24: Saving A Number For Recall Later
If the sounder is OFF and you want it ON press the navigational right arrow and then press ENTER (The display will then show ‘Exit’ which confirms the change has been made). Glensound Expedition Manual E&OE Page 24 of 35... -
Page 25: Auto Answer On/ Off
****With Block Outgoing ID OFF the person you are calling will be able to see the number that you are calling from. With Block Outgoing ID ON the number that you are calling from will not be seen by the person that you have called.**** Glensound Expedition Manual E&OE Page 25 of 35... -
Page 26: Network Mode
To change the switch mode press the navigational left or right arrows until the desired option is selected and then press ENTER (The display will then show ‘Exit’ which confirms the change has been made). Glensound Expedition Manual E&OE Page 26 of 35... -
Page 27: Input B Switch Configuration
The message centre number is a number that is used to handle texts by your phone operator. When you send a text the text is actually sent to the message centre who in turn forward it to your intended recipient. Glensound Expedition Manual E&OE Page 27 of 35... -
Page 28: Create Sms (Text)
Create SMS (Text) NOTE: The texting options on the Expedition have been included to allow customers to send and receive network critical communications such as when setting up a new SIM card. The Expeditions texting functions are not designed for day to day texting! From the home screen press the ‘MENU’... -
Page 29: Receive Sms (Text)
Then press the navigational down arrow until you see the ‘Own Telephone No.’ menu. The screen will now display your own telephone number. ****Note the Expedition cannot display the number if your network or SIM does not provide it. Glensound Expedition Manual E&OE Page 29 of 35... -
Page 30: Headphone Mix
The last option in the Headphone mix menu is ‘Phone RET:’ This allows the option of routing the Return audio to the Phone ON or OFF to the headphone mix. Glensound Expedition Manual E&OE Page 30 of 35... -
Page 31: Line Out Mix
Then press the navigational down arrow until you see the ‘Line Out mix menu’ menu. There are 3 settings within the Line out mix menu which allow 2 sources to be routed to the balanced Line output XLR on the side of the Expedition. To access these settings press ENTER. -
Page 32: Ringing Melody
DTMF tone can be changed in this menu between 500mS, 1000mS and 2000mS. To change the current setting use the navigation left/ right arrows to select the desired duration and press ENTER to save. Glensound Expedition Manual E&OE Page 32 of 35... - Page 33 Dfuse on your PC. 2) Make sure you know where the latest version of the Expedition’s firmware is located on your pc (this is a .dfu file). This is a file that Glensound will have sent you or told you the location off.
- Page 34 Not all batteries are equal in the amount of energy that they store. In fact they vary hugely. A battery that does not store much energy will of course not keep the Expedition running as long as one that stores a lot of energy. Traditionally Alkaline batteries have always been the choice of Broadcasters, and we still recommend them over most other battery types, however Lithium Ion batteries are now commonly available and generally far exceed alkaline batteries.
- Page 35 IC to ground which could potentially cause damage. EXPEDITION External DC power input: 2.5mm Barrel, Centre +Ve, 10 to 15 Volts, 1 Amp Glensound Expedition Manual E&OE Page 35 of 35...
