RECEIVER GUIDE
Pg.
2
HOT SHOT OVERVIEW
3
RECEIVER INDICATOR LEDS
4
FUNCTION SWITCH SETTINGS
4
SUPERVISION FEATURE
4
SUPERVISION FAIL SAFE FEATURE
4
ENGINE STARTUP MODE
4
LOAD SHARING FEATURE
5
MULTIPLE RELAY OUTPUT CONTROL
6
RECEIVER HOOKUP TO ELECTRIC WELL
7
RECEIVER HOOKUP TO ELECTRIC WELL DIAGRAM
8
RECEIVER HOOKUP TO ENGINE DRIVEN WELL
Hot Shot Systems Inc. will no longer sell or warranty its products for the use in controlling or monitoring pollut-
ants. However, the use of these controllers in non pollutant applications such as water tanks, water pumps, pivots,
irrigation systems and any other monitoring or control applications that do not involve pollutants are suitable for
these products.
IRRIGATION
810-R PLUS
Version : 1006
Advertisement
Table of Contents
Related Manuals for Hot Shot 810-R Plus
Summary of Contents for Hot Shot 810-R Plus
- Page 1 RECEIVER HOOKUP TO ENGINE DRIVEN WELL Hot Shot Systems Inc. will no longer sell or warranty its products for the use in controlling or monitoring pollut- ants. However, the use of these controllers in non pollutant applications such as water tanks, water pumps, pivots, irrigation systems and any other monitoring or control applications that do not involve pollutants are suitable for these products.
-
Page 2: Information To User
HOW IT WORKS Think of the HOT SHOT system as a control wire going from the transmitter site to the receiver site. When the Hot Shot Transmitter’s SENSOR ON-OFF Input is connected to COM, a 10 second delay timer is started. -
Page 3: Code Switch Settings
12” of the antenna whip. If longer range is needed, an external long range antenna can be used. Do not mount the HOT SHOT receiver to the well engine or cover because the strong vibrations can be harmful to the unit. - Page 4 SWITCH# FUNCTION SWITCH SETTINGS FOR RELAY #1 OUTPUT ONLY WILL ACTIVATE MOMENTARY FOR 10 SEC. INVERTED RELAY OUTPUT CONTROL ACTIVATION OF RELAY DELAYED BY 10 SEC. (See Load Sharing below) ACTIVATION OF RELAY DELAYED BY 5 SEC. (See Load Sharing below) NOT USED ACTIVATES ENIGNE STARTUP MODE - WITH 15MIN BY-PASS TIMER (See below) ACTIVATES FAIL-SAFE MODE - SCENERIO 1 (...
- Page 5 USING THE MULTIPLE RELAY OUTPUT TERMINALS When a Hot Shot Receiver 810-R PLUS is going to be used with a Hot Shot 810-T transmitter using it’s #1,2,3,4,5, OR 6 SENSOR INPUT or the Pump Selector Kit the receiver’s going to be used will...
- Page 6 Shot Systems, just request when ordering. Mount a 3 terminal fuse block and a 120vac relay. Hot Shot Systems suggest using a 115V AC coil relay. They are available for purchase through Hot Shot Systems, just request when or- dering.
- Page 7 OBJECT: WHEN THE HOT SHOT TRANSMITTER’S RELAY INPUT TO COMMON IS CLOSED IT SENDS OUT THE RELAY ON COMMAND TO THE RECEIVER. WHEN THE HOT SHOT RECEIVER GETS THE ON SIGNAL IT WILL CLOSE ITS N.O. TO COMMON CONTACTS. THIS WILL ENERGIZE THE 120V RELAY TO CLOSE THE 480V CONTACTOR.
- Page 8 Install a jumper wire connecting the negative terminal to the COM terminal on the receiver. Connect a wire from the N.C. terminal on the Hot Shot receiver to the S or the SW1 terminal on the Murphy kill switch.
- Page 9 FOR SAFETY AND PEAK PERFORMANCE Hot Shot wireless systems are equipped with a GROUND terminal that needs to be connected to an NEC approved ground rod. A Hot Shot has various lightning and static protection devices incorporated on the cir- cuit board that require proper grounding to operate.
- Page 10 APPENDIX SUPERVISION FEATURE The Supervision Feature is a great way for checking at a glance the integrity of communications between the trans- mitter and receivers. The supervision feature is designed to work with only one transmitter per system as the su- pervision feature’s timer can operate on multiple receivers at the same time.
