RECEIVER GUIDE
Pg.
2
HOT SHOT OVERVIEW
3
RECEIVER FUNCTION SWITCH SETTINGS
4
RECEIVER INDICATOR LIGHTS
4
SUPERVISION FEATURE
4
ASSIGNING RECEIVER #
5
MULTIPLE PUMP CONTROL
6
RECEIVER HOOKUP TO ELECTRIC WELL
7
RECEIVER HOOKUP TO ELECTRIC WELL DIAGRAM
8
RECEIVER HOOKUP TO ENGINE DRIVEN WELL
IRRIGATION
810-3R-PLUS
Version : 1005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 810-3R-PLUS and is the answer not in the manual?

Questions and answers

Summary of Contents for Hot Shot 810-3R-PLUS

  • Page 1 IRRIGATION 810-3R-PLUS RECEIVER GUIDE HOT SHOT OVERVIEW RECEIVER FUNCTION SWITCH SETTINGS RECEIVER INDICATOR LIGHTS SUPERVISION FEATURE ASSIGNING RECEIVER # MULTIPLE PUMP CONTROL RECEIVER HOOKUP TO ELECTRIC WELL RECEIVER HOOKUP TO ELECTRIC WELL DIAGRAM RECEIVER HOOKUP TO ENGINE DRIVEN WELL Version : 1005...
  • Page 2: How It Works

    This transmission will close the relay contacts at the pump to start water. When the pivot is done irrigating or when the safety is tripped, the pivot will open the Hot Shot Trans- mitter’s RELAY Input contacts and send the (turn OFF) relay command to stop water. Battery backup in the transmitter will still allow the HOT SHOT to work in case of a pivot power out- age.
  • Page 3: Code Switch Settings

    12” of the antenna whip. If longer range is needed, an external long range antenna can be used. Do not mount the HOT SHOT receiver to the well engine or cover because the strong vibrations can be harmful to the unit.
  • Page 4: Function Switch Settings

    RECEIVER UNIT 810-3R PLUS FUNCTION SWITCH SETTINGS WHAT RELAY WILL DO WHEN ACTIVATED SWITCH# WILL ACTIVATE MOMENTARY FOR 10 SEC. RELAY WILL STAY LATCHED UNTIL RESET CODE IS SENT. INVERT FUNCTION – AT POWER UP RELAY BECOMES ENERGIZED. (COM TERMINAL IS CLOSED TO N.O. TERMINAL) RELAY STARTS IN THE DEFAULT POSITION WITH N.C.
  • Page 5 USING 1 HOT SHOT 810-3R-PLUS TO CONTROL UP TO THREE PUMPS. A Hot Shot 810-3R-PLUS can come equipped to operate all three of its relays when the application requires it. This style of receiver is convenient when the pumps are located close together or when their power supply comes from the same circuit box.
  • Page 6 Shot Systems, just request when ordering.  Mount a 3 terminal fuse block and a 120vac relay. Hot Shot Systems suggest using a 115V AC coil relay. They are available for purchase through Hot Shot Systems, just request when or- dering.
  • Page 7 OBJECT: WHEN THE HOT SHOT TRANSMITTER’S RELAY INPUT TO COMMON IS CLOSED IT SENDS OUT THE RELAY ON COMMAND TO THE RECEIVER. WHEN THE HOT SHOT RECEIVER GETS THE ON SIGNAL IT WILL CLOSE ITS N.O. TO COMMON CONTACTS. THIS WILL ENERGIZE THE 120V RELAY TO CLOSE THE 480V CONTACTOR.
  • Page 8 Install a jumper wire connecting the negative terminal to the COM terminal on the receiver. Connect a wire from the N.C. terminal on the Hot Shot receiver to the S or the SW1 terminal on the Murphy kill switch.
