Power Cable/Fuse Replacement

This document describes how to change the power cord and fuse on a SmartBits chassis
when using the Power Cable/Fuse Kit that is shipped with the chassis.
The Power Cable/Fuse Kit contains the power cable and fuses that should be used for
international operation (other than U.S.A.) in a SmartBits chassis, in compliance with
safety requirements. Each SmartBits chassis is shipped with the default U.S.A. fuses
installed.

Fuse Amperage Information

Table 1
Table 1. Fuse Amperage for SmartBits Chassis
Chassis
SmartBits 200
SmartBits 10
SmartBits 2000
SmartBits 600
SmartBits 6000B
P/N 340-1228-001 Rev B, 2/03
lists the fuse amperage specified for each SmartBits chassis.
Fuse Amperage U.S.A.
2 Amp.
3.15 Amp.
2 Amp.
10 Amp.
Fuse Amperage International
1 Amp.
2 Amp.
1 Amp.
5 Amp.
Power Cable/Fuse Replacement
|
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SmartBits 200 and is the answer not in the manual?

Questions and answers

Related Manuals for Spirent communications SmartBits 200

Summary of Contents for Spirent communications SmartBits 200

  • Page 1 Fuse Amperage Information Table 1 lists the fuse amperage specified for each SmartBits chassis. Table 1. Fuse Amperage for SmartBits Chassis Chassis Fuse Amperage U.S.A. Fuse Amperage International SmartBits 200 2 Amp. 1 Amp. SmartBits 10 3.15 Amp. 2 Amp. SmartBits 2000 SmartBits 600 2 Amp.
  • Page 2 Power Cable/Fuse Replacement Chassis Fuse Location Chassis Fuse Location The power supply inlet switch is the main disconnect device and is located on the rear of each SmartBits chassis. It houses the power switch, fuse holder, and a universal 3-wire instrument power cord jack.
  • Page 3 Power Cable/Fuse Replacement Installing a Chassis Fuse Installing a Chassis Fuse The installation of a SmartBits chassis fuse varies based on the chassis model. Refer to the appropriate procedure below to install the fuse for your SmartBits chassis model. SMB-10, SMB-200, SMB-2000, and SMB-600 Power Supply Inlet Switch To remove or change a fuse: If your chassis is operating, power down the chassis and disconnect the power supply cable from its power source.
  • Page 4 Power Cable/Fuse Replacement Installing a Chassis Fuse Remove the fuse and replace it with the international fuse provided in the Power Cable/Fuse Kit. Replace the fuse holder assembly by sliding it back into the power supply inlet switch until it snaps into its proper position. Connect the new international power supply cable provided in the Power Cable/Fuse Kit.
  • Page 5 Power Cable/Fuse Replacement Installing a Chassis Fuse Use the screwdriver again and place it in the slot at the top of the red fuse holder assembly (Figure 7), then pry the assembly out. Slot Power Supply Inlet Switch (SMB-6000B) Fuse Holder Assembly (slides out) Figure 7.
