Technical Specifications ..8 • Powering the System ..15 • Rack Mounting the SPT-N11U/SPT-N12U ..10 • Related Documentation ..17 • How to Contact Us ..18...
Page 2
The information contained in this document is subject to change without notice and does not represent a commitment on the part of Spirent Communications. The information in this document is believed to be accurate and reliable, however, Spirent Communications assumes no responsibility or liability for any errors or inaccuracies that may appear in the document.
Page 3
Note: Describes limitations on the use of the equipment or procedure. Equipment Noise Level Warning: The SPT-N11U/SPT-N12U is designed for operation in an unattended room (e.g., datacom or telecom equipment room). The system can generate noise levels up to 90.7 dB (A-weighted sound power level, L...
Certifications and Standards The SPT-N11U/SPT-N12U chassis complies with the limits for a Class A digital device in accordance with Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when this equipment is operated in a commercial environment.
Page 5
SPT-N11U and SPT-N12U Chassis Installation Instructions Certifications and Standards The CE symbol on the product label (on the back of the box) indicates this network appliance is compliant with the EMC Directive and Low Voltage Directive of the European Union. This product meets the following technical standards: •...
Page 6
SPT-N11U and SPT-N12U Chassis Installation Instructions Certifications and Standards Environmental Considerations This label is on all Spirent-provided electrical and electronic products that are sold and shipped. This label indicates that the product contains material that presents an environmental concern. Spirent encourages users of Spirent-provided electrical and electronic equipment to not dispose of the labeled products in waste collection units where the waste is destined for landfills.
The inlet air temperature must be in the range of 59° to 95° F (15° to 35° C); 20% to 80% relative humidity • The SPT-N11U/SPT-N12U is designed to be mounted in a Telecom-style 19" 2- or 4- post open rack. •...
Inlet AC for STC-N11U-220: 4 x 230V @ 15A; one 15A circuit dedicated for system operation and one 15A circuit per four (4) test module slots • Peak power requirement: 7kW for fully loaded SPT-N11U, 8.2kW for SPT-N12U • Administration and Operation •...
Page 9
SPT-N11U and SPT-N12U Chassis Installation Instructions Technical Specifications • Built-in Android touchscreen (SPT-N11U only) • SSH terminal emulation via Ethernet • Direct via external video connector and USB ports • Indicators and controls • System power on/off • Controller reset •...
Refer to SPT-N11U/SPT-N12U Chassis Power Supply Installation Instructions. Warning: An empty SPT-N11U system weighs approximately 125 lb. An empty SPT- N12U system weighs approximately 127 lb. Spirent recommends that an IT equipment lift be used to rack the system. If one is not...
Page 11
SPT-N11U and SPT-N12U Chassis Installation Instructions Rack Mounting the SPT-N11U/SPT-N12U Two-Post Rack Mounting Warning: The chassis should never be installed in a two-post rack using the front rack ears. There is a risk of equipment damage and personal injury, due to the weight of the system.
Page 12
Figure 3. Securing the Center-Mount Brackets With the chassis secured, you can install the power supplies. Refer to SPT-N11U Chassis Power Supply Installation Instructions. SPT-N11U and SPT-N12U Installation Instructions P/N 71-008728 Rev A, August 2019...
Page 13
SPT-N11U and SPT-N12U Chassis Installation Instructions Rack Mounting the SPT-N11U/SPT-N12U Four-Post Rack Mounting Remove the center-mount brackets with a screwdriver if they are secured to the chassis (Figure Figure 4. Remove the Center-Mount Brackets Install the ACC-2021A tray or a shelf with a depth of at least 30" and with a static...
Page 14
SPT-N11U and SPT-N12U Chassis Installation Instructions Rack Mounting the SPT-N11U/SPT-N12U Figure 6. Using an Equipment Lift for Installation SPT-N11U and SPT-N12U Installation Instructions P/N 71-008728 Rev A, August 2019...
Figure 3 on page 12). Figure 7. Securing the Front-Mount Brackets to a Four-Post Shelf With the chassis secured, you can install the power supplies. Refer to SPT-N11U Chassis Power Supply Installation Instructions. Powering the System Important: Each power cord must be connected to a 15A circuit with no other connected equipment and each with its own breaker.
Page 16
Controller and Fans Figure 8. Power Supply Sockets for SPT-N11U/SPT-N12U-110 Configuration For the SPT-N11U/SPT-N12U-220 configuration, the rightmost power socket is also for the system (the system controller and fans); moving to the left, the next socket powers module slots 1 - 4, then 5 - 8, etc., with the leftmost socket powering slots 9 - 12.
SPT- N11U, SPT-N12U, and SPT-N4U chassis. • SPT-N11U and SPT-N12U Fan Tray Replacement Instructions – Describes the procedure to replace the fan tray. • Spirent Hardware Reference – Describes Spirent chassis, modules, and accessories.
Phone: +86 (400) 810-9529 (toll-free mainland China only) Phone: +86 (10) 8233 0033 (China) Hours: Monday through Friday, 09:00 to 18:00, Beijing Time Information about Spirent Communications and its products and services can be found on the main company website at https://www.spirent.com. Company Address Spirent Communications, Inc.
