- Page 1 INSTRUCTION MANUAL CAMERA INTERFACE FOR MERCEDES-BENZ NTG 6.0 MBUX (7 INCH) Product No. 27-591...
-
Page 2: Table Of Contents
CONTENT COMPATIBILITY ..................... 4 FEATURES ..................... 4 PACKAGE COMPONENTS ................5 CONNECTION DIAGRAM ................6 DIP SETTING ....................7 HOW TO ENTER DVR VIDEO IN (VIDEO 3) ............8... - Page 3 WARNING In order to protect the driving safety and avoid break the traffic law; please DO NOT operate the interface while driving. The reversing surveillance function just is used in reversing assistance. Please check the entire surroundings while reversing. All steps of installation should be done by the well-trained specialist. During installation, the ignition key should be taken off and after all installation finished, connect power cable last.
-
Page 4: Compatibility
COMPATIBILITY Make Models Years Original system MBUX (NTG 6.0) Mercedes-Benz A class 2018- with 7 inch screen FEATURES Offers 3 video in for front/rear view camera and external video device like TV tuner, etc Support PDC (Parking Distance Control) and FPG (Flexible Parking Guidelines) Supply pure 12V power to the front and rear view camera Display front view automatically after shifting from “R”... -
Page 5: Package Components
PACKAGE COMPONENTS Main Unit Main power harness LVDS Cable... -
Page 6: Connection Diagram
CONNECTION DIAGRAM OEM male connector OEM LVDS cable OEM head unit Provided LVDS cable POWER LVDS IN LVDS OUT 360 VGA ACC 12V output, supply power for external video device Reverse Detect, connect to reversing light if PARKING 12V cable does not output 12V Parking 12V, Supply 12V power for front &... -
Page 7: Dip Setting
DIP SETTING 2018- A class: Selection of car model 1 OFF, 2 OFF, 3 OFF Disable PDC (parking Enable distance control) Disable FPG (flexible Enable parking guideline) Enable DVR (video 3) Disable DVR (video 3) Display front view camera for 10S Disable front view automatically after shifted from “R”... -
Page 8: How To Enter Dvr Video In (Video 3)
HOW TO ENTER DVR VIDEO IN (VIDEO 3) Set DIP 6 down (ON), long press "Hang-up" button on steering wheel for 2S. OEM UI (VIDEO 3)
