Table of contents Conformity Managing printers Symbols and messages Printer selection (optional) Introduction Label printer selection (optional) About this manual Label printer usage (optional) Use restrictions Label content description Safety information Sterilizer tests Safety warnings Sterilizer performance tests Responsibility Bowie and Dick test Getting started Helix test Unpacking...
Page 4
800-cycle maintenance 4000 cycle or five-year maintenance Extraordinary maintenance Disposal Diagnostics Errors Troubleshooting Emergency door opening Technical data Sterilization cycles Sterilization cycle phases Technical data Recommendations for validation Diagrams Water quality Accessories, spare parts, consumables Authorized W&H service partners Documentation forms W&H installation check-list Helix test documentation form LISA ...
Conformity Note: Every new sterilizer is delivered with a Declaration of Conformity and a CONFORMITY TO EUROPEAN STANDARDS AND DIRECTIVES Warranty Card. STERILIZER featuring sterilization cycles conform with the following standards: Standards Description Directives Medical Device Directive (MDD). Medical Device Directive 93/42/EEC for devices class IIb, in accordance with the Rule 15 –...
Symbols and messages SAFETY SYMBOLS USED IN THIS MANUAL WARNING: Indicates a hazardous situation that, if not avoided, could CAUTION: Indicates a hazardous situation that, if not avoided, could result in death or serious injury. result in minor or moderate injury. Related to a sterilizer, these warnings indicate hazardous situations that could result in non-sterile conditions (e.g.
Introduction CONTENTS OBLIGATIONS WITH REGARD TO THIS MANUAL This section deals with the following subjects: This manual is an integral part of the product and accompanies it for its entire working life. It must be consulted in all situations related About this manual to the life cycle of the product, from its delivery through to Use restrictions...
Safety information CONTENTS ELECTRICAL RISKS This section deals with the following subjects: Do not pour water or any other liquids over the sterilizer (risk of electrical short circuits). Safety warnings Switch off the sterilizer and unplug the mains Responsibility cable before inspecting, carrying out maintenance or servicing the sterilizer.
Safety information always available at med.wh.com. TAMPERING Keep these Instructions for Use for future reference. Do not remove the name plate or labels from the sterilizer. MANUFACTURER RESPONSIBILITY Repairs, maintenance or service must be carried The manufacturer can only accept responsibility for the safety, out by authorized service providers always using reliability and performance of the product when the product genuine spare parts.
Getting started CONTENTS Unpacking This section deals with the following subjects: Unpacking UNPACK THE STERILIZER Handling CAUTION! Heavy product. The sterilizer must be removed Product description from the box and transported by two authorized technicians. Installing the sterilizer Weight: Operating the sterilizer LISA 17: 50.2 kg (110.7 lbs) User interface menu LISA 22: 51.7 kg (114 lbs)
Page 12
Getting started WARNINGS Notice: Check the external condition of the box and the sterilizer. In case of any damage, immediately contact the dealer or shipping agent that has carried out the transport. Keep the packaging for shipping or transporting the sterilizer in the future. Note: The packaging of the product is environmentally friendly and can be disposed of by industrial recycling companies.
Getting started ITEMS NOT PROVIDED WITH THE STERILIZER The following items are not provided: Water container to capture waste water during manual tank draining (volume larger than 4 l (1.06 gal)) LAN cable for connecting the sterilizer to a network (optional) See "Accessories, spare parts, consumables"...
Getting started Clearance requirements to ensure proper air circulation: Installing the sterilizer LOCATION REQUIREMENTS Notice: Do not place the sterilizer so that it is difficult to operate the controls behind the service door. Do not place the sterilizer so that it is difficult to disconnect the power supply plug.
Page 19
Getting started The electrical power supply of the sterilizer must fulfill all applicable LAN CONNECTION standards in the country of use, and must comply with the data label on the back of the sterilizer. WATER CONNECTIONS The sterilizer clean water tank can be filled manually by the user or automatically with a water supply system.
Getting started INSTALLING THE STERILIZER Operating the sterilizer WARNING! In case of sterilizer malfunctions immediately unplug the sterilizer and call for service. Do not attempt to POWER THE STERILIZER ON/OFF repair the sterilizer by yourself. Press the power switch behind the Notice: service door: once switched ON, the Please ensure that all installation requirements are met before...
Page 21
Getting started After a quick autotest the sterilizer HOMEPAGE DESCRIPTION automatically turns in standby Part Description mode. See "Standby mode" on page 32. Title/purpose of the screen, or the cycle number and the current date and time Available cycles Available tests Additional buttons used to navigate the menu.
Page 23
Getting started MAIN MENU FUNCTION Icon Function Label Icon Function Label Date & Time Sets time and date values and format. Menu Opens the menu. Language Sets the language. Settings Sets the device. Energy Sets the standby mode. management Opens the pages to monitor the performed cycle data and Traceability manage users and printing.
Page 24
Getting started Icon Function Icon Function Label Label Daily Cycle Programs a sequence of cycles to be run on daily basis. Save all Copies all the files in the specified location in the network. Program Connectivity Opens the pages to manage the network connection. Test Checks if the files can be copied to the specified location.
Page 25
Getting started Icon Function Icon Function Label Label Administrator only. Permits the following: Adjusts the label printer to the edge of the label. Options Calibration identify and save the operator who starts the cycle and releases the load. Protect with a password the cycle starts, the load Prints a test label.
Page 26
Getting started COMMON COMMANDS AND ICONS Icon Function Icon Function Icon Function Refreshes the page. Indicates that the option checked is working properly. Enters/exits the standby mode. Plays a video. Indicates the value that may be Starts a procedure. changed and appears by clicking on Moves to the previous/next screen.
Page 27
Getting started Icon Function Indicates that the option is active/not active. Indicates that the option is enabled/disabled. Indicates that the user is using the administrator credentials. Gives information about the function displayed. Confirms the active option and saves a setting or a parameter. Copy the system info to the USB pen drive.
Getting started Sterilizer setup SET THE DATE AND TIME To change the current date and time: SET THE LANGUAGE On the homepage tap > > > On the homepage tap > > > Tap the value you want to change (time, date, format): the highlighted Tap the language you prefer.
Page 29
Getting started SET THE STERILIZER NAME SET THE DISPLAY BRIGHTNESS To change the sterilizer name that appears in the cycle reports: To change the display brightness: On the homepage tap > > On the homepage tap > > > > Tap the text box: ...
Page 30
Getting started On the homepage tap > > Note: in the TPC/IP screen, the icon is visible only if you make any change. The Wi-Fi icon at the If the connection is through the bottom will not be visible if you Ethernet cable, tap : the TCP/IP connect through Ethernet cable.
Getting started Enter your new PIN and tap User authentication confirm: a confirmation message with your new PIN appears. FUNCTION AVAILABILITY and then to go back to PIN MANAGEMENT the previous page. PIN “0000” is assigned as default to each new user. It has to be changed at the first login.
Getting started Notice: Periodically remove the USB pen drive to save the cycle Standby mode data on a computer or on another safe support. DESCRIPTION FORMAT THE USB PEN DRIVE When in standby mode, the sterilizer display remains dark and the On the homepage tap >...
Administrator CONTENTS ADD A USER This section deals with the following subjects: On the homepage tap > > User management Traceability options Tap your user name. Hide/Unhide a cycle Enter the PIN and tap to confirm. User management FUNCTION AVAILABILITY WHO CAN MANAGE USERS AND RESET THEIR PIN Only a user with administrator rights can create and delete users and reset the PIN code of a user to "0000".
Page 35
Administrator Tap the text box: a keyboard If desired, tap to give the appears. administrator authority to the new user. to confirm: the PIN of the new user is set to "0000" and a confirmation message appears. and then to go back to the previous page.
Page 36
Administrator RESET A USER PIN On the homepage tap > > Tap your user name. Enter the PIN and tap to confirm. Tap the user name you want to delete. to confirm. and the user name for which you want to reset the PIN. to confirm: ...
Administrator Tap the information to be requested Traceability options to the users at the beginning and at the end of the cycle. FUNCTION AVAILABILITY If you want the user to check the WHO CAN SET THE TRACEABILITY OPTIONS load and release it as valid at the Only a user with administrator rights can set the traceability end of the cycle, tap options.
Page 38
Administrator HIDE/UNHIDE A CYCLE On the homepage tap > > > Tap your user name. Enter your PIN and tap confirm. to hide a cycle from the homepage. to unhide a cycle from the homepage. to confirm and go back to the previous page.
Managing printers On the homepage tap > > CONTENTS This section deals with the following subjects: Tap the model of the printer to use. Printer selection (optional) to confirm and go back to Label printer selection (optional) the previous page. Label printer usage (optional) Label content description Printer selection (optional)
Page 40
Managing printers connected to the sterilizer, while the shared label printer is SELECT A SHARED LABEL PRINTER connected to another sterilizer in the network. Ensure the sterilizer to which the printer is physically connected is SELECT AND CALIBRATE A LOCAL LABEL PRINTER ON and no cycle is running.
Managing printers From the sterilizer from which the From the sterilizer to which the printer is not physically connected, printer is connected, confirm the tap homepage > > > printer sharing. again to print a test label. Tap the text box and enter the IP address previously noted.
Page 42
Managing printers AUTOMATIC PRINTING OPTION SET THE MANUAL LABEL PRINTING The automatic printing option permits to automatically print a The manual printing option permits the user at the beginning of a preset number of labels after a successful sterilization cycle. The sterilization cycle to set manually the number of labels to print.
Page 43
Managing printers DISABLE THE LABEL PRINTING If the label printing is disabled, no label can be printed at the end of a sterilization cycle. On the homepage tap > > Activate Disabled. to confirm and go back to the previous page. LISA ...
Managing printers Label content description STRUCTURE Part Description Sterilizer model Serial number Software release Traceability code (alphanumerical and bar code) Released Depending on the traceability settings, this field may contain one of the following elements: the user who released the cycle the user who started the cycle the sterilizer ID Cycle...
Sterilizer tests CONTENTS This section deals with the following subjects: Sterilizer performance tests Bowie and Dick test Helix test Vacuum test Sterilizer performance tests TESTS THAT CAN BE PERFORMED ON THE STERILIZER Test Purpose Reference Bowie and Dick test Validate the sterilizer performance for textile load sterilization. See "Bowie and Dick test"...
Page 46
Sterilizer tests PURPOSE OF THE TEST The test is used to validate the sterilizer performance for textile load sterilization. DESCRIPTION It consists of several sheets of paper wrapped in a small packet with a chemical heat-sensitive indicator sheet in the middle. The colour assumed by this indicator sheet at the end of the sterilization cycle gives the result of the test.
Page 47
Sterilizer tests On the homepage tap Helix-B&D test. To set the duration of the Plateau/Sterilization phase and other settings, tap and enter your credentials if required: the chamber door locks. Wait until the end of the test and tap OPEN: the chamber door unlocks. Enter your credentials if required.
Page 48
Sterilizer tests INTERPRET THE TEST RESULT Test Indicator What happened What to do next passed The entire surface of the indicator sheet has changed colour. Certain ares of the indicator sheet have not changed colour since there was an air Repeat the test.
Sterilizer tests Helix test CAUTION! Follow local/national guidelines on the frequency of testing. PURPOSE OF THE TEST The test is used to validate the sterilizer performance for hollow items. DESCRIPTION It consists of a 1.5 m long tube open on one side and closed with a capsule containing a chemical indicator strip on the other side. The colour assumed by this indicator strip at the end of the sterilization cycle gives the result of the test.
Page 50
Sterilizer tests Place the tube with the capsule in the center of a tray in the lowest rack position and close the chamber door. On the homepage tap Helix-B&D test. To set the duration of the Plateau/Sterilization phase and other settings, tap and enter your credentials if required: the chamber door locks.
Sterilizer tests Open the chamber door, extract the tray using the tray holder and take the tube. CAUTION! Risk of burns. The test pack is very hot at the end of the cycle. Wear appropriate PPE (e.g. gloves). Unscrew the tube capsule and remove the indicator strip. Check the change in colour.
Page 52
Sterilizer tests PURPOSE OF THE TEST The test is used to validate the sterilizer performance in terms of: efficiency of the vacuum pump tightness of the pneumatic circuit DESCRIPTION It consists of a vacuum phase, followed by a stabilization period of 5 minutes and a testing period of 10 minutes. The internal pressure is monitored during the testing period.
Page 53
Sterilizer tests WHAT TO DO WHEN THE TEST FAILED Check, clean or replace the door gasket. Clean the chamber face side and the chamber filter. Repeat the Vacuum test. See "Carry out the test" on the previous page. If the test fails repeatedly, call technical service. LISA ...
Sterilization cycles CONTENTS CLEANING THE INSTRUMENTS This section deals with the following subjects: Clean all instruments thoroughly prior to sterilization. If possible, clean instruments immediately after use; always follow the Load maintenance and preparation instrument manufacturer ‘s instructions. Remove all traces of Prepare the sterilizer disinfectants and detergents.
Page 55
Sterilization cycles Follow these requirements: Load type Placement Items made from different On separate trays or wrapped/pouched Load type Placement materials (stainless steel, Hinged instruments (e.g., In open position carbon steel, aluminum, etc.) forceps, extraction pliers, etc.) Instruments manufactured Place paper among them and the trays to avoid Tubes Place tubes on a tray allowing the ends to remain from carbon steel...
Sterilization cycles Turn the sterilizer switch ON: after the initialization the Prepare the sterilizer homepage appears. WARNINGS GENERAL RECOMMENDATIONS Notice: Use only distilled or demineralized water (see "Feed water Follow these recommendations to obtain the most from the drying: specifications (EN 13060)" on page 118 for technical Ensure the paper side of the sterilization bags faces up, and requirements).
Sterilization cycles Check the cycle requirements. Sterilization cycle management Check the icon in the top left corner of the page to know the ECO DRY RUN A STERILIZATION CYCLE IMMEDIATELY mode assigned to the cycle. On the homepage tap the desired cycle.
Page 58
Sterilization cycles Wait the end of the sterilization. Tap SET THE STERILIZATION CYCLE START to view the cycle parameters in You may schedule the start of the sterilization cycles at a certain real time. See "View the cycle date and time (e.g., if you want to load the sterilizer in the evening parameters"...
Page 59
Sterilization cycles To change the start time, tap Start to lock the door and start cycle at. the countdown for the current cycle. Tap the time or the date: a settings Note: You can decide to start the cycle page opens. immediately or stop the countdown at any time.
Page 60
Sterilization cycles To program the sterilizer proceed as follows: Tap the date/time to set the start of the cycle. Load the chamber and close the chamber door. On the homepage tap > > > to add a cycle to the list above.
Page 61
Sterilization cycles DELETE A CYCLE FROM A PROGRAMMED SEQUENCE SET THE DRYING TIME For each ECO DRY mode, the drying time is automatically adjusted On the homepage tap > > to the total amount of load and cannot be modified. To set a new >...
Page 62
Sterilization cycles VIEW THE CYCLE PARAMETERS to increase the minutes or decrease them. You can check the real time cycle parameters or the cycle Note: for the minimum value of the parameters at the end of the cycle. Following is an example: drying time for each cycle see "Sterilization cycles"...
Page 63
Sterilization cycles When a cycle is successfully finished, the "Cycle completed" STERILIZATION CYCLE PAGE message appears on the screen. To end the cycle: Following are the information displayed while a cycle is running: to view the cycle Part Description summary or tap to view the cycle parameters.
Page 64
Sterilization cycles STOP A STERILIZATION CYCLE to abort the stop command. The cycle continues programmed. WARNING! You can stop the cycle at any time. Instruments must not be considered sterile if this occurs before the DRY to abort the cycle: the phase.
Sterilization cycles MESSAGES OF A STOPPED STERILIZATION CYCLE Check the message. See "Messages of a stopped Following are the messages: sterilization cycle" below. Load not sterile: Do not use items on patients! Drying interrupted: The load might be wet. Wet items are for to view the cycle immediate use only! parameters.
Page 66
Sterilization cycles WHAT HAPPENS WITH UNSAVED CYCLES PRINT OR SAVE A CYCLE REPORT ON THE USB PEN DRIVE If for any reason (e.g. USB memory full, USB pen drive disconnected, On the homepage tap > > etc.) some cycles cannot be saved, no alert is shown. If still stored in memory, the unsaved cycles will be copied in a working USB pen Scroll the list and tap the desired drive connected to the sterilizer as soon as a new cycle starts.
Page 67
Sterilization cycles to print the report, or tap to save the report on the USB pen drive. PRINT LABELS FOR A SPECIFIC CYCLE to print traceability labels for the selected cycle. On the homepage tap > > Scroll the list and tap the desired sterilization cycle: the report opens.
Page 68
Sterilization cycles to increase or SET THE REMOTE FOLDER FOR SAVING THE REPORTS decrease the number of label to be To activate the remote storage and set the necessary parameters printed. do the following: to save the set number for On the homepage tap >...
Page 69
Sterilization cycles TEST THE DATA STORAGE Not mandatory. Enter the domain name. Note: The test function is available only if the remote data storage is enabled. See "Set the remote folder for saving the reports" on the previous to require the page.
Page 70
Sterilization cycles SAVE ALL THE CYCLE REPORTS IN A REMOTE FOLDER Note: The save all function is available only if the remote data storage is enabled. See "Set the remote folder for saving the reports" on page 68. Only the last 400 cycles in HTML and 50 cycles in SCL in the sterilizer memory can be saved in the remote folder.
Page 71
Sterilization cycles CYCLE REPORT STRUCTURE Data Description Following the structure of a cycle report: Sterilizer model Sterilizer serial number Software rev. Software revision number Sterilizer Name Surgery – practice – doctor name Cycle Name of the executed cycle Number Cycle counter Sterilizat.
Maintenance CAUTION! Before accessing the chamber and the connected CONTENTS parts, be sure that the sterilizer is cold. This section deals with the following subjects: Notice: Follow the instructions in this chapter when carrying out any Warnings for maintenance operations maintenance on the sterilizer.
Page 74
Maintenance If you can not replace the consumable immediately, the sterilizer Frequency Cycles Operation will operate anyway but the message will appear again some cycles later. Replace the bacteriological filter. See "400-cycle Yearly maintenance" on page 81. to see an animated Replace the dust ...
Page 75
Maintenance REPLACE THE CONSUMABLE BEFORE THE MAINTENANCE DUE to see an animated DATE replacement procedure. If you replace the consumables before the request of replacement When you have replaced the appears, you should manually reset the counters through the consumable tap to confirm: the following procedure.
Maintenance Monthly or 50-cycle maintenance CLEANING THE DOOR GASKET AND THE CHAMBER FACE SIDE Proceed as follows: Clean the seal seat and the chamber face side with a damp, lint-free cloth moistened with clean water. Notice: Do not use abrasive products, cutting tools or sharp objects. If you use a detergent solution, be careful not to get in contact with the plastic body of the front cover.
Page 77
Maintenance CLEANING THE CHAMBER AND THE CHAMBER ACCESSORIES Proceed as follows: Remove the trays and the chamber rack. Clean the chamber with a damp sponge and a mild detergent solution paying attention not to bend or damage the temperature probe inside the sterilizer chamber.
Page 80
Maintenance Lock the filter cap by turning it clockwise. CLEANING THE EXTERNAL SURFACES OF THE STERILIZER Proceed as follows: Clean all external sterilizer covers with a slightly damp cloth moistened with water. Notice: Never use disinfectants, detergents or abrasive products. LISA ...
Maintenance 400-cycle maintenance REPLACING THE BACTERIOLOGICAL FILTER A video animation is available on https://video.wh.com/en_global/dental-faq. Notice: If you replace this consumable before the maintenance due date you have to reset the cycle counter. See "Replace the consumable before the maintenance due date" on page 75. Proceed as follows: Open the service door.
Page 82
Maintenance REPLACING THE DUST FILTER A video animation is available on https://video.wh.com/en_global/dental-faq. Notice: If you replace this consumable before the maintenance due date you have to reset the cycle counter. See "Replace the consumable before the maintenance due date" on page 75. Proceed as follows: Pull out the dust filter handle from underneath the sterilizer.
Maintenance Slide the handle back into its original position. 800-cycle or biannual maintenance SEQUENCE OF PROCEDURES TO CLEAN THE WATER TANKS To clean the water tanks, proceed as follows: 1. "Prepare the sterilizer for cleaning the water tanks" on the next page. 2.
Page 84
Maintenance PREPARE THE STERILIZER FOR CLEANING THE WATER TANKS A video animation is available on https://video.wh.com/en_global/dental-faq. Proceed as follows: Switch OFF the sterilizer and disconnect the mains cable. Completely drain both water tanks (see "Draining the used and clean water tank" on page ...
Page 85
Maintenance ACCESS TO THE WATER TANKS A video animation is available on https://video.wh.com/en_global/dental-faq. Proceed as follows: Lift the water tank cover. Tap with your fingers on the rubber membrane to remove any condensate. Remove the rubber membrane; clean and dry it. LISA ...
Page 86
Maintenance CLEAN THE WATER TANKS A video animation is available on https://video.wh.com/en_global/dental-faq. Notice: Do not touch the water level sensors. If misplaced or misaligned from their original position, the operation of the sterilizer could be impaired. Proceed as follows: Clean the internal tank surfaces with a soft sponge and a mild detergent solution. Notice: Never use disinfectants, strong detergents or abrasive products.
Maintenance 800-cycle maintenance REPLACING THE DOOR GASKET A video animation is available on https://video.wh.com/en_global/dental-faq. Notice: If you replace this consumable before the maintenance due date you have to reset the cycle counter. See "Replace the consumable before the maintenance due date" on page 75. Proceed as follows: Fully open the chamber door.
Page 89
Maintenance Insert the new seal and press first up and down. Press left and right and then the entire seal circumference to ensure its perfect placement. Notice: A steam discharge can damage the sterilizer plastic parts. Ensure the seal does not stick out. Wipe any residual water and run a Vacuum and Helix test to check for perfect tightness of the seal.
Maintenance 4000 cycle or five-year maintenance Element Replace Clean Check Internal parts, with particular care for the condenser fins and the main board GENERAL CHECK AND SERVICE REQUIRED Notice: Regular service is imperative to ensure continuous and Pneumatic connections effective operation of the sterilizer. Electrical connections A general check and service should be carried out every 4000 Temperature and pressure calibration...
Maintenance Extraordinary maintenance DRAINING THE USED AND CLEAN WATER TANK If you left accidentally the tanks full for more than seven days or if you plan not to use the sterilizer for at least seven days, you have to drain the tanks.
Maintenance Disposal DISPOSAL RESPONSIBILITY Separate the various components according to the materials they are made of. Drop the sterilizer with a company that specializes on the recycling of related products. Do not abandon the sterilizer in unsecured places. Always refer to current/applicable laws and rules in the country of use. The same instructions apply to disposal of all used consumable parts.
Diagnostics CONTENTS This section deals with the following subjects: Errors Troubleshooting Emergency door opening Errors CHECKS AND ACTIONS Notice: For any error not listed in this table, call technical service. Code Description Actions Load cannot be considered sterile. See "End of a sterilization cycle" on page 63 Repeat the cycle.
Page 94
Diagnostics Code Description Actions Wait before opening the chamber door. Allow the sterilization chamber to cool down. See error "13x to 16x" Repeat the cycle. below. If the problem persists, call service. 13x to 16x Check water level in the clean water tank. Reset the safety thermostat.. Repeat the cycle.
Page 95
Diagnostics Code Description Actions Check the door gasket. Clean or replace it if necessary. Repeat the cycle. If the problem persists, call service. Clean the chamber face side. Clean the chamber filter. Check if chamber filter is properly locked in the cap. Check the load does not exceed the MAXIMUM WEIGHT LIMITS.
Page 96
Diagnostics Message/Alert Description Action Non-conform water The clean water quality is bad (conductivity You may run a cycle but the water must be replaced soon, otherwise the unit will between 15 and 50 μS/cm). automatically lock-out to prevent damage. Unacceptable water The clean water quality is very bad (conductivity Running a cycle is inhibited to prevent damage.
Page 97
Diagnostics Message/Alert Description Action Door Gasket replacement is due. These messages advise that one consumable Replace the consumable and tap to reset the counter (See "Maintenance" on must be replaced. page 73). Have you replaced the door gasket? If you don't replace the consumable, press In this case, you may still use the sterilizer but the message will appear again after Bact.
Diagnostics When the OPEN button appears, tap Troubleshooting it to unlock the door. Confirm the opening of the door. MANAGING ERRORS If during a sterilization cycle an error occurs do the following: Notice: Water could be present in the chamber when opening the door: Wait until the end of the reset prevent spilling (e.g., place a towel phase.
Page 99
Diagnostics ERROR PAGE During the sterilization cycle, the sterilizer is continuously monitored by a control system. If an anomaly is detected, the cycle is aborted automatically, and the sterilizer starts a reset phase. The following page appears: Part Description Current sterilization cycle Error number, See "Errors"...
Page 100
Diagnostics RESET THE SAFETY THERMOSTAT The sterilizer is fitted with a safety thermostat to prevent it from overheating. If the safety thermostat operates because of too high temperatures, the error 240 or a timeout error is displayed. The thermostat must be reset manually. Proceed as follows: Switch the sterilizer OFF and remove the mains cable.
Page 102
Diagnostics Insert the dust filter back into its original position. Connect the mains cable and place the sterilizer back into its original position. Switch the sterilizer ON. Wait for the sterilizer to finish the error reset phase and follow the instructions on the display.
Page 103
Diagnostics TROUBLESHOOTING TABLE Note: If your problem is not resolved, call your authorized service provider. Notice: Before sending the sterilizer for technical service, remove the mains cable, empty both water tanks and use the original or appropriate packaging. Problem Possible cause Solutions The sterilizer remains switched The mains switch or network circuit breaker is OFF.
Page 104
Diagnostics Problem Possible cause Solutions Corrosion or spots on Tap water on instruments when placed in the Ensure that instruments are dry before they are placed in the sterilizer. instruments. sterilizer. Use of water of poor quality or water containing Drain both water tanks.
Page 105
Diagnostics Problem Possible cause Solutions When the sterilizer is connected Water fill system not connected. Connect the water fill system to the sterilizer. See "Water quality" on page 118. to an automated water supply When the water fill system attempted to fill the Since water tank filling is attempted only once in-between cycle execution, this event system: there is no clean water in tank, water was temporarily unavailable.
Diagnostics Emergency door opening WARNING ABOUT OPENING THE DOOR IN EMERGENCY WARNING! High pressure. Risk of explosion, jet of hot steam, sudden opening of the door. Carry out the following procedure only if necessary and only when NO RESIDUAL PRESSURE IS IN THE CHAMBER. Any attempt to open the door while the unit is still hot or under pressure could expose the operator and the surrounding personnel to serious risk.
Page 107
Diagnostics Extract the dust filter and remove the auxiliary cable loom. Plug two batteries into the connectors. Firmly open the service door. Holding the service door pulled, plug the plastic connector into the socket behind the bacteriological filter. As soon as the door opens, unplug the plastic connector to prevent system overload and consequent damage.
Technical data CONTENTS This section deals with the following subjects: Sterilization cycles Sterilization cycle phases Technical data Recommendations for validation Diagrams Water quality Accessories, spare parts, consumables Authorized W&H service partners Sterilization cycles WARNINGS For your safety and for the safety of your patients: WARNING! Never process objects different from those specified in the cycle program table and never exceed the maximum load weight limits specified in it as this could impair the sterilization process.
Page 109
Technical data STANDARD STERILIZATION CYCLES AVAILABLE There are four sterilization cycles available, all of them complying with the European Standard EN13060: three B-type cycles one S-type cycle Cycle Cycle name Purpose type B Universal For all your general items like hand instruments, forceps, etc. B Extended Features an extended sterilization time, if this is required for your load or mandated in your country.
Page 110
Technical data Sterilization cycles B Universal 134 B Extended 134 B Universal 121 S Fast 134 Minimum duration of the drying phase (set by the user) Load type All unwrapped, bagged, single/double wrapped items: Unwrapped items: Solid Solid Hollow A (Narrow lumen) Hollow B (simple Hollow B (simple hollow item) hollow item)
Page 111
Technical data MAXIMUM LOAD FOR INSTRUMENTS Note: The load given includes the trays, the containers and everything is put into the chamber, with the sole exclusion of the tray rack. Instruments Bagged Unwrapped Porous LISA 17 LISA 22 LISA 17 LISA 22 LISA 17 LISA 22...
Technical data Sterilization cycle phases COMMON LEGEND OF THE STERILIZATION CYCLE PHASES Following is the description of the sterilization phases. Code Description Pre-heating of the sterilizer. This phase is not considered a part of the cycle. PV1 - PV3 Vacuum pulse (removal of air from the sterilizer chamber/load) PV1 - PV6 PP1 - PP2 Pressure pulse (steam generation)
Page 114
Technical data TYPE S STERILIZATION CYCLE PHASES The S Fast 134 cycle is specifically designed to sterilize unwrapped instruments, for immediate use on patients, not requiring a complete drying. Thus, the drying phase of this cycle is short, making this cycle the fastest available. LISA ...
Technical data Technical data INSTALLATION REQUIREMENTS Working temperature From +5 °C to +40 °C (from +41 °F to +104 °F) Working relative humidity Max. RH 80% up to 31 °C (88 °F), linearly decreasing to 50% at 40 WATER SUPPLY SYSTEM °C (104 °F) Fitting Backflow preventing device...
Technical data Recommendations for validation Usable space LISA 17: 11.5 l/W: 195 mm/H: 195 mm/D: 297 mm (3 gal/W: 7.7’’/H: 7.7’’/D: 11.7’’) LISA 22: 15 l/W: 195 mm/H: 195 mm/D: 390 mm (4 gal/W: 7.7’’/H: 7.7’’/D: 15.4’’) TEST VALIDATION POINTS Bacteriological filter 0.3 µm LISA sterilizers can be validated in accordance to EN17665-1.
Technical data Water quality Contaminants/minerals/qualities Value/Specification Appearance colorless, clean, free from sediment FEED WATER SPECIFICATIONS (EN 13060) Hardness < 0.02 mmol/l Notice: Do not use rust inhibitor or any other agents in the clean No chemicals or additives must be added to the Chemical additives water tank.
Technical data Accessories, spare parts, consumables Part Picture Part number Optional chamber rack for 3 F523020X LIST OF ACCESSORIES AND SPARE PARTS cassettes /containers* for LISA Part Picture Part number Usable space - Cassette size (mm): Standard chamber rack for 3 F523008X 205 x 35 x 300 cassettes /containers* for LISA...
Page 120
Technical data Part Part Picture Part Picture Part number number Optional chamber rack for 4 F523012X Optional chamber rack for 2 F523016X cassettes/containers* for LISA 17 cassettes /containers* for LISA Usable space - Cassette size (mm): Usable space - Cassette size 190 x 32 x 300 (mm): 210 x 32 x 300...
Page 121
Technical data Part Part Picture Part Picture Part number number Mains cable U38011XX Multidem C27 - water demineralizer 19723112 Ethernet cable, 3 m A801500X USB pen drive V000004X Osmo - water demineralizer (osmotic principle) 19723100 Cycle report printer 19721108 Model: S'Print Safety bracket kit X051125X Label printer LisaSafe (label printer only)
Technical data CONSUMABLES Part Picture Part When replace it number Bacteriological filter W322400X Every 400 cycles Door gasket F460504X Every 800 cycles Dust filter F364502X Every 400 cycles 400/800 cycle X050326X Refer to each single consumable kit component above Components: 1 door gasket 2 bacteriological filters...
Documentation forms CONTENTS Question Answer This section deals with the following subjects: Completeness of the Instructions for Use W&H installation check-list Were all sections of the Instructions for Use of the sterilizer Yes No covered and explained during the in-service? Helix test documentation form Workplace suitability Is the allocated countertop for the sterilizer levelled and flat?
Page 124
Documentation forms Question Answer Question Answer 17 Have you shown the Head of the clinic/practice the maintenance Yes No 28 Have you executed a B Universal 134 cycle program with the tray Yes No program and procedures? rack and trays inserted? 18 Have you shown the Head of the clinic/practice how to use all of Yes No 29 Are all connections to the sterilizer well positioned and plugged...
