1. Locate Assembly Packet - A packet is included with vacuum and includes
two (2) 2-part bolts and two (2) cord hooks. Also included is an extra drive-
belt.
2. Attach Lower / Upper Handle - Slide the upper handle (D) and the lower
handle (E) together so the holes for the handle bolts are aligned and the
slots in the handle are positioned as shown in Figure 2. Insert a 2-part bolt
(A) in the center of the handle and fasten tightly. Position the assembled
handle (D/E) so it curves toward the operator. Push the handle into the
handle socket (F) at the rear of the cleaner. Align the holes, insert the other
2-part bolt (A) and tighten.
DependaVac 12
(Part # 135-1350-20)
Thank you for choosing Sterling's DependaVac 12 upright vacuum. This commercial
appliance is well constructed and should provide you with years of professional service
if you take the time to read this manual. For your information, this vacuum was pro-
tectively packed to prevent possible damage in transit. Should damage occur, please
notify the transporting carrier immediately for loss and/or claim. It is also important to
learn the steps for proper assembly, operation and maintenance. It will also make the
product easier to use and save you even more time and money. We suggest you keep
this manual at hand for future reference. We stand behind this product and can help
anytime with a knowledgeable and dedicated customer service sta . Please contact us
anytime at 844-822-7787 or SterlingNA.com
Unpackaging theVacuum - When the machine is delivered, carefully inspect the ship-
ping carton and the machine for damage. If damage is evident, save the shipping carton
so that it can be inspected. Contact Sterling Customer Service Department so a freight
claim can be led.
Machine Assembly
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sterling DependaVac 12
Summary of Contents for Sterling DependaVac 12
- Page 1 Unpackaging theVacuum - When the machine is delivered, carefully inspect the ship- ping carton and the machine for damage. If damage is evident, save the shipping carton so that it can be inspected. Contact Sterling Customer Service Department so a freight claim can be led.
- Page 2 3. Attach Upper Cord Hook - Pull the spring (G) on the cord upward toward the top of the handle. Insert the lower half of the spring (G) into the upper cord hook (B). Make sure slots in handle are positioned properly (Figure 2). Place inner tab into slot as shown in (1) and press hook around handle (2), snapping opposite inner tab into place (3) (Figure 4).
- Page 3 Maintenance Brush Roll Belt Replacement CAUTION! Belt and pulley become hot during normal use. The belt should be checked regularly to ensure proper cleaning. Replace belt if it appears stretched, cracked or is slipping. Remove bottom chrome plate by turning the two cam locks on each side. Remove worn belt from drive motor pulley. Remove brush roll from base, and slide o worn belt.
- Page 4 Important Safety Instructions When using an electrical vacuum, basic safety precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING YOUR VACUUM CLEANER WARNING: To reduce the risk of re, electrical shock, or injury: Do not leave appliance when plugged in. Unplug from outlet when not in use and before servicing. Do not expose to rain.
- Page 5 IMPORTANTES CONSIGNES DE SECURITE L’utilisation d’un appareil électrique demande certaines précautions: LIRE TOUTES LES INSTRUCTIONS AVANT DE FAIRE FONCTIONNER CET APPAREIL AVERTISSEMENT: Pour réduire les risques d’incendie, de choc életrique ou de blessure: Ne pas laisser l’appareil sans surveillance lorsqu’il est branché. De brancher lorsque l’appariel n’est pas utilisé et avant l’entretien. Ne brancher qu’à...
