www.covesmart.com Touchscreen Panel INSTALLATION + LOCATION PANEL BUTTONS STATUS BAR ICONS PANEL DISPLAY SYSTEM SOUNDS ALARMS USER PASSCODES MESSAGES + ALERTS HISTORY EXIT + TRANSMISSION DELAY SYSTEM INFO SENSORS SYSTEM/SENSOR TESTS...
INSTALLATION + LOCATION Your panel serves as the heart of your system. It should be placed in a central location within your home. The panel must be within 5 feet of an electrical outlet does not that does not have a ground fault circuit interrupter (GFCI) button and is not controlled by a switch.
PANEL BUTTONS HOME BUTTON Button LED Status A motion sensor was triggered EMERGENCY CALL BUTTON Button LED Emergency Call Status STATUS BAR ICONS BATTERY BATTERY NO CELLULAR BATTERY FULL CHARGING CONNECTION MESSAGES AC POWER NO AC MESSAGE CONNECTED POWER...
PANEL DISPLAY ADJUST SCREEN BRIGHTNESS ADJUST THE DISPLAY TIMEOUT TIME CLEAN SCREEN TURN LED BUTTONS ON/OFF SYSTEM SOUNDS ADJUST THE PANEL VOLUME TURN CHIME SOUND ON/OFF (FOR ALL SENSORS) ADJUST THE TOUCH SCREEN VOLUME TURN VOICE SOUND ON/OFF (FOR ALL SENSORS) CHANGE THE VOICE GENDER (MALE/FEMALE) TEST THE SIREN...
TEST SENSOR SWINGER SHUTDOWN CROSS ZONING technical support at 1-855-268-3669. SYSTEM/SENSOR TESTS once every month. All system tests can be COMPLETE SENSOR SIGNAL TEST technical support at 1-855-268-3669 if any tested sensor fails to reach verified status. SENSOR SIGNAL WALK TEST technical support at 1-855-268-3669 if any tested sensor fails.
Page 14
Motion Sensors SEE PAGE 9 FOR REFERENCE TO: INSTALLATION + LOCATION Sensors have a 90º field of view and detect motion up to 45 feet away. FEET CORNER WALL PLACEMENT PLACEMENT...
Page 15
ENTRY DELAY Motion Sensors have a 0 second entry delay. It is recommended to keep the ACTIVE IN STAY MODE Motion Sensors is protecting an area that is rarely used. To SENSITIVITY Motion Sensors are set to high sensitivity to prevent false alarms. To change DETECTING PETS Motion Sensors will not detect a body under 55 pounds.
Page 16
Window Sensors SEE PAGE 9 FOR REFERENCE TO: INSTALLATION + LOCATION 1/2” Max Contact Magnet Sensor 1/2” apart and align the two semi-circles...
Page 17
Operable Window 1/2” Max TESTING SENSOR CHANGING BATTERIES Window Sensors require two CR2032 batteries. Open the contact sensor (large piece) by Use a screwdriver to slide the batteries out from under the black padded circles. After replacing the batteries it is recommended that you test the sensor to make sure it works properly.
Page 18
Door Sensors SEE PAGE 9 FOR REFERENCE TO: INSTALLATION + LOCATION 1/2” Max Contact Magnet Sensor 1/2” apart and align the two semi-circles SWINGING DOOR Correct Correct Incorrect...
Page 19
SLIDING DOOR DOUBLE DOOR Near the top on the least used door (or secured door), place the contact sensor with the alignment mark facing the other door. Place the magnet on the door or the frame between the two doors. ENTRY DELAY Sensors have a 30 second entry delay to allow the user time to disarm TESTING SENSOR...
Page 20
Medical Pendants SEE PAGE 9 FOR REFERENCE TO: TRIGGERING PENDANT TESTING PENDANT CHANGING BATTERIES Medical Pendants require one CR2032 battery. To change the battery, remove the bottom cover by using a screwdriver to remove the 4 screws. Use a screwdriver to slide the batteries out from under the black padded circles.
Page 21
Key Remotes SEE PAGE 9 FOR REFERENCE TO: TRIGGERING REMOTE AWAY BUTTON STAY BUTTON DISARM BUTTON SOS BUTTON DISABLE/ENABLE SOS BUTTON CHANGING BATTERIES the back using a screwdriver and remove the cover. Use a screwdriver to slide the batteries out from under the black padded circles.
Page 22
Smoke/Heat/Freeze Detectors SEE PAGE 9 FOR REFERENCE TO: INSTALLATION + LOCATION Detector on the ceiling or wall. Consult the device manufacturer guide 4” 4” 4” min 12” max Ceiling Mount Wall Mount...
Page 23
DISABLE/ENABLE SENSOR ZONES Detector allows you to turn basic functionality on and off. For TESTING SENSOR Detector’s connection to the panel, tap Settings > Sensors > CHANGING BATTERIES Detectors require three AAA batteries. Twist the cover After replacing the batteries it is recommended that you test the sensor to make sure it works properly.
Page 24
Carbon Monoxide Detectors SEE PAGE 9 FOR REFERENCE TO: INSTALLATION + LOCATION Carbon Monoxide Detector on the ceiling or wall. Consult the device manufacturer guide included in your package for detailed installation, testing, and maintenance instructions. Once you determined where to place your sensor, remove the adhesive backing, place the detector and press firmly for 30 seconds.
Page 25
TESTING SENSOR To test a Carbon Monoxide Detector’s connection to the panel, tap Settings > Smoke > Carbon Monoxide > (select sensor) > Edit > Test Sensor. After replacing the batteries it is recommended that you test the sensor to make sure it works properly. CHANGING BATTERIES Carbon Monoxide Detectors require one CR123A battery.
Page 26
Smoke + Carbon Monoxide Detectors SEE PAGE 9 FOR REFERENCE TO: TESTING SENSOR Detector’s CHANGING BATTERIES Detector Detector Detector After replacing the batteries it is recommended that you test the sensor to make sure it works properly. FIRE ALARM VERIFICATION To turn a Smoke + Carbon Monoxide Detector’s fire alarm verification setting on or off, tap Settings >...
Page 27
Flood/Freeze Sensors SEE PAGE 9 FOR REFERENCE TO: INSTALLATION + LOCATION Sensor TESTING SENSOR Sensor’s CHANGING BATTERIES The Flood/Freeze Sensor requires one CR2450 battery. Remove the rubber feet on Sensor the bottom of the sensor, remove the screws and the casing, and remove the old battery. Be sure to have the + side of the battery facing towards you.
Page 28
www.covesmart.com Glass Break Detectors SEE PAGE 9 FOR REFERENCE TO: - Adding a sensor - Renaming a sensor - Removing a sensor - Bypassing a sensor long term INSTALLATION + LOCATION Please refer to the diagrams below demonstrating where to place the Glass Please refer to the diagrams below demonstrating where to place the Glass Please refer to the diagrams below demonstrating where to place the Glass...
Page 29
(855) 268-3669 TESTING SENSOR To test a Glass Break Detector’s connection to the panel, tap Settings > Sensors > Glass Break > (select sensor) > Test > Test Sensor. Press Test button briefly (1/2 second) until the Green LED turns ON. Immediately release the test button.
Page 33
Cove Smart, LLC is not an insurer. This product is neither insurance nor a guarantee that such an event will be prevented, and users should protect themselves with proper insurance.
Page 34
WASTE + ELECTRICAL + ELECTRONIC EQUIPEMENT DIRECTIVE (WEEE) NOTICE The symbol shown below is on the product or on its packaging which indicates that this product must not be disposed of with other waste. Instead, it is the user’s responsibility to dispose of the user’s waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment.
Page 35
(1) year. This does not cover batteries. This warranty extends only to customers who buy direct from Cove Smart, LLC or through an approved distribution partner. There are no obligations or liabilities on the part of Cove Smart, LLC for consequential damages arising out of or in connection with use or performance of this product or other indirect damages with respect to loss of property, revenue, or profit;...
