Summary of Contents for Immarsat Wideye FX 250
- Page 8 Description Order Code FX 250 Terminal FX25-9TE00-01 Description Order Code FX 500 Terminal FX50-9TE00-01 Description Order Code FX 500 FleetBroadband Primary Handset FX50-0PH00-02 FX 250 FleetBroadband Primary Handset FX25-0PH00-01 Ethernet Cable (1.5m) FX50-0CE02-01 Telephone Cord (1.8m) FX50-0CT02-01 Handset Wall Mount Cradle SG5000/WMC Power Cable (3m) FX50-0CP03-02...
- Page 20 Ambient Temperature -25ºC to +55ºC Relative Humidity Up to 95% at +40ºC.
- Page 24 Pin No. Signal Pin No. Signal Pin 5 Pin 2 Pin 2 Pin 3 Pin 3 Pin 5...
- Page 25 GPIO Port Pin Signal Name Description of Signal Color Code GPIO-1 RES_1 Reserve line 1 Black GPIO-2 Ground line Brown GPIO-3 LED_ENABLE To enable LED ON GPIO-4 REM_ON_OFF Remote ON / OFF Orange GPIO-5 BUZZER Buzzer Yellow GPIO-6 Ground line Green GPIO-7 TX_OFF...
- Page 27 LED Name Status Meaning TERMINAL Steady Amber BDU is powering up. Steady Green BDU has powered up successfully. Steady Red BDU detects failure. Blinking Amber Switching OFF BDU. ANTENNA Steady Amber ADU is powering up. Steady Red ADU is not OK/Error. Blinking Amber ADU is calibrating.
