2-TIER WRITING DESK
MS46-020-096-10
RECOMMENDED NUMBER OF PEOPLE FOR ASSEMBLY : 1
ESTIMATED ASSEMBLY TIME: 1 HOUR
14 STEPS TO COMPLETE
CALL OUR TOLL FREE NUMBER 1-800-729-1569 FOR FURTHER ASSISTANCE.
•
•
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
DO NOT ALLOW CHILDREN TO CLIMB OR PLAY ON THE UNIT.
•
CLEAN THE PRODUCT WITH YOUR FAVORITE FURNITURE POLISH AND A SOFT CLOTH.
•
•
DO NOT USE HARSH CHEMICALS OR ABRASIVE CLEANERS.
MOVE YOUR NEW FURNITURE CAREFULLY WITH TWO PEOPLE. NEVER PUSH OR DRAG THE UNIT.
•
Huisen Furniture (Longnan) Co., Ltd.
Designed in the USA |Made in China
TOP SHELVE MAXIMUM LOAD
13 LBS (5.91 KG)
SHELVE MAXIMUM LOAD
40 LBS (18.18 KG)
We are available to assist you Monday - Friday from 9:00 am - 5:00 pm
Eastern Standard Time. 1-800-729-1569 |USA only.
DO NOT RETURN THE PRODUCT TO THE
STORE.
INDIVIDUAL STORES DO NOT STOCK
PARTS.
FOR MISSING OR DAMAGED PARTS CALL
1-800-729-1569.
PARTS WILL BE SHIPPED FREE OF CHARGE.
FOR PROMPT, RELIABLE SERVICE, PLEASE
HAVE YOUR ASSEMBLY MANUAL READY.
LOT NUMBER______________
DATE OF PURCHASE___/___/___
3D GUIDED INTERACTIVE ASSEMBLY
INSTRUCTIONS CAN BE FOUND IN BILT
DOWNLOAD THE FREE APP
