dipo INDUCTION BKP26-A User Manual

Hide thumbs

Advertisement

Table of Contents

CK26-A/CK35-A/CK226-A/CK235-A/2CK235-A
User's Manual
BKP118-A/BKPW11-A
BKP26-A/BKP18-A/BKPW-A
BK118-A/BKW11-A
BK26-A/BK35-A/BKW-A
CK118-A/CK218-A
TCK26-A/TCK35-A
Read this manual,
before using the Range.
Theory
Cautions
Specifications
How to use
Emergency Measures
Installation
Cookware for Induction 23P
Warranty Card
Caution
4P
5~9P
10~16P
17~20P
21P
22P
24P

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BKP26-A and is the answer not in the manual?

Questions and answers

Related Manuals for dipo INDUCTION BKP26-A

Summary of Contents for dipo INDUCTION BKP26-A

  • Page 1 User’s Manual BKP118-A/BKPW11-A BKP26-A/BKP18-A/BKPW-A BK118-A/BKW11-A BK26-A/BK35-A/BKW-A CK118-A/CK218-A CK26-A/CK35-A/CK226-A/CK235-A/2CK235-A TCK26-A/TCK35-A Caution Read this manual, before using the Range. Theory Cautions 5~9P Specifications 10~16P How to use 17~20P Emergency Measures Installation Cookware for Induction 23P Warranty Card...
  • Page 2 INSTRUCTIONS and SAFEGUARDS 1. Use an individual 208-240 VOLT, 20 AMPERE electrical socket.(BKW- A,BKPW-A,BKW11-A,BKPW11-A: 5 AMPERE) 2. DO NOT block the air-intake panel as blocking may overheat the unit. 3. Use pans 12cm (4.75”) or larger in diameter. Please refer to Page 23 for a list of suitable and unsuitable pans.
  • Page 3 9. Close supervision is necessary when the induction range is used or near children. 10. DO NOT operate the induction range if it has been damaged in any manner or if the unit malfunctions. Return the unit to the nearest authorized service facility for examination or repair.
  • Page 4 Theory of DIPO Induction Induction Range When the magnetic flux created at the coil passes through the bottom of the pot placed on the top plate, eddy current is generated around the flux. This eddy current then is transformed into heat by the resistant element of the pan and heats up the pan for cooking.
  • Page 5 Warnings / Cautions Contents Indicates the possibility of severe injury or death . Warning Indicates the possibility of injury or damage to Caution the equipment. S Y M B O L General Don’t touch! Important! prohibition Be careful of Use of fire strictly Electric shock! prohibited!

  • Page 6: Warnings & Cautions

    Warnings / Cautions Warning 1. Use the specified NEMA outlet. ** If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. Don’t touch the power plug or Don't use a damaged power plug.
  • Page 7 Warnings / Cautions Warning This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 8 Warnings / Cautions Warning Don’t spray water on the range. Don’t touch the hob surface, after using range. It will be hot. *It can cause a fire or electric shock. Metallic objects such as knives, Don’t use sharp tools, when you forks, spoons and lids should not clean this appliance.
  • Page 9 Warnings / Cautions Warning When not in use, unplug the unit. Do not block the exhaust vents. Use vessels of the proper size. Do not heat an empty pan or cook *Use pans with a flat bottom and a diameter dry ingredients.

  • Page 10: Specifications

    Specifications MODEL: BKP26-A/BKP18-A/BKPW-A Ceramic Top Plate Display Ventilation Power Touch Power Button UP/Down Button Model BKP26-A BKP18-A BKPW-A Voltage AC 208 - 240V, 60Hz Watt 2600W 1800W 400W Weight 9 lbs Size 14 5/8” x 11 ¾” x 3 ¼”...
  • Page 11 Specifications MODEL: BKP118-A / BKPW11-A Ceramic Top Plate Display Ventilation Power Touch Control Button Button Model BKP118-A BKPW11-A Voltage AC 100 - 120V, 60Hz Watt 1800W 350W Weight 9 lbs Size 14 5/8” x 11 ¾” x 3 ¼” 9 Steps Heat Level 7 Steps (Warm : 1, 2)
  • Page 12 Specifications MODEL: BK118-A / BKW11-A Ventilation Ceramic Top Plate Display Timer Button Control Knob Start Button Power Min,Sec Button Button Mode Button Model BKW11-A BK118-A Voltage AC 100 - 120V, 60Hz Watt 1800W 350W Weight 9 lbs Size 14 5/8” x 11 ¾” x 3 ¼” 10 Steps Heat Level 7 Steps...
  • Page 13 Specifications MODEL: BK26-A / BK35-A / BKW-A Ventilation Ceramic Top Plate Display Timer Button Control Knob Start Button Power Min,Sec Button Button Mode Button Model BK26-A BK35-A BKW-A Voltage AC 208 - 240V, 60Hz Watt 2600W 3500W 400W 11 lbs Weight Size 14 5/8”...
  • Page 14 Specifications MODEL: CK118-A/CK26-A/CK35-A Ceramic Top Ventilation Plate Display Power Button Power Up/Down Buttons Air Filter Start/Stop Button Model CK118-A CK26-A CK35-A AC 100- Voltage AC 208-240V 60Hz 120V 60Hz Watt 3500W 1800W 2600W 15 lbs 15 lbs 15 lbs Weight 18”...
  • Page 15 Specifications MODEL: CK218-A/CK226-A/CK235-A/2CK235-A Ceramic Top Ventilation Plate Display Power UP/Down Power Air Filter Buttons Button Start/Stop Button Model CK218-A CK235-A 2CK235-A CK226-A Voltage AC 100-120V AC 208-240V 60Hz 60Hz Watt 3600W 5200W 7000W 6100W Weight 29 lbs 29 lbs 29 lbs 29 lbs 27.5”...
  • Page 16 Specifications MODEL: TCK26-A / TCK35-A Ventilation Display Ceramic Top Plate Control Knob Timer/Mode Power Button Button Air Filter Start Button Model TCK26-A TCK35-A Voltage AC 208-240V 60Hz Watt 2600W 3500W 19 lbs 19 lbs Weight 18” x 14 ½” x 4 ½” Size 10 Steps (Warm : 7 Steps) Heat Level...

  • Page 17: How To Use

    ◆ If you want to control Heat Level, press the Up or Down button. You can control levels from 1 to 9 steps. 4. Heat Levels Model Cook Warm BKP26-A 3 ~ 9 Steps Step 1 (95 BKP118-A Step 2 (140 BKP18-A...
  • Page 18 How To Use BK-A Series Start Button Timer Power Button Min/Sec Control Knob Button Button 1. Insert power plug. ◆ Four lighted dots on the display indicates that the unit is plugged in. 2. Place a vessel on the Ceramic Top Plate. ◆...
  • Page 19 How To Use CK-A / 2CK-A Series Power Button Display Start Button Window Buttons to control Heat Level 1. Insert the power plug. Two lighted dots on the display indicates that the unit is plugged in ◆ 2. Place a vessel on the Ceramic Top Plate. ◆...
  • Page 20 How To Use TCK-A Series Mode Start Timer Power Button Button Button Min/Sec Control Knob Button Button 1. Insert the power plug. ◆ Four lighted dots on the display indicates that the unit is plugged in. 2. Place a vessel on the Ceramic Top Plate. ◆...

  • Page 21: Cleaning And Troubleshooting

    Cleaning & Troubleshooting Cleaning 1. Cleaning ceramic top plate and control panel ◆ Light stains : Clean the top plate with a soft damp cloth. ◆ Severe stains : Use a soft cloth with a mild cleaning agent or detergent. ◆...

  • Page 22: Installation

    Installation BKP-A/BK-A Model Series Cut an opening as shown below. For fan ventilation, 4” space is 4’’ required in the front and back side of product. Hole Size Left-Right Hole Size Front-Rear Hole Size 14 1/4” 11 7/8” 11 3/8” 14 1/4”...
  • Page 23 A pot for Induction Pots and Pans for Induction 1. Bottom of Pan should be flat. Size of Bottom : from 4 ¾” to 9 ½” in diameter 4.7’’ ~ 9.4’’ (CK-A Series & TCK-A Series : Max 12” (Max. 12’’) in diameter) 2.

  • Page 24: Warranty

    Warranty Limited Warranty Statement All commercial cooking equipment manufactured by DIPO is warranted against defects in materials and workmanship for a period of one year from the date of invoice. Accessories, cookware and other incidental non-range items sold by DIPO are warranted against defects in materials and workmanship for a period of 90 days.
  • Page 25 Warranty This warranty is void if it is determined upon inspection by DIPO or one it’s Authorized agents that the equipment has been modified, misused, misapplied, improperly installed, or damaged in transit or by fire, flood or act of God. Broken Glass-Ceramic tops are considered abuse and are NOT covered.
  • Page 26 MEMO BKP/BK 설치 가이드...
  • Page 27 MEMO BKP/BK 설치 가이드...
  • Page 28 TEL : 82-31-793-5895 FAX : 82-31-793-5862 E-MAIL : dipoelec@naver.com www.dipoelec.com DIPO Induction USA TEL : 937-552-7138 FAX : 866-497-8351 E-MAIL : info@dipousa.com www.dipousa.com Rm402, Hanamventure Center, 523 Changu-dong, Hanam-si, Gyeonggi-do 465-120, Korea...
