Step #1
Place T-nut on backside of center hole in main harness.
(This is easiest on a flat surface!)
Place bolt and washer in front side of leg harness center hole.
Hand tighten for now, keep loose.
M6 Bolt
X 10
Washer
T-nut
Tool
Loctite
Step #2
Place on motorcycle in desired location.
Revolve legs until they are at desired angle.
Note what lean angle the lean selector arrow is closest to.
M6 Bolt/washer
Right
Leg harness
Apply a small drop of included
Loctite to the bolts
Main or Center
harness
T-nut
T-nut
Step #3
Install remaining hardware in leg harness bolt holes and
corresponding main harness holes. (This is easiest on a flat surface)
Hand tighten only, until all hardware has been installed.
Finally tighten hardware using provided key.
Before riding, tighten all straps/bolts and check periodically.
Reckless 80 Revolver
Assembly instructions
M6 Bolt/washer
Left
Leg harness
Advertisement
Related Manuals for MOSKO MOTO Reckless 80 Revolver
Summary of Contents for MOSKO MOTO Reckless 80 Revolver
- Page 1 Reckless 80 Revolver Step #1 Place T-nut on backside of center hole in main harness. Assembly instructions (This is easiest on a flat surface!) Place bolt and washer in front side of leg harness center hole. Hand tighten for now, keep loose.
- Page 2 Reckless 80 Revolver Installation instructions ...now pass the leg straps through passenger peg braces or other available frame location. Begin to tighten and adjust all mounting straps equally Pass the rear mounting straps through until desired position and tightness is achieved.
- Page 3 Heat Shield Placement Hose clamp Heat Shield location that protects the bag and your motorcycle’s plastics from melting. It is important to check after each use that your heat shield is located properly. Failure to do so may result in severe product/bike damage that is not covered under warranty.
