Seicane S6905 2001-2008 Mercedes Benz G Class W463
aftermarket car stereo head unit upgrade installation replacement
instruction
Seicane S6905 2001-2008 Mercedes Benz G Class W463 head unit after installation
Please note: This unit can be suitable for the following cars which are also with the
same installation steps as follows.
2002-2008 Mercedes Benz E Class W211 E200, E220, E230, E240, E270, E280, E300,
E320, E350, E420, E500, E550, E55, E63
2001-2008 Mercedes Benz G Class W463 G550, G500, G400, G320, G270, G55
2004-2011 Mercedes Benz CLS Class W219 CLS350 CLS500 CLS55
Advertisement
Table of Contents
Related Manuals for Seicane S6905
Summary of Contents for Seicane S6905
- Page 1 Seicane S6905 2001-2008 Mercedes Benz G Class W463 head unit after installation Please note: This unit can be suitable for the following cars which are also with the same installation steps as follows.
- Page 2 4. For your convenience, here’s the recommended tools for removal and installation from Seicane, please check for more details: https://www.seicane.com/car-dvd-dismantling-device-srd-400 2001-2008 Mercedes Benz G Class W463 head unit installation guide 1.
- Page 3 4. Remove the two screws marked with red arrows and pull out the original radio. 5. Check all the accessories for the new Seicane head unit. 6. Connect the cables in the package. a. Connect with the power cable in the car.
- Page 4 Connect CAN-TX. 7. Connect the harnesses to the back of the new Seicane head unit. 8. Remove the baffle-plate under the assistant driver seat, connect the CAN-H, CAN-L cable (green)③ with the CAN-BUS socket marked in the picture.
- Page 5 9. Pry the decoration panel beside the driver's seat, change fuse from 5A TO 10A. 10. Remove the screws for fastening the car pc in the left of the trunk. 11. Find the amplifier in the left of the trunk and remove the four screws marked with red arrows.
- Page 6 14. Turn on the new Seicane head unit to have a careful check if everything works well. If yes, all the installation is done. If not, please check if all the cables are connected correctly. Attention: We suggest you arrange a professional to install it. If you have any questions about installation, please send us photos about your original car's plugs, we can make a wiring diagram for your car.
