Summary of Contents for FSR T6
- Page 1 PDF provided by Conference Room AV FSR HV-T6-FLEX-1000 Table Box with 3.5" Touch Screen Control & Matrix Switcher...
- Page 2 5.50 PRE-CUT 6.00" DIA. HOLE IN TABLE UNDERSIDE VIEW OF SHROUD INSTALL DESIRED BRACKETS INTO THE 'T6' SUB-ASS'Y. DROP THE SUB-ASS'Y INTO THE HOLE IN THE TABLE (COVER ORIENTATION IS PRE-SET BY THE SHROUD INSTALLATION). (7) CABLE INSTALL CLAMP SHROUD TO UNDERSIDE...
