Summary of Contents for FSR IPS-A223S
- Page 1 IPS-A223S / IPS-A511S SERIES UNBALANCED STEREO AUDIO TO BALANCED OUTPUT IPS INSERTS OPERATING GUIDE 43938 LIT1262B...
- Page 2 FSR or replace the unit without charge for parts or labor. Shipping charges to the factory or repair station must be prepaid by the owner, return-shipping charges, via UPS / FedEx ground, will be paid by FSR. Inc.
-
Page 3: Technical Specifications
AUDIO Gain +6 dB balanced or unbalanced ±0.2dB into 600Ω load The IPS-A223S and IPS-A511S inserts are the latest addition to the FSR Frequency response 20 Hz to 20 kHz ±0.25 dB IPS product line. Either unit will convert an unbalanced line level input THD + Noise 0.02% @ 1 kHz, 7V RMS... - Page 4 TO A STEREO BALANCED PREAMP INPUT The IPS-A223S and IPS-A511S inserts have a mounting standard SIGNAL SIGNAL INSTALL JUMPER that will fi t any FSR IPS series wall plates or IPS Rack Mount Frame. FOR 3 WIRE FLOW FLOW INSTALLATION (2) SHIELD Mounting screws are included for both products.
