- Page 1 R207 Smart IOT Controller Smart Home Controller Manual For IPK Version 0.0.0.59 and above...
-
Page 2: Table Of Contents
5. Set up R207 ............................. 4 5.1 Connect to the device ............................ 4 5.2 Find the IP address of R207 .......................... 4 5.3 Log in to the management interface of R207 ....................5 5.4 Status ................................6 5.5 Internet Settings ............................6 5.6 Management .............................. -
Page 3: Introduction
1. Introduction R207 is a high reliable IoT gateway for smart home. R207 can communicate with the LoRa network and act as a gateway in the LoRa network. It can be automatically added and configured. It is the control core of the Netvox smart home network. -
Page 4: Installation And Preparation
4. Installation and Preparation 4.1 R207 Port Instruction 4.2 Hardware Connection Use the network cable to connect the R207 to the home router. If there is a camera, users can connect the camera under the same router to operate. 4.3 Power on Plug a DC 5V 1.5A power adapter to R207. -
Page 5: Restore To Factory Setting
5. Set up R207 5.1 Connect to the device Please connect the R207 LAN port to your computer with a network cable, power on the R207, and turn on the DHCP service in the router. 5.2 Find the IP address of R207 Log in to your router's settings interface with a browser. -
Page 6: Log In To The Management Interface Of R207
5.3 Log in to the management interface of R207 Open the web browser, enter the IP address of R207 found in [5.2 Find the IP Address of R207] in the URL address bar, and then press the Enter key or click the go button in the address bar to access... -
Page 7: Status
5.4 Status Select the [Status] module. On the left page of the module, you can see five sub-function modules including status, statistics, management, quick settings, and operation modules. 5.5 Internet Settings (1) Select the [Internet Settings] module. The module mainly has LAN interface settings and WAN interface settings. -
Page 8: Management
5.6 Management The management module of R207 is mainly composed of statistics, time zone setting, denial of service, system log, firmware upgrade, save/load settings and password. (1) Statistics (This page shows the count of sending and receiving packets for wireless and Ethernet... - Page 9 NTP Server3: time.windows.com Make sure that the current time of the gateway is the same as the local time. Otherwise, the timestamp verification will fails and it can not be connected to the cloud. (3) Denial of service (a hacker tries to block the legitimate user of the service to use the service), as shown in the following figure, the general user does not have to set it, and the setting may be incorrect, which may result in the network being inaccessible.
- Page 10 below 5) Upgrade the firmware (you can upgrade the access point firmware to the new version on this page) as shown below...
- Page 11 (6) Save/reload settings (you can save the current settings to the file on this page or reload the settings from the previously saved files) as shown below: (7) The password setting is as follows. You can modify the login password of the R207 setting interface, including user license, administrator license, and vendor license. Please remember to set...
-
Page 12: Smart Home Module Setup Instructions
6. Smart Home Module Setup Instructions Log in to the R207 webpage and click [Smart Home] on the left navigation menu to enter the smart home system settings page. This page contains device list, device management, client user management, upgrade communication software, backup and restore user data, data import, and communication settings. - Page 13 Click [Detail] to view the detailed information of the device, and click [Delete] to delete the corresponding device. Click [Detail] to enter the device details interface, you can view the basic information of the device, as shown in the screen shot below.
- Page 14 6.2 Device Management Click Device Management on the left page to display the detailed function page, which includes two functions: Open Screening and Add Device. Enter the IEEE address of the device to be added, click [Add], and then perform the screening operation.
- Page 15 6.4 Upgrade communication software Click the upgrade communication software on the left page and the following detailed function interface appears. Click the [View] button, select the upgrade file, and then click the [Upgrade] button to upgrade the communication software. Note: During the upgrade of the LoRa module software, ensure that the gateway cannot be powered off.
- Page 16 6.5 Backup restore user data Click the backup on the left page to restore the user data, and the following detailed function interface appears. On this page, you can choose to back up data to the cloud, restore the data to the cloud according to the selected backup (divided into automatic and manual backup) date, and delete the backup data.
- Page 17 6.6 Data import Click on the data import on the left page and the following detailed function interface appears. Click the [View] button, select the "Intelligent Scene Control Scheme" file to be imported, and then press the [Update] button to update the intelligent scenario control scheme. 6.7 Communication settings Click on the communication settings on the left page and the following detailed function interface appears.
-
Page 18: Important Maintenance Instructions
Enable/disable timestamp verification: The factory defaults the timestamp verification. When the gateway time is incorrectly deviated from the local time by 10 minutes, the timestamp verification timeout will occur. Callback permission verification: The factory defaults to check the permission verification, the user does not have to modify this content.
