- Page 1 ZigBee - Measurement and Switch Socket User Manual Measurement and Switch Socket Model: Z809A Firmware: V3.5 Hardware: V1.2...
-
Page 2: Table Of Contents
5-5. Reset Power Consumption Summation......................5 5-6. Restore to Factory Setting..........................5 5-7. Power Metering...............................5 5-8. Report Configuration for Developer Only......................6 6. Home Automation Clusters for Z809A........................8 7. Netvox App Control Interface..........................9 8. Loading property..............................12 9. Important Maintenance Instructions........................13... -
Page 3: Introduction
1. Introduction Netvox Z809A, a ZigBee measurement and switch socket, acts as a Router Device in ZigBee network. It performs the On/Off controlling feature. Users are able to wirelessly control the switch through paired soft On/Off button or paired remote controller. Users could also monitor the power consumptions such as current/ voltage/ power/ energy through Netvox ZiG-BUTLER application. -
Page 4: Specification
Socket/Plug Selection 3. Specification Fully IEEE 802.15.4 compliant Utilizes 2.4GHz ISM band; up to 16 channels Power supply: 100~240VAC; 50/60Hz Power consumption: 15mA@220V Resistive load: 250VAC/ 16A Inductive load: 220VAC/ 8A Monitoring range 100mA to 16A with ±1% accuracy ... -
Page 5: Installation
5-1. Join the ZigBee Network After Z809A is turned on (all indicators flash once), it will search for an existing ZigBee network and send a request to join the network automatically. While Z809A is under the coverage from a coordinator or a router whose permit-join feature is enabled, Z809A will be permitted to join the network. -
Page 6: Control
5-4. Control A. Remote Control Users are able to use the device which is bound with Z809A to control it. While the switch is ON, the On/Off Status Indicator shows green. While the switch is OFF, the On/Off Status Indicator shows red. -
Page 7: Report Configuration For Developer Only
Report command and then it will report according to report setting. After powering on, Z809A will detect battery voltage, if the device report has been previously configured, it will issue 1 or 2 reports within 1-60 seconds randomly on the device, and thereafter it will report according to the configuration. -
Page 8: Home Automation Clusters For Z809A
A cluster is a set of related attributes and commands which are grouped together to provide a specific function. A simple example of a cluster would be the On/Off cluster which defines how an on/off switch behaves. This table lists the clusters which are supported by Z809A. 1.End Point(s)：0x01 2.Device ID：Mains Power Outlet (0009) -
Page 9: Netvox App Control Interface
8-bit 0x00 –0xff Read 0x01 Enumeration only 7. Netvox App Control Interface 1. After joining in Netvox App system, device IEEE address will show up in device management interface. Select “Mains Power Outlet”; there is only an EP as below:... - Page 10 2. Select “Mains Power Outlet” to enter setting interface. Click “bind device” as below: 3. Click “Power Status” as below:...
-
Page 11: Loading Property
4. Click “About Devices” to show information as below: Loading property Overload Rated Load Max. Load with Max. Inductive Max. Load with Protection with LEDs （AC） Load（cosφ=0.4） Electric Motors Auto Power ** Remark** **Remark** Cutoff Type ： 16A/250V ～ Type ： power less 13A/250V ～... -
Page 12: Important Maintenance Instructions
Load Protection: The current is over 16A → it will be off-load in 2 seconds After it is off-load, the Bit1 (Current OverLoad) of the parameter ACAlarmsMask will be checked: Bit1 (Current OverLoad) is 1 → it sends the alarm message ... - Page 13 FCC Statement: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
