Highnovate BELLA Manual

A REMOTE CONTROLLED ANCHOR
GENERAL INSTRUCTIONS
Use only standard gear, checked by a
certified person.
Use the product only after proper training
from a certified guide.
Do not use the product without reading the
instructions.
Check the product functionality before
every use. If there is any doubt, do not use
it until consulting with the manufacturer.
Anchor the product to a firm structure using a
telescopic pole or directly to a standard anchor
point. Use a carabiner to connect the "head" of the
Bella to the anchor point.Make sure the anchor is
strong enough to support the loads that might occur
during a dynamic fall and that it is stable, structural
element.
When using a pole – lift the pole up to the anchoring point,
while the throw bag and rope adapter stays on the ground.
Make sure the hook which the head is connected to is firmly
attached to a part of the structure. (beam or rail). When using
other methods of anchoring ( for example using a webbing or
sling wrapped around a structural element (beam or rail)) after
anchoring and connecting the head, throw the bag so the tag
line will reach the ground. Lower the rope adapter to the
ground.
Connect a rope/ladder/rescue kit to be lifted to the anchoring
point using a carabiner to the pin.
Pull the tagline until the rope adapter and
the rope connected to it will reach the
head. Make sure the rope adapter got to its
place inside the head and created an
anchor.
BELLA
TAG LINE
METHODE OF USE
Anchoring using a webbing
Clipping a carabiner helps to avoid
obstacles
KIT PARTS
HEAD
PIN / ROPE
THROW
Anchoring using a hook and pole
Throwing the bag
after connecting the
head to the anchor
Rope connection using a
carabiner
pulling the rope to Final position of the
connect the parts anchor
ADAPTER
BAG
