Adaptive MaxStream XPress Replacement Instructions

MaxStream® XPress™ Wireless Ethernet Bridge
Overview
These instructions apply to replacing MaxStream XPress Ethernet Bridge modems for AlphaEclipse Excite™ 23mm
pitch signs. The XPress Ethernet Bridge modems are used for wireless communication between the ooh!Media
computer and the Excite sign. The MASTER modem is connected to the ooh!Media computer or to your network and
sends messages to your Excite sign The modem connected to your Excite sign receives messages from the MASTER
modem.
Contents of the XPress Ethernet Bridge box:
Adaptive Micro Systems • 7840 North 86th Street • Milwaukee, WI 53224 USA • 414-357-2020 • 414-357-2029 (fax) • http://www.adaptivedisplays.com
Adaptive is a registered trademark of Adaptive Micro Systems. AlphaEclipse and AlphaEclipse Excite are trademarks of Adaptive Micro Systems.
January 26, 2007
Replacement Instructions
(pn 1199121701SP)
© Copyright 2007 Adaptive Micro Systems LLC. All rights reserved.
All other brand and product names are trademarks or registered trademarks of their respective companies.
Quantity
XPress Ethernet Bridge RF modem.
The modem labeled MASTER will be connected to your
2
computer, the other modem will be connected to the sign.
6 VDC/80-240VAC power adapters.
One power adapter is used with the modem connected to
2
your computer (or network). The other power adapter is not
used.
PoE (Power over Ethernet) adapters.
One PoE adapter is used to connect your computer, the
2
modem connected to your computer, and power. The other
PoE is not used.
Half-wave, 2.5 dBi, dipole antennas w/RPTNC connector.
2
Both antennas are used.
CAT5e outdoor cables, 30 feet.
2
Description
1199610401A
