Contents 1. Basic specifications .................. 5 2. Product design ..................6 3. Safety requirements .................. 8 4. Installation of card collector..............9 4.1. Required equipment ................9 4.2. Installation of card collector ............. 9 6. Inversion of the LED panel board ............27 7. - Page 4 List of abbreviations – power supply – access control system – operating device – normally connected – normally opened Software FW v1.52 Praktika K-01 card collector...
-
Page 5: Basic Specifications
1. Basic specifications Table 1. Basic specifications Specification Value Dimensions (WхHхL), mm 200х1045х200 Weight, kg Temperature range,, ºС: +1…+40 - operation +1…+40 - transportation and storage Atmosphere relative humidity, no more than % Supply voltage, V: - nominal 8…18 - working Average current in standby mode * A Maximal current *, A 155х40х55... -
Page 6: Product Design
PS, OD and ACS cables are connected. The hatch includes a card storage device. The lower part of housing is equipped with a hole for cables inlet. Overall dimensions of the card collector are shown in Fig. 2 Praktika K-01 card collector... - Page 7 Fig 2. Dimensions ATTENTION (!) Card reader is not included in the delivery set. Customer can choose reader model suitable for the existing system. The reader is mounted on a universal adjustable bracket, located under the top cover of the card collector. This solution provides maximum flexibility for installation and connection of the card reader.
-
Page 8: Safety Requirements
Set the power supply inside the card reader housing, as this could lead to electric shock to persons; Set the card collector other than in dry and heated places; Apply chemically aggressive cleaning detergents as pastes and liquids. Praktika K-01 card collector... -
Page 9: Installation Of Card Collector
4. Installation of card collector CAUTION: The card collector should be installed securely to avoid swinging and (or) overthrow during operation. In case of installation on the low strength floors - take action to strengthen the floor at the installation site. Before verify of operability of the card reader carefully read this section of the Regulations. - Page 10 3) in the lower plate of the card collector. 3 Hole Fig 3. Linkage dimension 4.2.5. Open the box, unpack the product and check for completeness. 4.2.6. Route PS, OD and ACS cables into cable conduit. Praktika K-01 card collector...
- Page 11 4.2.7. Set the housing of card collector on the prepared area (Fig. 3). Open the hatch using the wrench. Bring the PS, OD and ACS cables inside the card collector housing. Secure the cables with cable ties. 4.2.8. Align together the holes in the housing of card collector and anchors in the floor.
- Page 13 5.2. Slide the LED panel to the stop in the direction indicated in Fig. 5. Carefully lift the panel. 5.3. Remove two M4 screws (8, Fig. 6) and remove the universal bracket for readers (2, Fig. 6). 5.4. Disassemble the reader, removing the M3 screw (6, Fig. 6), and set its lower part (1, Fig.
- Page 14 Fig.6 Installation of proximity card reader Инструкция по монтажу...
-
Page 15: Inversion Of The Led Panel Board
Fig. 7 Recommended option to install proximity card reader 5.8. CAREFULLY (!) set the LED panel in its original position. Tighten the M4 screw and set the decorative cover. CAUTION! When installing the LED panel in its original position, make sure that wires of optical sensors mounted on the guiding bars for cards will not be damaged by other elements. - Page 16 6.2. Disconnect the cable connector (1, fig. 8) on the LED panel board (2, Figure 8). 6.3. Remove four M3 nuts (3, Fig. 8), remove lockwashers and washers. 6.4. Rotate the board by 180º. 6.5. Assemble in reverse order. 6.6. Install the LED panel in its original position, following the instructions in Section 5.8.
-
Page 17: Connecting Card Collector
7. Connecting card collector Connection of PS, OD and ACS cables is made with the use of card collector board. In order to do it open the hatch of the housing using the wrench. Fig. 1 shows the location of the board in card reader housing. Fig. - Page 18 (+ 12V) and (GND) contacts on the board respectively. When the card collector board is powered, D11 LED indicator will turn on. Make sure that cable is connected securely. 7.2. Connecting operating device Connection of OD to the card collector is performed with the use of two contact sets: "Let Go"...
- Page 19 Pass Ok and GND), confirming the passage, is received, the card collector switches into standby mode and can collect the next card. For these reasons, the connection of this contact set is essential to the system capacity 7.3. Connecting ACS controller Block diagrams of ACS controller with the use of card collector are shown in Appendix 1.
- Page 20 generates a signal to the OD via "Let Go" contact set (see. article 7.2.1) and to ACS via "Card Inside" contact set. In such case a green arrow indicator on the LED panel turns on. 7.3.2. "Free Pass-GND" contact set Free Pass and GND contacts.
- Page 21 Press and hold BUT1 button until the card collector provides 1 audio signal, indicating that it is switched to pulse mode of operation; Set mode is saved when power is turned off. In order to return to the pulse mode repeat the above sequence. 7.3.3.
- Page 22 Appendix 1. Block diagram of ACS using the card reader Fig. 10 Block diagram №1 Fig. 10 shows the most common connection circuit of card collector. OD can be controlled either by ACS controller or by the card collector directly, that is why connections 1* and 2* are drawn by dotted lines. This scheme features two readers.
- Page 23 Fig.11 Block diagram №2 Fig. 11shows a more advanced but also a more high-cost circuit connection. The advantage of this scheme is that it uses only one reader installed in the card collector. Wiegand interface provides a possibility to connect several identical ACS controllers to one reader in parallel. ACS controllers are connected to different inputs of the card collector.
- Page 24 Fig. 12 Block diagram №3 The block diagram #3 can be considered to be a logical development of the block diagram #2. It reduces the cost of installed system. For this purpose the controller with two output signals to one input of a reader (i.e., the controller can distinguish the guest cards and permanent cards transmitting a signal to the corresponding output) is used.
- Page 25 Appendix 2: Location of mounting holes in relation to the overall dimensions of the card collector Fig. 13. Location of mounting holes in relation to the overall dimensions of the card collector Installation guidelines...
- Page 26 Инструкция по монтажу...
- Page 28 OOO "Vozrozdenie" 192289 Saint Petersburg Sofiyskaya st., 66 Tel./fax +7 (812) 366 15 94 www.oxgard.com info@oxgard.com...
