- Page 1 ASSEMBLY INSTRUCTIONS Style # CR1439/CR1438/CR1437/CR1436 Coat Rack with Storage Page 1 of 12...
- Page 2 Pre-Assembly: Please read all instructions before beginning assembly. Save all packing materials until assembly is complete to avoid accidentally discarding smaller parts or hardware. Prepare a soft clean surface for assembly. To guard against color transfer, do not assemble directly on carpet, flooring, or other sensitive coverings. Instruction of Using Cam Lock ...
- Page 3 Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean padded surface. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures. Using the incorrect hardware will cause damage.
- Page 4 Hardware List (A). Quantity Of 20 Bolt (B). Quantity Spring washers (C). Quantity Of 20 Flat washers (D). Quantity Of 1 Allen Wrench (E). Quantity Of 16 Screw (F). Quantity Of 8 Metal Hook (G). Quantity Of 1 Knob with bolt Assembly Tool Required: Phillips Screwdriver (Not Included).
- Page 5 Assembly Instructions Step 1: Connect the two Posts (1) together as above shown. Assemble other Posts (2), (3) and (4) in the same way. Page 5 of 12...
- Page 6 Assembly Instructions Step 2: Assemble Posts (1), (2), (3), (4) to Top Panel (5) and Shelf w/Drawer (6) using Bolts (A) with Spring Washers (B) & Flat Washers (C) by Allen Wrench (D). Note: Please do not tighten bolts until all of them are attached. Page 6 of 12...
- Page 7 Assembly Instructions Step 3: Assemble shelf (7) to Posts (1),(2),(3),(4) using bolts (A) with spring washers (B) & flat washers(C) by Allen Wrench. Page 7 of 12...
- Page 8 Assembly Instructions Step 4: Assemble Bottom Posts (8) to Shelf (7) using Bolts (A) with Spring Washers (B)& Flat Washers (C) by Allen Wrench. Page 8 of 12...
- Page 9 Assembly Instructions Step 5: Assemble the Bottom Panel (9) to Bottom Legs (8) using Bolts (A) with Spring Washer(B) and Flat Washers (C). Note: Please do not tighten bolts until all of them are attached. Page 9 of 12...
- Page 10 Assembly Instructions Step 6: Attach hooks (F) to Top Panel (5) using Screws (E). Page 10 of 12...
- Page 11 Assembly Instructions Step 7: Attach Knob (G) to the front of drawer using included bolt. Page 11 of 12...
- Page 12 Assembly Instructions Page 12 of 12...
