2007 - 2018 Jeep Wrangler JK Radio Mount Kit
Bill of Materials
Part Number
M56281-BK
JK Radio Mount Switch Panel
RM25R-U/V
Dual Band Radio, 25W
DB-RM
Dual Band Radio Antenna
NMO-MT-U
Antenna Mount
KU80011
Rocker Switch, 20 A, Blue
KU80012
Rocker Switch, 20 A, Green
KU80013
Rocker Switch, 20 A, Amber
KU80014
Rocker Switch, 20 A, Red
BU71060
Hardware
KJ71060BK
KJ71060BK
Description
Quantity
1
1
1
1
1
1
1
1
1
Page 1
www.Daystarweb.com
Tech Support Contact Info
Tech@DaystarWeb.com
Phone: 623.907.0081
841 South 71
Required Tools
Trim Removal Tools
Metric Tool Set
Screwdriver Set
Drill
Drill Bit Set
Instructions Sheet INS71060
2018 Daystar Products International
Fax: 623.907.0088
st
Avenue
Phoenix, AZ 85043
Version: 00
INS71060
Advertisement
Related Manuals for DayStar KJ71060BK
Summary of Contents for DayStar KJ71060BK
- Page 1 Rocker Switch, 20 A, Green Metric Tool Set Screwdriver Set KU80013 Rocker Switch, 20 A, Amber Drill KU80014 Rocker Switch, 20 A, Red Drill Bit Set BU71060 Hardware Instructions Sheet INS71060 2018 Daystar Products International Version: 00 KJ71060BK Page 1 INS71060...
- Page 2 Pre-Install Procedure 1. Remove roof panels a. Disengage locks and remove each panel KJ71060BK Page 2 INS71060...
- Page 3 3. Firmly press mount against upper dash panel and 2. Locate desired position of radio mount on upper mark location of holes dash panel a. Recommend positioning at the center, above the rear view mirror, between the driver and passenger visors KJ71060BK Page 3 INS71060...
- Page 4 6. Install radio into corresponding hole on radio mount a. Insert radio and fasten using supplied hardware 5. Bore out holes with an adequate drill and bit a. Verify supplied screws fit and securely hold mount to upper dash panel KJ71060BK Page 4 INS71060...
- Page 5 7. Install rocker switches into corresponding holes on radio mount a. Slide each switch in until they lock into place KJ71060BK Page 5 INS71060...
- Page 6 8. Assemble antenna mount bracket 9. Install antenna mount bracket onto driver side window frame KJ71060BK Page 6 INS71060...
- Page 7 10. Install radio antenna KJ71060BK Page 7 INS71060...
- Page 8 11. Run antenna cable along door jam and behind dash panels 12. Install radio electrical wiring a. Run positive from positive battery terminal b. Ground negative to the body of the vehicle KJ71060BK Page 8 INS71060...
- Page 9 13. Reinstall upper dash panel 14. Connect cables and wiring to corresponding a. Leave cables hanging out behind upper dash connectors behind radio panel KJ71060BK Page 9 INS71060...
- Page 10 15. Install radio mount a. Tuck cables behind radio mount b. Align radio mount and upper dash panel holes, and fasten using supplied screws KJ71060BK Page 10 INS71060...
- Page 11 Be sure not to drill all the way through the visor, if that is the desired position of the microphone mount b. Verify supplied screws fit and securely hold mount to surface KJ71060BK Page 11 INS71060...
- Page 12 18. Insert microphone onto holder KJ71060BK Page 12 INS71060...
- Page 13 Check the kit hardware against the parts list. Be sure you have all the needed parts and understand where they go. If anything is missing, do not proceed with the installation, Call Daystar Products to obtain needed items. 1977...
