- Page 1 TECHNICAL PASSPORT INSTALLATION and OPERATION MANUAL For SOLAR COLLECTORS - РК SL AL With full plate aluminum absorber model: ......serial number: ........version 01/SRCC-2-2011/...
-
Page 2: Table Of Contents
TECHNICAL PASSPORT INSTALLATION and OPERATION MANUAL Table of contents page Safety instructions Requirements to solar collector installation place 1.1.1 Instructions to collector installer 1.1.2. Instructions to installation user MAIN TECHNICAL SPECIFICATIONS Description Transport. Handling Collector protection against lightning COLLECTORS INTERCONNECTING IN A FIELD WITH 20m² Pressure loss Recommended angle of installation of the collector Collector protection against frost... -
Page 3: Safety Instructions
TECHNICAL PASSPORT INSTALLATION and OPERATION MANUAL Safety instructions 1.1. Requirements to solar collector installation place This manual contains important information for the safe and correct installation, start-up and trouble-free operation and maintenance of the solar collector. The solar collector can be used to produce domestic hot water and support of space heating system only in the manner described in this manual. -
Page 4: Instructions To Installation User
TECHNICAL PASSPORT INSTALLATION and OPERATION MANUAL DANGER of slipping, fall. In most cases, collectors are installed in hardly accessible and dangerous places. We recommend that installation and service maintenance be carried out by authorized service technicians observing all safety measures. 1.1.2. -
Page 5: Main Technical Specifications
TECHNICAL PASSPORT INSTALLATION and OPERATION MANUAL 2. MAIN TECHNICAL SPECIFICATIONS Table. 1 ABSORBING DIMENSIONS WEIGHT OF THERMAL MAXIMUM Model SURFACE AxBxC (mm) EMPTY LIQUID WORKING COLLECTOR CAPACITY (Lt) PRESSURE (kg) (bar) ALUMINUM PK SL AL 1010x1980x86 34 1,75 SELECTIVE 2,00 м² PK SL AL ALUMINUM 1230x1930x86 43... -
Page 6: Transport. Handling
TECHNICAL PASSPORT INSTALLATION and OPERATION MANUAL Antifreeze liquid mixture is absolutely necessary in any case. 4. Transport. Handling. Collectors are packed in cardboard or with stretch film, carton on glass surface and hard polystyrene on the corners and must always be transported in vertical position. Palletizing of collectors. -
Page 7: Pressure Loss
TECHNICAL PASSPORT INSTALLATION and OPERATION MANUAL 7. Pressure loss For the dimensioning of the circulating pump, the following tables which show the pressure drop against flow of thermal fluid through the collector must be taken under consideration: Scheme 5. Pressure loss of collectors PK SL AL 2,0 и 2,4 Recommended angle of installation of the collector The angle of the collector referred to the horizon must be the latitude of the place plus 5°. -
Page 8: Maintenance
TECHNICAL PASSPORT INSTALLATION and OPERATION MANUAL 10. Maintenance Our collectors require the minimum maintenance and attendance such as summarized below. Every two years the following actions must be taken: I. Check that all the fastening screws of the supports and the screws of the collectors’ holders are well tightened. -
Page 9: Maximum Limit Of Snow Load And Wind Speed
TECHNICAL PASSPORT INSTALLATION and OPERATION MANUAL The distance from an obstacle being at East, South or West must be : - at least 1,5 time the height of the obstacle for countries with latitude 30° - at least 2 times the height of the obstacle for countries with latitude 40° - at least 2,5 times the height of the obstacle for countries with latitude 50°... -
Page 10: Important Recommendations When Installing The Collector
TECHNICAL PASSPORT INSTALLATION and OPERATION MANUAL 13. Important recommendations when installing the collector - It is very critical to keep the front cover on until the whole circuit is full of thermal fluid otherwise very high temperatures may appear on the collectors which can damage them. - Verify again that the inclination towards the outlet of about 1-2% exists. -
Page 11: Warranty Terms
TECHNICAL PASSPORT INSTALLATION and OPERATION MANUAL - Start pouring the anti-freezing and anti-corrosive brine in the system using the venting upper point of the system or other appropriate method. A good air venting of the system is critical for any solar installation. -
Page 12: Technical Features
TECHNICAL PASSPORT INSTALLATION and OPERATION MANUAL 14.3. Claiming warranty Every customer who has purchased a collector from manufacturer, and who has good reasons to lay a warranty claim, shall proceed as follows: 14.3.1. Immediately notify in writing: - The installer, or the company that has sold the collector to him; - The distributor firm;... - Page 13 TECHNICAL PASSPORT INSTALLATION and OPERATION MANUAL 15. Technical features of collectors PK SL AL Табл 3 PK SL AL 2.0 PK SL AL 2.4 Overall dimensions 1010 1230 Width 1980 1930 Height Thickness Overall surface 2.00 2.37 Aperture/Absorber surface 1.86/1.86 2.23/2.23 Volume of heat carrier 1.40...
-
Page 14: Recycling And Waste Disposal
TECHNICAL PASSPORT INSTALLATION and OPERATION MANUAL 16. RECYCLING AND WASTE DISPOSAL 16.1. Recycling of collector packaging Parts of the packaging made of wood or paper can be used as combustible for the boiler. Submit the rest of the packaging material for recycling according to the local regulations and requirements. Replaced heating installation components must be submitted for processing to an authorized factory which complies with the environmental protection regulation. - Page 15 TECHNICAL PASSPORT INSTALLATION and OPERATION MANUAL Notes 15 - EN...
- Page 16 TECHNICAL PASSPORT INSTALLATION and OPERATION MANUAL 16 - EN...
