ADA EZ Pro
Hardwire Instructions
700503 Rev A 05-23-13
1.1
Installing the Optional Plug-In Transformer
An optional plug-in transformer is recommended in installations where the automatic door-opening feature
will be used frequently and is required if the Power Close or Push and Go fetures are activated.
1.1.1
Route the extension wire from the wall outlet to the frame of the door.
1.1.2
Refer to Figure 1, and mount one door cord bracket to the face of the door behind the
battery pack , mount the other door cord bracket to the frame of the door using the
supplied mounting screws.
© 2012 ADA EZ. ALL RIGHTS RESERVED.
NOTE
Figure 1. Installing the Optional Plug-In Transformer
700503
Rev. A, 05/23/13
1 of 2
