King Young Sumicom S675E Installation Manual

INSTALLATION GUIDE
Item Checklist
Accessory Pack
CPU Cooler
Power Adapter
Power Cord
Driver DVD
Installation
Guide
Mainboard and PCIe Riser Card Layout
1
2
3
4
5
6
7
8
9
10
11
12
M1675E
System Unit
PU Sponge
1 1 Secondary COM Port Header Secondary COM Port Header A1 A1 GigaLAN Port GigaLAN Port
2 2 CPU Socket CPU Socket A2 A2 Two USB 2.0 Ports Two USB 2.0 Ports
3 3 4 Lane PCIe Riser Card Slot 4 Lane PCIe Riser Card Slot A3 A3 PS/2 Mouse Port PS/2 Mouse Port
A4 A4 PS/2 Keyboard Port PS/2 Keyboard Port
4 4 Intel Giga LAN Chip Intel Giga LAN Chip
5 5 SODIMM Slots SODIMM Slots A5 A5 RS232/COM 1 Port RS232/COM 1 Port
6 6 Intel HM76 Chip Intel HM76 Chip A6 A6 VGA Port VGA Port
7 7 Super IO Chip Super IO Chip A7 A7 DC 12V Power In DC 12V Power In
A8 A8 Line-Out Port Line-Out Port
8 8 CPU Cooling Fan Connector CPU Cooling Fan Connector
9 9 SATA DVD-ROM Drive Cable SATA DVD-ROM Drive Cable A9 A9 4 Lane PCIe Riser Card 4 Lane PCIe Riser Card
10 10 CMOS Battery CMOS Battery A10 A10 Optional DVI-D Port Optional DVI-D Port
11 11 SATA HDD Connector SATA HDD Connector
B1 B1 Mic-In Phone Jack Mic-In Phone Jack
12 12 Buzzer Buzzer
B2 B2 Power/HDD LED Power/HDD LED
B3 B3 Power Button Power Button
B4 B4 Reset Button Reset Button
B5 B5 Ear Phone Jack Ear Phone Jack
B6 B6 Four USB 3.0 Ports Four USB 3.0 Ports
B7 B7 Optional GigaLAN Ports Optional GigaLAN Ports
Standard S675 Front IO Ports
B6 B6
B5 B1
B4 B3 B2
Barebone System Unpacking Guide
1
Loose the screws on the rear panel from the case.
2 Pull out the mainboard from the case.
Standard S675 Rear IO Ports
A3
A8 A7 A6 A5
A10
Model S675T/S675G3 Rear IO Ports
4 Lane PCIe
Riser Card
A9
A10
Optional DVI-D
Daughterr Board
Install Memory
2
SODIMM Slot
1
1
2
2 1
1
Install CPU and CPU Cooler
A9
CPU Cooler
Screw
2
A2 A1
A4
A9
2
3
FAN
Socket
1 Install CPU into CPU socket. Match socket pin 1 and
CPU cut edge. Screw down the black button to fasten
the CPU.
Glue the heatsink compound on the CPU die surface.
2
Install CPU cooler on top of CPU. Tighten CPU cooler
with screws into pillaret.
Connect CPU FAN connector to mainboard CPU
3
FAN socket.
Specifications are for reference only and subject to change without notice.
1
SODIMM
Complete
Insert SODIMM into the SODIMM slot
0
on the motherboard by 30 .
Push down the SODIMM.
Heatsink
1
180
Close Open
CPU
Socket988
CPU
1
*CPU install notice
