Outdoor Portable Charcoal Grill
Model No. CBT12011BL / CBT12011P / CBT12011M / CBT12011G
For Outdoor Use Only!
Warning! Be careful of sharp edges during assembly.
Made In China
Save these instructions for future reference. If you are assembling this unit for someone
else, give this manual to them to read and save for future use.
Contact 1-800-694-0013 for assistance. Do not return to place of purchase.
Advertisement
Table of Contents
Related Manuals for Outdoor Solutions CBT12011BL
Summary of Contents for Outdoor Solutions CBT12011BL
- Page 1 Outdoor Portable Charcoal Grill Model No. CBT12011BL / CBT12011P / CBT12011M / CBT12011G For Outdoor Use Only! Warning! Be careful of sharp edges during assembly. Made In China Save these instructions for future reference. If you are assembling this unit for someone else, give this manual to them to read and save for future use.
- Page 2 Parts & Hardware List Warranty Expanded View Parts List Part No. 1. Air vent B0105-B00 2. Lid handle B0108-D00 3. Lock 12011-010 4. Lid 12011-020 5. Top hinge 12011-030 6. Warming rack 12011-040 7. Cooking grid 12011-050 8. Charcoal grid 12011-060 9.
- Page 3 Assembly Instructions Tools Required: Knife or scissors and Phillips head screwdriver . To avoid losing any small components or hardware, assemble your product on a hard level surface that does not have cracks or openings. . Clear an area large enough to layout all components and hardware. .
- Page 4 Step 3 Attach leg to bottom bowl (C Screw 8Pcs). Step 4 Attach bottom air damper to bottom bowl (B Screw 4Pcs / D Wing nut 4Pcs).
- Page 5 Step 5 Attach bottom hinge to bottom bowl (C Screw 2Pcs / J Heat resistant washer 2Pcs / H Washer 2Pcs / L Lock washer 2Pcs / E Wing nut 2Pcs). Step 6 Attach lid to bottom bowl (N Pin 1Pc / O Cotter pin 1Pc).
- Page 6 Step 7 Insert charcoal grid into bottom bowl. Insert cooking grid into bottom bowl. Step 8 Slide warming rack into holes in lid and bottom bowl. Note: Look for corresponding holes on side of lid, insert short wire ends into lid hole one side at a time. Position warming rack legs into slots on bottom bowl sides.
- Page 7 Appendix This grill can be folded for your easy transport. Please refer to steps below: To lock lid (Note: Lid must be locked before transporting) To unlock lid (Note: Always unlock and open lid before lighting) To fold and unfold grill legs (Note: Always lock lid before fold grill).
- Page 8 SAFETY HINTS 1. Stand your grill on a safe, level surface away from flammable items such as wooden fences or over hanging tree branches. NEVER USE your grill indoors. 2. DO NOT use petrol, paraffin, methylated spirit or lighter fuel to light your charcoal. 3.
