Outdoor Round Charcoal Barbecue Grill
Model No. CBC22043HB
For Outdoor Use Only!
WARNING! BE CAREFUL OF SHARP EDGES DURING ASSEMBLY.
Made In China
Save these instructions for future reference. If you are assembling this unit for someone
else, give this manual to them to read and save for future use.
Contact 1-800-694-0013 for assistance. Do not return to place of purchase.
Advertisement
Table of Contents
Related Manuals for Outdoor Solutions CBC22043HB
Summary of Contents for Outdoor Solutions CBC22043HB
- Page 1 Outdoor Round Charcoal Barbecue Grill Model No. CBC22043HB For Outdoor Use Only! WARNING! BE CAREFUL OF SHARP EDGES DURING ASSEMBLY. Made In China Save these instructions for future reference. If you are assembling this unit for someone else, give this manual to them to read and save for future use.
- Page 2 Parts & Hardware List Warranty Part List Expanded View Part No. 1. Lid Handle B0108-C00 2. Air Vent B0105-A00 3. Lid 22043-01B 4. Bottom Bowl 22043-020 5. Warming Rack N2204-151 6. Cooking Grid N2204-022 7. Charcoal Grid N2204-023 8. Left Top Hinge* P2204-261 9.
- Page 3 Assembly Instructions Tools Required: Knife or scissors, Phillips head screwdriver and wrench . To avoid losing any small components or hardware, assemble your product on a hard level surface that does not have cracks oropenings. . Clear an area large enough to layout all components and hardware. .
- Page 4 Step 3 Attach feet to legs. Step 4 Attach legs to bottom bowl (B Screw 8Pcs / E Wing nut 8Pcs / F Washer 8Pcs / G Lock washer 8Pcs ) Attach bottom mesh and wheels to legs ( C Nut 2Pcs / E Wing Nut 2Pcs / F Washer 2Pcs ) Note: Do not fully tighten screws until bottom mesh is attached.
- Page 5 Step 5 Attach lock to bottom bowl ( A screw 2Pcs ) Step 6 Attach lid to bottom bowl ( H Pin 1Pc / I Cotter pin 1Pc )
- Page 6 Step 7 Insert warming rack Step 8 Insert charcoal grid and cooking grid Insert ash receiver.
- Page 7 Step 9 Congratulations, your assembly is now complete. Read operating instructions before proceeding. Appendix To lock lid: lift up on lock handle, place lock bracket onto rise of lid and push lock handle down to secure. To unlock lid: lift up on lock handle, remove lock bracket from rise on lid, push lock handle down.
-
Page 8: Helpful Hints
SAFETY HINTS 1. Stand your grill on a safe, level surface away from flammable items such as wooden fences or over hanging tree branches. NEVER USE your grill indoors. 2. DO NOT use petrol, paraffin, methylated spirit or lighter fuel to light your charcoal. 3.
