- Page 1 Ver 1.0 USER'S MANUAL PWR Series II RADIO REMOTE CONTROL SYSTEMS 0341 Drivecon Inc. reserves the right to alter or amend the above information without notice.
-
Page 2: Table Of Contents
Figure 10 LCD Display in Service Mode..............14 Figure 11 Pushbutton as keyboard for Hoist Condition Monitoring Unt......14 Figure 12 LCD representing Tared Load ..............14 Drivecon Inc. reserves the right to alter or amend the above information without notice. - Page 3 Charging temperature 5ºC to 35ºC 41F to 95F Operating Time 12h at 50% PWRSII 6-2-11 model. 8h at 50% PWRSII 6-2-13 model. Page 1 of 18 Drivecon Inc. reserves the right to alter or amend the above information without notice.
-
Page 4: Safety Precautions
Do not use the radio control system when visibility is limited. • Avoid knocking, bumping or dropping the transmitter. Do not use the equipment if failure is detected. • Page 2 of 18 Drivecon Inc. reserves the right to alter or amend the above information without notice. -
Page 5: Figure 1 Battery Charger Bc60K
(keys, coins, etc.). • Always keep contacts clean. • Never leave batteries in direct sunlight. Page 3 of 18 Drivecon Inc. reserves the right to alter or amend the above information without notice. -
Page 6: Figure 2 Receiver Box Dimensions
The way to connect the receiver box to the crane' s electrical installations is using a cable with a terminal multiple-pole connector: Note: See attached drilling pattern sheet. Page 4 of 18 Drivecon Inc. reserves the right to alter or amend the above information without notice. -
Page 7: Figure 3 Receiver To Power Electric Circuit Connection
8A fuse(s) has to be provided in the crane control panel for the for the output relays. Page 5 of 18 Drivecon Inc. reserves the right to alter or amend the above information without notice. -
Page 8: Use
Remember to connect the ground cable. Use only the approved cables. Select the appropriate voltage on the receiver (115Vac default, 230Vac or 48 Vac). Page 6 of 18 Drivecon Inc. reserves the right to alter or amend the above information without notice. -
Page 9: Figure 5 Connection Diagram For Pwrsii 6-2-13
Remember to connect the ground cable. Use only the approved cables. Select the appropriate voltage on the receiver (115Vac default, 230Vac or 48 Vac). Page 7 of 18 Drivecon Inc. reserves the right to alter or amend the above information without notice. -
Page 10: Starting Up
4. Pull up STOP pushbutton. The transmitter LED should flash yellow-green for a second. 5. Press START The transmitter LED should light up green indicating that the transmitter is transmitting. Page 8 of 18 Drivecon Inc. reserves the right to alter or amend the above information without notice. -
Page 11: Figure 6 Pwrsii 6-2-11 And Pwrsii 6-2-13 Transmitters
Flashing ON (quickly) each time a good frame is received with ID correct. This means that the receiver has recognized the transmitter’s identification code Page 9 o18 Drivecon Inc. reserves the right to alter or amend the above information without notice. -
Page 12: Spurious Disturbance
If the equipment is installed on a crane with a friction power supply, where electric arcs are produced as a result of defective contact, an RC circuit should be fitted between each phase and earth. Page 10 of 18 Drivecon Inc. reserves the right to alter or amend the above information without notice. - Page 13 Remember that you are going to control remotely a moving piece of machinery. The safety instructions described in chapter 3 of this manual must be strictly adhered to. Page 11 of 18 Drivecon Inc. reserves the right to alter or amend the above information without notice.
-
Page 14: Programming Of A Replacement Transmitter
EEPROM is being written with the stored parameters. Wait for the orange LED to turn off. In case the LED remains in red repeat the process. 5. Press the STOP button. This completes the programming processes. Page 12 of 18 Drivecon Inc. reserves the right to alter or amend the above information without notice. -
Page 15: General Description Of Service Mode
6. Press Pushbutton UP in second step, and then START. The system enters in Service Mode. See figure 9. Figure 9 Entering the Service mode. Drivecon Inc. reserves the right to alter or amend the above information without notice. Page 13 of18... -
Page 16: Keys For Moving Within The Menus
LCD representing Tared Load Figure 12 6.5 Resetting the Tared Load. Pressing the ESC button for several seconds performs the reset of the Tared Load. Page 14 of 18 Drivecon Inc. reserves the right to alter or amend the above information without notice. -
Page 17: Exiting Service Mode
If the transmitter does not receive a valid frame from the receiver within 2.5 seconds, the display will erase the data being displayed. This means that there is faulty link between transmitter and receiver. Page 15 of 18 Drivecon Inc. reserves the right to alter or amend the above information without notice. -
Page 18: Preventive Maintenance
Check to make sure the cable fixture screws are tight. • Check the contacts on the fuses and the fuse-holders. Battery charger and batteries: • Keep all contacts clean. Page 16 of 18 Drivecon Inc. reserves the right to alter or amend the above information without notice. - Page 19 If the problem is associated with the equipment, please send both the transmitter and the receiver to the Technical Assistance Service, together with a description of the problem and the status of the LEDs. Page 17 of 18 Drivecon Inc. reserves the right to alter or amend the above information without notice.
-
Page 20: Drilling Pattern Sheet
8 Drilling pattern sheet. NO SCALE 255.5mm = 10” 169.5mm = 6.7” Page 18 of 18 Drivecon Inc. reserves the right to alter or amend the above information without notice.
